K8S ) 7주차 과제

zosys 2026. 2. 18. 16:52

2026. 2. 18. 16:52

RKE2란?

RKE2는 Rancher에서 개발한 엔터프라이즈급 Kubernetes 배포판으로,

특히 미국 연방 정부 수준의 보안 및 규정 준수를 목표로 설계된 보안 중심 K8S입니다.

보안 및 규정 준수
- 기본 설정만으로 CIS Kubernetes Benchmark v1.7 / v1.8 통과 가능
- FIPS 140-2 규정 준수 지원
- 빌드 파이프라인에서 Trivy 기반 CVE 정기 점검
아키텍처 특징
- 컨트롤 플레인 컴포넌트를 kubelet이 관리하는 Static Pod로 실행
- 기본 컨테이너 런타임은 containerd
- 불필요한 구성 요소를 제거한 하드닝된 Kubernetes
운영방식
- 단독 실행 가능
- Rancher 플랫폼과 통합 운영 가능
구성요소
- K8s
  - API Server , Controller Manager , Scheduler
  - Proxy , Kubelet
- etcd
- runc
- containerd/cri
- CNI: Canal
- CoreDNS
- Ingress NGINX Controller and/or Traefik
- Metrics Server
- Helm

RKE2 실습

실습환경배포

PS C:\Users\bom\Desktop\스터디\7week\k8s-rke2> pwd

Path
----
C:\Users\bom\Desktop\스터디\7week\k8s-rke2

PS C:\Users\bom\Desktop\스터디\7week\k8s-rke2> vagrant up
Bringing machine 'k8s-node1' up with 'virtualbox' provider...
Bringing machine 'k8s-node2' up with 'virtualbox' provider...
==> k8s-node1: Preparing master VM for linked clones...
    k8s-node1: This is a one time operation. Once the master VM is prepared,
    k8s-node1: it will be used as a base for linked clones, making the creation
    k8s-node1: of new VMs take milliseconds on a modern system.
==> k8s-node1: Importing base box 'bento/rockylinux-9'...

###################중략####################

PS C:\Users\bom\Desktop\스터디\7week\k8s-rke2> vagrant status
Current machine states:

k8s-node1                 running (virtualbox)
k8s-node2                 running (virtualbox)

설치

RKE 서버 노드 설치

  PS C:\Users\bom\Desktop\스터디\7week\k8s-rke2> vagrant ssh k8s-node1

  This system is built by the Bento project by Chef Software
  More information can be found at https://github.com/chef/bento

  Use of this system is acceptance of the OS vendor EULA and License Agreements.
  [root@k8s-node1 ~]# vi install.sh
  [root@k8s-node1 ~]# ll
  total 28
  -rw-r--r--. 1 root root 25291 Feb 18 14:14 install.sh
  [root@k8s-node1 ~]# chmod +x install.sh
  [root@k8s-node1 ~]# INSTALL_RKE2_CHANNEL=v1.33 ./install.sh

  [root@k8s-node1 ~]# rke2 --version
  rke2 version v1.33.8+rke2r1 (eb75e3c1774cee5a584259d6fee77eb8cfa9b430)
  go version go1.24.12 X:boringcrypto

  [root@k8s-node1 ~]# dnf repolist
  repo id                                                              repo name
  appstream                                                            Rocky Linux 9 - AppStream
  baseos                                                               Rocky Linux 9 - BaseOS
  extras                                                               Rocky Linux 9 - Extras
  rancher-rke2-1.33-stable                                             Rancher RKE2 1.33 (v1.33)
  rancher-rke2-common-stable                                           Rancher RKE2 Common (v1.33)

  [root@k8s-node1 ~]# cat /etc/yum.repos.d/rancher-rke2.repo
  [rancher-rke2-common-stable]
  name=Rancher RKE2 Common (v1.33)
  baseurl=https://rpm.rancher.io/rke2/stable/common/centos/9/noarch
  enabled=1
  gpgcheck=1
  repo_gpgcheck=1
  gpgkey=https://rpm.rancher.io/public.key
  [rancher-rke2-1.33-stable]
  name=Rancher RKE2 1.33 (v1.33)
  baseurl=https://rpm.rancher.io/rke2/stable/1.33/centos/9/x86_64
  enabled=1
  gpgcheck=1
  repo_gpgcheck=1
  gpgkey=https://rpm.rancher.io/public.key

  [root@k8s-node1 ~]# cat /etc/rancher/rke2/config.yaml
  write-kubeconfig-mode: "0644"

  debug: true

  cni: canal

  bind-address: 192.168.10.11
  advertise-address: 192.168.10.11
  node-ip: 192.168.10.11

  disable-cloud-controller: true

  disable:
    - servicelb
    - rke2-coredns-autoscaler
    - rke2-ingress-nginx
    - rke2-snapshot-controller
    - rke2-snapshot-controller-crd
    - rke2-snapshot-validation-webhook

#모니터링

Every 2.0s: pstree -a                                                                                  k8s-node1: Wed Feb 18 14:18:15 2026

systemd --switched-root --system --deserialize 31
  |-NetworkManager --no-daemon
  |   `-2*[{NetworkManager}]
  |-VBoxDRMClient
  |   `-4*[{VBoxDRMClient}]
  |-VBoxService --pidfile /var/run/vboxadd-service.sh
  |   `-8*[{VBoxService}]
  |-agetty -o -p -- \\u --noclear - linux

[root@k8s-node1 ~]# journalctl -u rke2-server -f
Feb 18 14:17:57 k8s-node1 systemd[1]: Starting Rancher Kubernetes Engine v2 (server)...
Feb 18 14:17:57 k8s-node1 rke2[6907]: time="2026-02-18T14:17:57+09:00" level=warning msg="not running in CIS mode"
Feb 18 14:17:57 k8s-node1 rke2[6907]: time="2026-02-18T14:17:57+09:00" level=info msg="Applying Pod Security Admission Configuration"
Feb 18 14:17:57 k8s-node1 rke2[6907]: time="2026-02-18T14:17:57+09:00" level=info msg="Starting rke2 v1.33.8+rke2r1 (eb75e3c1774cee5a584259d6fee77eb8cfa9b430)"

[root@k8s-node1 ~]# systemctl status rke2-server --no-pager
● rke2-server.service - Rancher Kubernetes Engine v2 (server)
     Loaded: loaded (/usr/lib/systemd/system/rke2-server.service; enabled; preset: disabled)
     Active: active (running) since Wed 2026-02-18 14:21:54 KST; 3s ago
       Docs: https://github.com/rancher/rke2#readme
    Process: 6905 ExecStartPre=/sbin/modprobe br_netfilter (code=exited, status=0/SUCCESS)
    Process: 6906 ExecStartPre=/sbin/modprobe overlay (code=exited, status=0/SUCCESS)

    [root@k8s-node1 ~]# k get pod -A
NAMESPACE     NAME                                         READY   STATUS             RESTARTS      AGE
kube-system   etcd-k8s-node1                               1/1     Running            0             4m27s
kube-system   helm-install-rke2-canal-4sndc                0/1     Completed          0             2m2s
kube-system   helm-install-rke2-coredns-ctxlg              0/1     Completed          0             2m2s
kube-system   helm-install-rke2-metrics-server-hklqz       0/1     Completed          0             2m2s
kube-system   helm-install-rke2-runtimeclasses-57qwm       0/1     Completed          0             2m2s
kube-system   kube-apiserver-k8s-node1                     1/1     Running            0             4m27s
kube-system   kube-controller-manager-k8s-node1            1/1     Running            0             3m49s
kube-system   kube-proxy-k8s-node1                         1/1     Running            0             4m27s
kube-system   kube-scheduler-k8s-node1                     1/1     Running            0             3m49s
kube-system   rke2-canal-vwnxr                             1/2     CrashLoopBackOff   3 (39s ago)   112s
kube-system   rke2-coredns-rke2-coredns-559595db99-sgwf7   1/1     Running            0             114s
kube-system   rke2-metrics-server-fdcdf575d-6tb9x          1/1     Running            0             83s
```

![image.png](attachment:101ce327-1607-4334-965b-17744799c8dd:image.png)

rke2디렉터리 : addon helm chart,인증서

  [root@k8s-node1 ~]# tree /var/lib/rancher/rke2 -L 1
  /var/lib/rancher/rke2
  ├── agent
  ├── bin -> /var/lib/rancher/rke2/data/v1.33.8-rke2r1-1b2872361ec5/bin
  ├── data
  └── server

  4 directories, 0 files

  [root@k8s-node1 ~]# tree /var/lib/rancher/rke2/server/ -L 1
  /var/lib/rancher/rke2/server/
  ├── agent-token -> /var/lib/rancher/rke2/server/token
  ├── cred
  ├── db
  ├── etc
  ├── manifests
  ├── node-token -> /var/lib/rancher/rke2/server/token
  ├── tls
  └── token

  5 directories, 3 files

  [root@k8s-node1 ~]# cat /var/lib/rancher/rke2/server/token
  K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722
  [root@k8s-node1 ~]# kubectl get crd | grep -E 'helm|addon'
  addons.k3s.cattle.io                                    2026-02-18T05:20:08Z
  helmchartconfigs.helm.cattle.io                         2026-02-18T05:20:08Z
  helmcharts.helm.cattle.io                               2026-02-18T05:20:08Z

  [root@k8s-node1 ~]# cat /var/lib/rancher/rke2/agent/etc/crictl.yaml
  runtime-endpoint: unix:///run/k3s/containerd/containerd.sock

  [root@k8s-node1 ~]# crictl images
  IMAGE                                           TAG                            IMAGE ID            SIZE
  docker.io/rancher/hardened-calico               v3.31.3-build20260206          952c7453d7729       233MB
  docker.io/rancher/hardened-coredns              v1.14.1-build20260206          ad73f5d41fead       30.3MB
  docker.io/rancher/hardened-etcd                 v3.5.26-k3s1-build20260126     4b6a4b1e13f3e       18.7MB
  docker.io/rancher/hardened-flannel              v0.28.1-build20260206          170c73d2937d4       23MB
  docker.io/rancher/hardened-k8s-metrics-server   v0.8.1-build20260206           7a4190a831781       21.4MB
  docker.io/rancher/hardened-kubernetes           v1.33.8-rke2r1-build20260210   ceea5f6055309       201MB
  docker.io/rancher/klipper-helm                  v0.9.14-build20260210          2e2c8cbfb79b8       64.1MB
  docker.io/rancher/mirrored-pause                3.6                            6270bb605e12e       301kB
  docker.io/rancher/rke2-runtime                  v1.33.8-rke2r1                 b1d89cfc44e65       100MB

  #보안설정 확인
  [root@k8s-node1 ~]# cat /var/lib/rancher/rke2/agent/etc/kubelet.conf.d/00-rke2-defaults.conf
  address: 192.168.10.11
  apiVersion: kubelet.config.k8s.io/v1beta1
  authentication:
    anonymous:
      enabled: false
    webhook:
      cacheTTL: 2m0s
      enabled: true
    x509:
      clientCAFile: /var/lib/rancher/rke2/agent/client-ca.crt
  authorization:
    mode: Webhook
    webhook:
      cacheAuthorizedTTL: 5m0s
      cacheUnauthorizedTTL: 30s
  cgroupDriver: systemd
  clusterDNS:
  - 10.43.0.10
  clusterDomain: cluster.local
  containerRuntimeEndpoint: unix:///run/k3s/containerd/containerd.sock
  cpuManagerReconcilePeriod: 10s
  crashLoopBackOff: {}

  ***failSwapOn: false**                  # 원래 쿠버네티스는 스왑(Swap) 메모리가 켜져 있으면 실행되지 않지만, RKE2는 이를 허용하도록 설정되어 있습니다.
  **nodeStatusUpdateFrequency: 10s**     # 10초마다 "나 살아있어요"라고 컨트롤플레인 노드에 보고
  **serializeImagePulls: false**         # 이미지 병렬 pull 허용*

  ##중략###

노드관리

워커 노드 추가

토큰확인

  [root@k8s-node1 ~]# cat /var/lib/rancher/rke2/server/node-token
  K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722

  [root@k8s-node1 ~]# ss -tnlp | grep 9345
  LISTEN 0      4096       127.0.0.1:9345       0.0.0.0:*    users:(("rke2",pid=6907,fd=7))
  LISTEN 0      4096   192.168.10.11:9345       0.0.0.0:*    users:(("rke2",pid=6907,fd=6))
  LISTEN 0      4096           [::1]:9345          [::]:*    users:(("rke2",pid=6907,fd=8))

워커 노드 추가

  [root@k8s-node2 ~]# curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE="agent" INSTALL_RKE2_CHANNEL=v1.33 sh -
  [INFO]  using stable RPM repositories
  [INFO]  using 1.33 series from channel stable
  Rancher RKE2 Common (v1.33)                                                                               2.1 kB/s | 659  B     00:00
  Rancher RKE2 Common (v1.33)                                                                               8.0 kB/s | 2.4 kB     00:00
  Importing GPG key 0xE257814A:
   Userid     : "Rancher (CI) <ci@rancher.com>"
   Fingerprint: C8CF F216 4551 26E9 B9C9 18BE 925E A29A E257 814A
   From       : https://rpm.rancher.io/public.key
  Rancher RKE2 Common (v1.33)                                                                               3.6 kB/s | 2.6 kB     00:00
  Rancher RKE2 1.33 (v1.33)                                                                                 2.3 kB/s | 659  B     00:00
  Rancher RKE2 1.33 (v1.33)                                                                                  19 kB/s | 2.4 kB     00:00
  Importing GPG key 0xE257814A:
   Userid     : "Rancher (CI) <ci@rancher.com>"
   Fingerprint: C8CF F216 4551 26E9 B9C9 18BE 925E A29A E257 814A
   From       : https://rpm.rancher.io/public.key
  Rancher RKE2 1.33 (v1.33)                                                                                 8.4 kB/s | 5.9 kB     00:00
  Dependencies resolved.
  ==========================================================================================================================================
   Package                      Architecture           Version                             Repository                                  Size
  ==========================================================================================================================================
  Installing:
   rke2-agent                   x86_64                 1.33.8~rke2r1-0.el9                 rancher-rke2-1.33-stable                   8.3 k
  Installing dependencies:
   rke2-common                  x86_64                 1.33.8~rke2r1-0.el9                 rancher-rke2-1.33-stable                    27 M
   rke2-selinux                 noarch                 0.22-1.el9                          rancher-rke2-common-stable                  22 k

  Transaction Summary
  ==========================================================================================================================================
  Install  3 Packages

  [root@k8s-node2 ~]# TOKEN=K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722
  [root@k8s-node2 ~]# mkdir -p /etc/rancher/rke2/
  [root@k8s-node2 ~]# cat << EOF > /etc/rancher/rke2/config.yaml
  server: https://192.168.10.11:9345
  token: $TOKEN
  EOF

  [root@k8s-node2 ~]# systemctl enable --now rke2-agent.service
  Created symlink /etc/systemd/system/multi-user.target.wants/rke2-agent.service → /usr/lib/systemd/system/rke2-agent.service.

워커노드 정보 확인

  [k8s-node1]

  [root@k8s-node1 ~]# kubectl get node -owide
  NAME        STATUS   ROLES                       AGE     VERSION          INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                      KERNEL-VERSION                 CONTAINER-RUNTIME
  k8s-node1   Ready    control-plane,etcd,master   19m     v1.33.8+rke2r1   192.168.10.11   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
  k8s-node2   Ready    <none>                      7m17s   v1.33.8+rke2r1   192.168.10.12   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1

  [root@k8s-node1 ~]# kubectl get pod -n kube-system -owide | grep k8s-node2
  kube-proxy-k8s-node2                         1/1     Running            0             7m48s   192.168.10.12   k8s-node2   <none>           <none>
  rke2-canal-wr4d8                             1/2     CrashLoopBackOff   6 (60s ago)   7m48s   192.168.10.12   k8s-node2   <none>           <none>

  [k8s-node2]
  [root@k8s-node2 agent]# tree /var/lib/rancher/rke2 -L 1
  /var/lib/rancher/rke2
  ├── agent
  ├── bin -> /var/lib/rancher/rke2/data/v1.33.8-rke2r1-1b2872361ec5/bin
  ├── data
  └── server

  4 directories, 0 files

  [root@k8s-node2 agent]# systemctl status rke2-agent.service --no-pager
  ● rke2-agent.service - Rancher Kubernetes Engine v2 (agent)
       Loaded: loaded (/usr/lib/systemd/system/rke2-agent.service; enabled; preset: disabled)
       Active: active (running) since Wed 2026-02-18 14:31:50 KST; 8min ago
         Docs: https://github.com/rancher/rke2#readme
      Process: 6711 ExecStartPre=/sbin/modprobe br_netfilter (code=exited, status=0/SUCCESS)
      Process: 6712 ExecStartPre=/sbin/modprobe overlay (code=exited, status=0/SUCCESS)
     Main PID: 6713 (rke2)
        Tasks: 61
       Memory: 2.3G
          CPU: 53.113s

   [root@k8s-node2 agent]# ln -s /var/lib/rancher/rke2/bin/containerd /usr/local/bin/containerd
  ln -s /var/lib/rancher/rke2/bin/crictl /usr/local/bin/crictl
  ln -s /var/lib/rancher/rke2/agent/etc/crictl.yaml /etc/crictl.yaml

워커 노드 삭제 → 워커노드 재추가

워커노드 삭제를 위해 drain 진행

  [root@k8s-node1 ~]# kubectl drain k8s-node2 --ignore-daemonsets --delete-emptydir-data
  node/k8s-node2 cordoned
  Warning: ignoring DaemonSet-managed Pods: kube-system/rke2-canal-wr4d8
  node/k8s-node2 drained
  [root@k8s-node1 ~]# kubectl delete node k8s-node2
  node "k8s-node2" deleted

워커 노드 삭제

  [root@k8s-node2 agent]# systemctl stop rke2-agent
  [root@k8s-node2 agent]# ls -l /usr/bin/rke2*
  -rwxr-xr-x. 1 root root 124432768 Feb 14 04:11 /usr/bin/rke2
  -rwxr-xr-x. 1 root root      3373 Feb 18 02:48 /usr/bin/rke2-killall.sh
  -rwxr-xr-x. 1 root root      5606 Feb 18 02:48 /usr/bin/rke2-uninstall.sh
  [root@k8s-node2 agent]# cat /usr/bin/rke2-uninstall.sh
  #!/bin/sh
  set -ex

  # helper function for timestamped logging
  log() {
      echo "[$(date +'%Y-%m-%d %H:%M:%S')] $*"
  }

  # helper function for logging error and exiting with a message
  error() {
      log "ERROR: $*" >&2
      exit 1
  }

  [root@k8s-node2 agent]# tree /etc/rancher
  /etc/rancher [error opening dir]

  0 directories, 0 files
  [root@k8s-node2 agent]# tree /var/lib/rancher
  /var/lib/rancher [error opening dir]

워커노드 재추가

  [root@k8s-node2 agent]# curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE="agent" INSTALL_RKE2_CHANNEL=v1.33 sh -
  shell-init: error retrieving current directory: getcwd: cannot access parent directories: No such file or directory
  [INFO]  using stable RPM repositories
  [INFO]  using 1.33 series from channel stable
  Rancher RKE2 Common (v1.33)                                                                               2.3 kB/s | 659  B     00:00
  Rancher RKE2 1.33 (v1.33)                                                                                 1.5 kB/s | 659  B     00:00
  Dependencies resolved.
  ==========================================================================================================================================
   Package                      Architecture           Version                             Repository                                  Size
  ==========================================================================================================================================
  Installing:
   rke2-agent                   x86_64                 1.33.8~rke2r1-0.el9                 rancher-rke2-1.33-stable                   8.3 k
  Installing dependencies:
   rke2-common                  x86_64                 1.33.8~rke2r1-0.el9                 rancher-rke2-1.33-stable                    27 M
   rke2-selinux                 noarch                 0.22-1.el9                          rancher-rke2-common-stable                  22 k

  Transaction Summary
  ==========================================================================================================================================
  Install  3 Packages

  [root@k8s-node2 agent]# TOKEN=K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722
  [root@k8s-node2 agent]# echo $TOKEN
  K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722

  [root@k8s-node2 agent]# cat << EOF > /etc/rancher/rke2/config.yaml
  server: https://192.168.10.11:9345
  token: $TOKEN
  EOF
  [root@k8s-node2 agent]# cat /etc/rancher/rke2/config.yaml
  server: https://192.168.10.11:9345
  token: K106e21a8fb999718d131eb1dce5e2a55218ca993338cdff4de2c72137794588cb2::server:56d69e65a53934b4010ecd46aafe8722
  [root@k8s-node2 agent]# systemctl enable --now rke2-agent.service
  Created symlink /etc/systemd/system/multi-user.target.wants/rke2-agent.service → /usr/lib/systemd/system/rke2-agent.service.

  [root@k8s-node2 agent]# systemctl enable --now rke2-agent.service
  Created symlink /etc/systemd/system/multi-user.target.wants/rke2-agent.service → /usr/lib/systemd/system/rke2-agent.service.
  [root@k8s-node2 agent]# journalctl -u rke2-agent -f

샘플앱 배포진행

  [root@k8s-node1 ~]# kubectl get deploy,pod,svc,ep -owide
  Warning: v1 Endpoints is deprecated in v1.33+; use discovery.k8s.io/v1 EndpointSlice
  NAME                     READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES           SELECTOR
  deployment.apps/webpod   0/2     2            0           3s    webpod       traefik/whoami   app=webpod

  NAME                          READY   STATUS              RESTARTS   AGE   IP       NODE        NOMINATED NODE   READINESS GATES
  pod/webpod-697b545f57-4nnh7   0/1     ContainerCreating   0          3s    <none>   k8s-node2   <none>           <none>
  pod/webpod-697b545f57-tftg7   0/1     Pending             0          3s    <none>   k8s-node1   <none>           <none>

  NAME                 TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)        AGE   SELECTOR
  service/kubernetes   ClusterIP   10.43.0.1      <none>        443/TCP        27m   <none>
  service/webpod       NodePort    10.43.182.94   <none>        80:30000/TCP   3s    app=webpod

  NAME                   ENDPOINTS            AGE
  endpoints/kubernetes   192.168.10.11:6443   27m
  endpoints/webpod       <none>               3s

업그레이드

인증서 관리 및 수동갱신

인증서 관리 요약
- 클라이언트/서버 인증서 유효기간: 발급일 기준 365일
- 자동 갱신 조건:
  - 인증서가 만료되었거나
  - 만료 120일 이내로 남았을 경우

    → RKE2 재시작 시 자동 갱신
- 자동 갱신 방식: 기존 키를 재사용하여 유효기간만 연장
- 새 키 + 새 인증서로 교체하려면: rotate 명령어로 수동 교체 필요
- 만료 120일 이내 진입 시: Kubernetes 이벤트 CertificateExpirationWarning 발생

노드인증서와 만료일 확인

[[k8s-node1]

[root@k8s-node1 ~]# rke2 certificate check --output table
INFO[0000] Server detected, checking agent and server certificates

FILENAME                           SUBJECT                             USAGES                  EXPIRES                  RESIDUAL TIME   STATUS

client-controller.crt system:kube-controller-manager ClientAuth Feb 18, 2027 05:17 UTC 1 year OK
client-controller.crt rke2-client-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK
kube-controller-manager.crt kube-controller-manager ServerAuth Feb 18, 2027 05:17 UTC 1 year OK
kube-controller-manager.crt rke2-server-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK
client-scheduler.crt system:kube-scheduler ClientAuth Feb 18, 2027 05:17 UTC 1 year OK

[[k8s-node2]

[root@k8s-node2 agent]# rke2 certificate check --output table
INFO[0000] Server detected, checking agent and server certificates

FILENAME SUBJECT USAGES EXPIRES RESIDUAL TIME STATUS

client-kube-proxy.crt system:kube-proxy ClientAuth Feb 18, 2027 05:46 UTC 1 year OK
client-kube-proxy.crt rke2-client-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK
client-kubelet.crt system:node:k8s-node2 ClientAuth Feb 18, 2027 05:46 UTC 1 year OK
client-kubelet.crt rke2-client-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK
serving-kubelet.crt k8s-node2 ServerAuth Feb 18, 2027 05:46 UTC 1 year OK
serving-kubelet.crt rke2-server-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK
client-rke2-controller.crt system:rke2-controller ClientAuth Feb 18, 2027 05:46 UTC 1 year OK
client-rke2-controller.crt rke2-client-ca@1771391877 CertSign Feb 16, 2036 05:17 UTC 10 years OK


  - 인증서 수동 교체 : rke2 certificate rotate 명령 사용.

      ```bash
      [root@k8s-node1 ~]# systemctl stop rke2-server

      [root@k8s-node1 ~]# rke2 certificate rotate
      INFO[0000] Server detected, rotating agent and server certificates
      INFO[0000] Rotating dynamic listener certificate
      INFO[0000] Rotating certificates for rke2-controller
      INFO[0000] Rotating certificates for api-server
      INFO[0000] Rotating certificates for admin
      INFO[0000] Rotating certificates for auth-proxy
      INFO[0000] Rotating certificates for cloud-controller
      INFO[0000] Rotating certificates for etcd
      INFO[0000] Rotating certificates for scheduler
      INFO[0000] Rotating certificates for supervisor
      INFO[0000] Rotating certificates for kube-proxy
      INFO[0000] Rotating certificates for controller-manager
      INFO[0000] Rotating certificates for kubelet
      INFO[0000] Successfully backed up certificates to /var/lib/rancher/rke2/server/tls-1771393856, please restart rke2 server or agent to rotate certificates

      [root@k8s-node1 ~]# systemctl start rke2-server
      [root@k8s-node1 ~]# rke2 certificate check --output table
      INFO[0000] Server detected, checking agent and server certificates

      FILENAME                           SUBJECT                             USAGES                  EXPIRES                  RESIDUAL TIME   STATUS
      --------                           -------                             ------                  -------                  -------------   ------
      client-auth-proxy.crt              system:auth-proxy                   ClientAuth              Feb 18, 2027 05:52 UTC   1 year          OK
      client-auth-proxy.crt              rke2-request-header-ca@1771391877   CertSign                Feb 16, 2036 05:17 UTC   10 years        OK
      client-rke2-cloud-controller.crt   rke2-cloud-controller-manager       ClientAuth              Feb 18, 2027 05:52 UTC   1 year          OK
      client-rke2-cloud-controller.crt   rke2-client-ca@1771391877           CertSign                Feb 16, 2036 05:17 UTC   10 years        OK

      [root@k8s-node1 ~]# diff /etc/rancher/rke2/rke2.yaml ~/.kube/config
      18,19c18,19
      <     client-certificate-data: LS0tLS1CRUdJTiBDRVJUS //중략

      >     client-certificate-data: LS0tLS1CRUdJTiBDRVJUS //중
      ```

업그레이드 소개
1. 업그레이드 정책

  Kubernetes Version Skew Policy 적용
- RKE2 업그레이드 시 Kubernetes 버전 편차 정책을 따름
- 마이너 버전을 건너뛰는 업그레이드는 불가

  예시
- v1.26 → v1.28 직접 업그레이드 불가
- v1.26 → v1.27 → v1.28 순차 업그레이드 필요
1. Release Channels

  설치 스크립트 또는 자동 업그레이드 기능 사용 시, 릴리스 채널 기준으로 버전이 선택됨.

  stable (기본값)
- 운영 환경 권장
- 커뮤니티 검증 완료
- Rancher 최신 릴리스와 호환

  latest
- 최신 기능 테스트 목적
- 커뮤니티 검증이 충분하지 않을 수 있음
- Rancher와 호환되지 않을 가능성 존재

  특정 Kubernetes 마이너 버전 채널 (예: v1.34)
- 해당 마이너 버전 계열의 최신 패치 버전 제공
- 반드시 안정 릴리스만 의미하지는 않음
1. 설치 스크립트 주요 변수

  INSTALL_RKE2_VERSION
- 설치할 RKE2 버전 지정
- 기본값: stable

  INSTALL_RKE2_TYPE
- 생성할 systemd 서비스 유형 지정
- server (기본값)
- agent

  INSTALL_RKE2_CHANNEL_URL
- 릴리스 채널 정보를 가져올 URL
- 기본값:

  https://update.rke2.io/v1-release/channels

INSTALL_RKE2_CHANNEL

- 사용할 릴리스 채널 지정
- 기본값: stable
- 선택 가능: latest, testing

INSTALL_RKE2_METHOD

- 설치 방식 지정
- rpm: RPM 기반 시스템 기본값
- tar: 그 외 시스템 기본값

수동업그레이드

수동업그레이드 절차 : 컨트롤노드를 하나씩 업그레이드 → 워커노드 업그레이드

[rke2-server] 컨트롤 플레인 노드 업그레이드

[root@k8s-node1 ~]# kubectl get node
NAME        STATUS   ROLES                       AGE   VERSION
k8s-node1   Ready    control-plane,etcd,master   41m   v1.33.8+rke2r1
k8s-node2   Ready    <none>                      13m   v1.33.8+rke2r1

[root@k8s-node1 ~]# rke2 --version
rke2 version v1.33.8+rke2r1 (eb75e3c1774cee5a584259d6fee77eb8cfa9b430)
go version go1.24.12 X:boringcrypto

[root@k8s-node1 ~]# curl -s https://update.rke2.io/v1-release/channels | jq .data

{
  "id": "v1.34",
  "type": "channel",
  "links": {
    "self": "https://update.rke2.io/v1-release/channels/v1.34"
  },
  "name": "v1.34",
  "latest": "v1.34.4+rke2r1",
  "latestRegexp": "v1\\.34\\..*",
  "excludeRegexp": "^[^+]+-"
}

[root@k8s-node1 ~]# curl -sfL https://get.rke2.io | INSTALL_RKE2_CHANNEL=v1.34 sh -
[INFO]  using stable RPM repositories
[INFO]  using 1.34 series from channel stable
Importing GPG key 0xE257814A:
Userid     : "Rancher (CI) <ci@rancher.com>"
Fingerprint: C8CF F216 4551 26E9 B9C9 18BE 925E A29A E257 814A
From       : https://rpm.rancher.io/public.key
Error: Failed to download metadata for repo 'rancher-rke2-1.34-stable': repomd.xml GPG signature verification error: Bad GPG signature

[root@k8s-node1 ~]# rke2 --version
rke2 version v1.34.4+rke2r1 (c6b97dc03cefec17e8454a6f45b29f4e3d0a81d6)
go version go1.24.12 X:boringcrypto

[root@k8s-node1 ~]# kubectl get pod -n kube-system --sort-by=.metadata.creationTimestamp | tac
helm-install-rke2-canal-db69m                0/1     Completed          0              26s
helm-install-rke2-coredns-6bgr5              0/1     Completed          0              26s
helm-install-rke2-metrics-server-km25q       1/1     Running            0              26s
helm-install-rke2-runtimeclasses-qcq8j       1/1     Running            0              26s
kube-proxy-k8s-node1                         1/1     Running            0              42s
kube-controller-manager-k8s-node1            1/1     Running            0              44s
kube-scheduler-k8s-node1                     1/1     Running            0              45s
etcd-k8s-node1                               1/1     Running            0              49s
kube-apiserver-k8s-node1                     1/1     Running            0              79s
rke2-canal-jfzmt                             1/2     CrashLoopBackOff   8 (23s ago)    17m
kube-proxy-k8s-node2                         1/1     Running            0              17m
rke2-metrics-server-fdcdf575d-6tb9x          1/1     Running            0              41m
rke2-canal-vwnxr                             1/2     CrashLoopBackOff   17 (19s ago)   42m
rke2-coredns-rke2-coredns-559595db99-sgwf7   1/1     Running            0              42m

[root@k8s-node1 ~]# kubectl get node -owide
NAME        STATUS   ROLES                       AGE   VERSION          INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                      KERNEL-VERSION                 CONTAINER-RUNTIME
k8s-node1   Ready    control-plane,etcd,master   45m   v1.34.4+rke2r1   192.168.10.11   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
k8s-node2   Ready    <none>                      18m   v1.33.8+rke2r1   192.168.10.12   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1

[rke2 agent] 워커 노드 업그레이드

  [root@k8s-node2 agent]# rke2 --version
  rke2 version v1.33.8+rke2r1 (eb75e3c1774cee5a584259d6fee77eb8cfa9b430)
  go version go1.24.12 X:boringcrypto

  [root@k8s-node2 agent]# curl -sfL https://get.rke2.io | INSTALL_RKE2_TYPE=agent INSTALL_RKE2_CHANNEL=v1.34 sh -
  shell-init: error retrieving current directory: getcwd: cannot access parent directories: No such file or directory
  [INFO]  using stable RPM repositories
  [INFO]  using 1.34 series from channel stable
  Importing GPG key 0xE257814A:
   Userid     : "Rancher (CI) <ci@rancher.com>"
   Fingerprint: C8CF F216 4551 26E9 B9C9 18BE 925E A29A E257 814A
   From       : https://rpm.rancher.io/public.key
  Error: Failed to download metadata for repo 'rancher-rke2-1.34-stable': repomd.xml GPG signature verification error: Bad GPG signature
  Importing GPG key 0xE257814A:

  [root@k8s-node2 agent]# rke2 --version
  rke2 version v1.34.4+rke2r1 (c6b97dc03cefec17e8454a6f45b29f4e3d0a81d6)
  go version go1.24.12 X:boringcrypto
  [root@k8s-node2 agent]# dnf repolist
  repo id                                                              repo name
  appstream                                                            Rocky Linux 9 - AppStream
  baseos                                                               Rocky Linux 9 - BaseOS
  extras                                                               Rocky Linux 9 - Extras
  rancher-rke2-1.34-stable                                             Rancher RKE2 1.34 (v1.34)
  rancher-rke2-common-stable                                           Rancher RKE2 Common (v1.34)
  [root@k8s-node2 agent]# systemctl restart rke2-agent

서버노드 확인

  [root@k8s-node1 ~]# kubectl get node -owide
  NAME        STATUS   ROLES                       AGE   VERSION          INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                      KERNEL-VERSION                 CONTAINER-RUNTIME
  k8s-node1   Ready    control-plane,etcd,master   47m   v1.34.4+rke2r1   192.168.10.11   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
  k8s-node2   Ready    <none>                      20m   v1.34.4+rke2r1   192.168.10.12   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1

  [root@k8s-node1 ~]# kubectl get pod -n kube-system --sort-by=.metadata.creationTimestamp | tac
  kube-proxy-k8s-node2                         1/1     Running            0              33s
  kube-proxy-k8s-node1                         1/1     Running            0              2m38s
  helm-install-rke2-canal-db69m                0/1     Completed          0              3m45s
  helm-install-rke2-coredns-6bgr5              0/1     Completed          0              3m45s
  helm-install-rke2-metrics-server-km25q       1/1     Running            2 (97s ago)    3m45s
  helm-install-rke2-runtimeclasses-qcq8j       1/1     Running            2 (97s ago)    3m45s
  kube-controller-manager-k8s-node1            1/1     Running            0              4m3s
  kube-scheduler-k8s-node1                     1/1     Running            0              4m4s
  etcd-k8s-node1                               1/1     Running            0              4m8s
  kube-apiserver-k8s-node1                     1/1     Running            0              4m38s
  rke2-canal-jfzmt                             1/2     Error              11 (31s ago)   20m
  rke2-metrics-server-fdcdf575d-6tb9x          1/1     Running            0              44m
  rke2-canal-vwnxr                             1/2     CrashLoopBackOff   22 (76s ago)   45m
  rke2-coredns-rke2-coredns-559595db99-sgwf7   1/1     Running            0              45m
  NAME                                         READY   STATUS             RESTARTS       AGE

자동업그레이드 소개
- Rancher의 System Upgrade Controller를 사용하여 RKE2 클러스터 업그레이드를 관리할 수 있음
- Kubernetes 네이티브 방식으로 동작하는 업그레이드 구조임
- Plan 사용자 정의 리소스(CRD)를 통해 선언적으로 업그레이드를 정의함
- Plan에서 다음 항목을 지정할 수 있음
  - 업그레이드할 노드
  - 적용할 RKE2 버전
  - 업그레이드 정책 및 요구사항
- Label Selector를 사용하여 업그레이드 대상 노드를 지정함
  - 특정 역할(control-plane, worker) 기준 선택 가능
  - 특정 환경(dev, prod) 기준 선택 가능
  - 특정 노드 그룹 기준 선택 가능
- 컨트롤러는 Plan 리소스를 지속적으로 모니터링함
- 조건에 맞는 노드를 자동으로 선택함
- 선택된 노드에 Kubernetes Job을 생성하여 업그레이드를 수행함
- Job 기반으로 업그레이드 일정과 실행을 관리함
- 업그레이드 Job이 성공적으로 완료되면
- 해당 노드에 완료 상태를 나타내는 레이블을 자동으로 추가함
- 이를 통해 중복 업그레이드를 방지하고 상태 추적이 가능함

자동업그레이드 수행(v1.34→v1.35)

system-upgrade-controller 설치

[root@k8s-node1 ~]# kubectl apply -f https://github.com/rancher/system-upgrade-controller/releases/latest/download/crd.yaml -f https://github.com/rancher/system-upgrade-controller/releases/latest/download/system-upgrade-controller.yaml
customresourcedefinition.apiextensions.k8s.io/plans.upgrade.cattle.io created
namespace/system-upgrade created
serviceaccount/system-upgrade created
role.rbac.authorization.k8s.io/system-upgrade-controller created
clusterrole.rbac.authorization.k8s.io/system-upgrade-controller created
clusterrole.rbac.authorization.k8s.io/system-upgrade-controller-drainer created
rolebinding.rbac.authorization.k8s.io/system-upgrade created
clusterrolebinding.rbac.authorization.k8s.io/system-upgrade created
clusterrolebinding.rbac.authorization.k8s.io/system-upgrade-drainer created
configmap/default-controller-env created
deployment.apps/system-upgrade-controller created

[root@k8s-node1 ~]# kubectl get deploy,pod,cm -n system-upgrade
\NAME                                        READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/system-upgrade-controller   1/1     1            1           21s

NAME                                             READY   STATUS    RESTARTS   AGE
pod/system-upgrade-controller-6f9f9b8cf4-lwxwr   1/1     Running   0          21s

NAME                               DATA   AGE
configmap/default-controller-env   10     21s
configmap/kube-root-ca.crt         1      22s

[root@k8s-node1 ~]# kubectl get crd | grep upgrade
plans.upgrade.cattle.io                                 2026-02-18T06:12:32Z
[root@k8s-node1 ~]# kubectl logs -n system-upgrade -l app.kubernetes.io/name=system-upgrade-controller -f
W0218 06:12:38.134112       1 client_config.go:667] Neither --kubeconfig nor --master was specified.  Using the inClusterConfig.  This might not work.
time="2026-02-18T06:12:38Z" level=info msg="Updating embedded CRD plans.upgrade.cattle.io"
I0218 06:12:39.607690       1 leaderelection.go:257] attempting to acquire leader lease system-upgrade/system-upgrade-controller...
I0218 06:12:39.607884       1 event.go:389] "Event occurred" object="k8s-node1" fieldPath="" kind="Node" apiVersion="" type="Normal" reason="Starting" message="system-upgrade-controller v0.18.0 (8271c14) starting leader election for system-upgrade/system-upgrade-controller"
I0218 06:12:39.625094       1 leaderelection.go:271] successfully acquired lease system-upgrade/system-upgrade-controller
time="2026-02-18T06:12:39Z" level=info msg="Starting /v1, Kind=Node controller"
time="2026-02-18T06:12:39Z" level=info msg="Starting /v1, Kind=Secret controller"
time="2026-02-18T06:12:39Z" level=info msg="Starting batch/v1, Kind=Job controller"
time="2026-02-18T06:12:39Z" level=info msg="Starting upgrade.cattle.io/v1, Kind=Plan controller"
I0218 06:12:39.743665       1 event.go:389] "Event occurred" object="k8s-node1" fieldPath="" kind="Node" apiVersion="" type="Normal" reason="Started" message="system-upgrade-controller v0.18.0 (8271c14) running as system-upgrade/system-upgrade-controller"

계획 작성 후 실행 및 확인

  #계획작성시에, latest정상구동안되어 버젼직접지정하여 진행
    serviceAccountName: system-upgrade
    upgrade:
      image: rancher/rke2-upgrade
    version: **v1.35.1+rke2r1**

    [root@k8s-node1 ~]# kubectl get node -owide
    NAME        STATUS   ROLES                       AGE   VERSION          INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                      KERNEL-VERSION                 CONTAINER-RUNTIME
    k8s-node1   Ready    control-plane,etcd,master   54m   v1.34.4+rke2r1   192.168.10.11   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
    k8s-node2   Ready    <none>                      27m   v1.34.4+rke2r1   192.168.10.12   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1

    [root@k8s-node1 ~]# kubectl get node -owide
    NAME        STATUS   ROLES                       AGE   VERSION          INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                      KERNEL-VERSION                 CONTAINER-RUNTIME
    k8s-node1   Ready    control-plane,etcd,master   70m   v1.35.1+rke2r1   192.168.10.11   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
    k8s-node2   Ready    <none>                      43m   v1.35.1+rke2r1   192.168.10.12   <none>        Rocky Linux 9.6 (Blue Onyx)   5.14.0-570.52.1.el9_6.x86_64   containerd://2.1.5-k3s1
    ```

Cluster API 실습

kind k8s에 관리용 클러스터 설치

  (⎈|kind-myk8s:default) zosys@4:~$ mkdir capi-docker
  (⎈|kind-myk8s:default) zosys@4:~$ cd capi-docker/
  (⎈|kind-myk8s:default) zosys@4:~/capi-docker$

  (⎈|N/A:N/A) zosys@4:~/capi-docker$ kind create cluster --name myk8s --image kindest/node:v1.35.0 --config - <<EOF
  kind: Cluster
  apiVersion: kind.x-k8s.io/v1alpha4
  nodes:
  - role: control-plane
    extraMounts:
    - hostPath: /Users/gasida/.orbstack/run/docker.sock  # 대분분 이 값 사용: /var/run/docker.sock
      containerPath: /var/run/docker.sock
    extraPortMappings:
    - containerPort: 30000     # sample
      hostPort: 30000
    - containerPort: 30001     # kube-ops-view
      hostPort: 30001
  EOF
  Creating cluster "myk8s" ...

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ curl -L https://github.com/kubernetes-sigs/cluster-api/releases/download/v1.12.2/clusterctl-linux-amd64 -o clusterctl
    % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                   Dload  Upload   Total   Spent    Left  Speed
    0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0
  100 68.2M  100 68.2M    0     0  7307k      0  0:00:09  0:00:09 --:--:-- 10.5M
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ sudo install -o root -g root -m 0755 clusterctl /usr/local/bin/clusterctl

  [sudo] password for zosys:
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ clusterctl version -o json | jq
  {
    "clusterctl": {
      "major": "1",
      "minor": "12",
      "gitVersion": "v1.12.2",
      "gitCommit": "9ee80d1ff529c48ae0b8e022ec01d70ac496e8e5",
      "gitTreeState": "clean",
      "buildDate": "2026-01-20T16:48:19Z",
      "goVersion": "go1.24.12",
      "compiler": "gc",
      "platform": "linux/amd64"
    }
  }

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get crd | grep x-k8s
  clusterclasses.cluster.x-k8s.io                              2026-02-18T06:49:12Z
  clusterresourcesetbindings.addons.cluster.x-k8s.io           2026-02-18T06:49:12Z
  clusterresourcesets.addons.cluster.x-k8s.io                  2026-02-18T06:49:12Z
  clusters.cluster.x-k8s.io                                    2026-02-18T06:49:12Z
  devclusters.infrastructure.cluster.x-k8s.io                  2026-02-18T06:49:14Z

관리용 매니지먼트 K8S 클러스터 정보 확인

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl describe -n capi-system deployment.apps/capi-controller-manager | grep feature-gates
        --feature-gates=MachinePool=true,ClusterTopology=true,RuntimeSDK=false,MachineSetPreflightChecks=true,MachineWaitForVolumeDetachConsiderVolumeAttachments=true,PriorityQueue=false,ReconcilerRateLimiting=false,InPlaceUpdates=false,MachineTaintPropagation=false
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get providers.clusterctl.cluster.x-k8s.io -A
  NAMESPACE                           NAME                    AGE     TYPE                     PROVIDER      VERSION
  capd-system                         infrastructure-docker   2m17s   InfrastructureProvider   docker        v1.12.3
  capi-kubeadm-bootstrap-system       bootstrap-kubeadm       2m18s   BootstrapProvider        kubeadm       v1.12.3
  capi-kubeadm-control-plane-system   control-plane-kubeadm   2m18s   ControlPlaneProvider     kubeadm       v1.12.3
  capi-system                         cluster-api             2m19s   CoreProvider             cluster-api   v1.12.3
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get providers -n capi-system cluster-api -o yaml
  apiVersion: clusterctl.cluster.x-k8s.io/v1alpha3
  kind: Provider
  metadata:
    creationTimestamp: "2026-02-18T06:49:13Z"
    generation: 1
    labels:
      cluster.x-k8s.io/provider: cluster-api
      clusterctl.cluster.x-k8s.io: ""
      clusterctl.cluster.x-k8s.io/core: inventory
    name: cluster-api
    namespace: capi-system
    resourceVersion: "1037"
    uid: 1a5dacb5-8700-46e3-a5d7-344a17bcdc9a
  providerName: cluster-api
  type: CoreProvider
  version: v1.12.3

cert-manager 확인

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get crd | grep cert
  certificaterequests.cert-manager.io                          2026-02-18T06:48:49Z
  certificates.cert-manager.io                                 2026-02-18T06:48:49Z
  challenges.acme.cert-manager.io                              2026-02-18T06:48:49Z
  clusterissuers.cert-manager.io                               2026-02-18T06:48:49Z
  issuers.cert-manager.io                                      2026-02-18T06:48:49Z
  orders.acme.cert-manager.io                                  2026-02-18T06:48:49Z
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get deploy,pod,svc,ep,cm,secret,sa -n cert-manager
  Warning: v1 Endpoints is deprecated in v1.33+; use discovery.k8s.io/v1 EndpointSlice
  NAME                                      READY   UP-TO-DATE   AVAILABLE   AGE
  deployment.apps/cert-manager              1/1     1            1           3m36s
  deployment.apps/cert-manager-cainjector   1/1     1            1           3m36s
  deployment.apps/cert-manager-webhook      1/1     1            1           3m36s

  NAME                                           READY   STATUS    RESTARTS   AGE
  pod/cert-manager-598d877b78-d2m7f              1/1     Running   0          3m36s
  pod/cert-manager-cainjector-6b5777d564-pxjt2   1/1     Running   0          3m36s
  pod/cert-manager-webhook-5d9fc6b4ff-q2tzg      1/1     Running   0          3m36s

  NAME                              TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)            AGE
  service/cert-manager              ClusterIP   10.96.105.201   <none>        9402/TCP           3m37s
  service/cert-manager-cainjector   ClusterIP   10.96.22.45     <none>        9402/TCP           3m37s
  service/cert-manager-webhook      ClusterIP   10.96.245.210   <none>        443/TCP,9402/TCP   3m37s

  NAME                                ENDPOINTS                          AGE
  endpoints/cert-manager              10.244.0.7:9402                    3m37s
  endpoints/cert-manager-cainjector   10.244.0.6:9402                    3m37s
  endpoints/cert-manager-webhook      10.244.0.8:10250,10.244.0.8:9402   3m37s

  NAME                         DATA   AGE
  configmap/kube-root-ca.crt   1      3m38s

  NAME                             TYPE     DATA   AGE
  secret/cert-manager-webhook-ca   Opaque   3      3m22s

  NAME                                     AGE
  serviceaccount/cert-manager              3m38s
  serviceaccount/cert-manager-cainjector   3m38s
  serviceaccount/cert-manager-webhook      3m38s
  serviceaccount/default                   3m38s
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get issuers.cert-manager.io -A
  NAMESPACE                           NAME                                           READY   AGE
  capd-system                         capd-selfsigned-issuer                         True    3m17s
  capi-kubeadm-bootstrap-system       capi-kubeadm-bootstrap-selfsigned-issuer       True    3m18s
  capi-kubeadm-control-plane-system   capi-kubeadm-control-plane-selfsigned-issuer   True    3m17s
  capi-system                         capi-selfsigned-issuer                         True    3m19s
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get certificaterequests.cert-manager.io -A -owide
  NAMESPACE                           NAME                                        APPROVED   DENIED   READY   ISSUER                                         REQUESTER                                         STATUS                                         AGE
  capd-system                         capd-serving-cert-1                         True                True    capd-selfsigned-issuer                         system:serviceaccount:cert-manager:cert-manager   Certificate fetched from issuer successfully   3m19s
  capi-kubeadm-bootstrap-system       capi-kubeadm-bootstrap-serving-cert-1       True                True    capi-kubeadm-bootstrap-selfsigned-issuer       system:serviceaccount:cert-manager:cert-manager   Certificate fetched from issuer successfully   3m21s
  capi-kubeadm-control-plane-system   capi-kubeadm-control-plane-serving-cert-1   True                True    capi-kubeadm-control-plane-selfsigned-issuer   system:serviceaccount:cert-manager:cert-manager   Certificate fetched from issuer successfully   3m20s
  capi-system                         capi-serving-cert-1                         True                True    capi-selfsigned-issuer                         system:serviceaccount:cert-manager:cert-manager   Certificate fetched from issuer successfully   3m22s
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl get certificates.cert-manager.io -A -owide
  NAMESPACE                           NAME                                      READY   SECRET                                            ISSUER                                         STATUS                                          AGE
  capd-system                         capd-serving-cert                         True    capd-webhook-service-cert                         capd-selfsigned-issuer                         Certificate is up to date and has not expired   3m24s
  capi-kubeadm-bootstrap-system       capi-kubeadm-bootstrap-serving-cert       True    capi-kubeadm-bootstrap-webhook-service-cert       capi-kubeadm-bootstrap-selfsigned-issuer       Certificate is up to date and has not expired   3m25s
  capi-kubeadm-control-plane-system   capi-kubeadm-control-plane-serving-cert   True    capi-kubeadm-control-plane-webhook-service-cert   capi-kubeadm-control-plane-selfsigned-issuer   Certificate is up to date and has not expired   3m24s
  capi-system                         capi-serving-cert                         True    capi-webhook-service-cert                         capi-selfsigned-issuer                         Certificate is up to date and has not expired   3m26s

워크로드 클러스터 생성

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ export SERVICE_CIDR=["10.20.0.0/16"]
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ export POD_CIDR=["10.10.0.0/16"]
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ export SERVICE_DOMAIN="myk8s-1.local"
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ export POD_SECURITY_STANDARD_ENABLED="false"
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ clusterctl generate cluster capi-quickstart --flavor development \
    --kubernetes-version v1.34.3 \
    --control-plane-machine-count=3 \
    --worker-machine-count=3 \
    > capi-quickstart.yaml

  New clusterctl version available: v1.12.2 -> v1.12.3
  sigs.k8s.io/cluster-api
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl apply -f capi-quickstart.yaml
  clusterclass.cluster.x-k8s.io/quick-start created
  dockerclustertemplate.
  infrastructure.cluster.x-k8s.io/quick-start-cluster created
  kubeadmcontrolplanetemplate.controlplane.cluster.x-k8s.io/quick-start-control-plane created
  dockermachinetemplate.infrastructure.cluster.x-k8s.io/quick-start-control-plane created
  dockermachinetemplate.infrastructure.cluster.x-k8s.io/quick-start-default-worker-machinetemplate created
  dockermachinepooltemplate.infrastructure.cluster.x-k8s.io/quick-start-default-worker-machinepooltemplate created
  kubeadmconfigtemplate.bootstrap.cluster.x-k8s.io/quick-start-default-worker-bootstraptemplate created
  cluster.cluster.x-k8s.io/capi-quickstart created

  ##생성 확인 & kubeconfig 자격 증명 & CNI 플러그인 설치 후 확인

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ clusterctl get kubeconfig capi-quickstart > capi-quickstart.kubeconfig
  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ kubectl --kubeconfig=capi-quickstart.kubeconfig apply -f https://raw.githubusercontent.com/projectcalico/calico/v3.27.0/manifests/calico.yaml

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ docker ps
  CONTAINER ID   IMAGE                  COMMAND                  CREATED          STATUS          PORTS                                                             NAMES
  01fa53373460   kindest/node:v1.35.0   "/usr/local/bin/entr…"   21 minutes ago   Up 21 minutes   0.0.0.0:30000-30001->30000-30001/tcp, 127.0.0.1:38469->6443/tcp   myk8s-control-plane
  098bc8adc657   kindest/node:v1.35.0   "/usr/local/bin/entr…"   3 minutes ago    Up 3 minutes                                                                      capi-quickstart-md-0-67fkn-9ajzs-lcjv4
  4f137h6yy154   kindest/node:v1.35.0   "/usr/local/bin/entr…"

  (⎈|kind-myk8s:N/A) zosys@4:~/capi-docker$ clusterctl describe cluster capi-quickstart
  NAME                                                           REPLICAS AVAILABLE READY UP TO DATE STATUS REASON        SINCE MESSAGE
  Cluster/capi-quickstart                                        6/6      6         6     0          True Available

워크로드 LB확인

  (⎈|kind-myk8s:N/A) zosys@4:~$ docker ps
  CONTAINER ID   IMAGE                                COMMAND                  CREATED             STATUS             PORTS                                                             NAMES
  a8f3c1d9b2e7   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour   127.0.0.1:32775->6443/tcp                                         capi-quickstart-j9fdm-6zg8v
  b7e2d4a1c9f3   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour   127.0.0.1:32774->6443/tcp                                         capi-quickstart-j9fdm-27w2s
  c3d9e7f1a2b6   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour                                                                     capi-quickstart-md-0-p7lv8-t7r9t-nhfpb
  d4a1b8c7e2f9   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour                                                                     capi-quickstart-md-0-p7lv8-t7r9t-rmcls
  e9f2a7b4c1d8   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour                                                                     capi-quickstart-md-0-p7lv8-t7r9t-t5ds2
  f1a2b3c4d5e6   kindest/node:v1.34.3                 "/usr/local/bin/entr…"   About an hour ago   Up About an hour   127.0.0.1:32773->6443/tcp                                         capi-quickstart-j9fdm-ggm9z
  9c8b7a6d5e4f   kindest/haproxy:v20230606-42a2262b   "haproxy -W -db -f /…"   About an hour ago   Up About an hour   0.0.0.0:32770->6443/tcp, 0.0.0.0:32771->8404/tcp                  capi-quickstart-lb
  7e6d5c4b3a2f   kindest/node:v1.35.0                 "/usr/local/bin/entr…"   2 hours ago         Up 2 hours         0.0.0.0:30000-30001->30000-30001/tcp, 127.0.0.1:54601->6443/tcp   myk8s-control-plane

  (⎈|kind-myk8s:N/A) zosys@4:~$ docker inspect capi-quickstart-lb | jq
  ...
  "Entrypoint": [
    "haproxy",
    "-W",
    "-db",
    "-f",
    "/usr/local/etc/haproxy/haproxy.cfg"

  (⎈|kind-myk8s:N/A) zosys@4:~$ curl -sk https://127.0.0.1:32770/version | jq
  {
    "major": "1",
    "minor": "34"
  }

  (⎈|kind-myk8s:N/A) zosys@4:~$ cat haproxy.cfg
  global
    log /dev/log local0
    log /dev/log local1 notice
    daemon
    maxconn 100000

  resolvers docker
    nameserver dns 127.0.0.11:53

  defaults
    log global
    mode tcp
    option dontlognull
    timeout connect 5000
    timeout client 50000
    timeout server 50000
    default-server init-addr none

  frontend stats
    mode http
    bind *:8404
    stats enable
    stats uri /stats
    stats refresh 1s
    stats admin if TRUE

  frontend control-plane
    bind *:6443
    default_backend kube-apiservers

  #############################################

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 6주차 과제 (1)	2026.02.13
K8S ) 5주차 과제 (0)	2026.02.06
K8S) 4주차 과제 (0)	2026.01.31
K8S)3주차 과제 (0)	2026.01.24
K8S)2주차 과제 (0)	2026.01.15

K8S ) 6주차 과제

zosys 2026. 2. 13. 23:51

2026. 2. 13. 23:51

Kubespray offline 설치

폐쇄망환경에서 정상적인 서비스 제공을 위한 주요 구성 요소

NTP 서버 : Kubernetes는 인증서(TLS), etcd, 로그, 토큰 만료 시간 등에서 시간 동기화가 매우 중요하기 때문에 모든 노드 간 동일한 시간 유지가 필수
DNS 서버 : Kubernetes 노드 간 통신과 내부 서비스 접근은 FQDN 기반으로 동작하는 경우가 많기 때문에 안정적인 내부 이름 해석 환경이 필요
Network Gateway (IGW/NATGW) : 완전 폐쇄망이 아닌 경우 외부 리소스 접근 또는 DMZ 구간과의 통신을 위해 네트워크 경계 및 트래픽 제어 구성이 필요
Local (Mirror) YUM/DNF Repository : Kubespray 설치 과정에서 필요한 OS 패키지(container runtime, iptables, socat 등)를 외부 인터넷 없이 설치하기 위해 내부 패키지 저장소가 필요
Private Container Image Registry : Kubernetes 구성요소(kube-apiserver, etcd, coredns, CNI 등)와 애플리케이션 이미지를 폐쇄망 환경에서 Pull 하기 위해 내부 컨테이너 이미지 저장소가 필요
Helm Artifact Repository : Kubernetes 배포 이후 Helm 기반 애플리케이션(ingress, monitoring, logging 등)을 외부 Helm 저장소 없이 배포하기 위해 내부 Helm 차트 저장소가 필요
Private PyPI Mirror : Kubespray(Ansible 기반) 및 Python 애플리케이션의 의존 패키지를 폐쇄망 환경에서 설치하기 위해 내부 Python 패키지 저장소가 필요
Private Go Module Proxy : Go 기반 애플리케이션 및 Kubernetes 확장 개발 시 외부 Go 모듈 의존성을 내부에서 관리하기 위해 사설 Go 모듈 프록시가 필요

graph TB
    subgraph InternalServices["내부망 내 필요한 서비스"]
        NTP["⏱️ NTP Server"]
        DNS["🌐 DNS Server"]
        GW["🛜 Network Gateway<br/>(IGW, NATGW)"]
        YUM["📦 Local (Mirror) YUM/DNF Repository"]
        REG["🐳 Private Container (Image) Registry"]
        HELM["🧭 Helm Artifact Repository"]
        PYPI["🐍 Private PyPI Mirror"]
    end

폐쇄망 실습환경구성

NAT GATEWAY

설정 확인

실습내에 enp0s8 ⇒ 실인터페이스 : enp0s3 enp0s9⇒실인터페이스enp0s8

  root@admin:~# cat /etc/NetworkManager/system-connections/enp0s3.nmconnection
  [connection]
  id=enp0s3
  uuid=74d64498-c95a-435b-9340-81b2e4a7d1f2
  type=ethernet
  interface-name=enp0s3

  [ethernet]

  [ipv4]
  method=auto

  [ipv6]
  addr-gen-mode=eui64
  method=ignore

  [proxy]
  root@admin:~# cat /etc/NetworkManager/system-connections/enp0s8.nmconnection
  [connection]
  id=enp0s8
  uuid=60dff4a4-af47-4907-84b1-dc4b1e9a129a
  type=ethernet
  autoconnect-priority=-100
  autoconnect-retries=1
  interface-name=enp0s8

  [ethernet]
  mac-address=08:00:27:6d:47:bb

  [ipv4]
  method=manual
  addresses=192.168.10.10/24
  gateway=192.168.10.1

  [user]
  org.freedesktop.NetworkManager.origin=vagrant

네트워크 기본 설정 : enp0s3 연결 down, enp0s8 디폴트 라우팅

  root@k8s-node1:~# nmcli connection down enp0s3
  Connection 'enp0s3' successfully deactivated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/2)
  root@k8s-node1:~# nmcli connection modify enp0s3 connection.autoconnect no
  root@k8s-node1:~# nmcli connection modify enp0s8 +ipv4.routes "0.0.0.0/0 192.168.10.10 200"
  root@k8s-node1:~# nmcli connection up enp0s8
  Connection successfully activated (D-Bus active path: /org/freedesktop/NetworkManager/ActiveConnection/5)
  root@k8s-node1:~# ip route
  default via 192.168.10.1 dev enp0s8 proto static metric 100
  default via 192.168.10.10 dev enp0s8 proto static metric 200
  192.168.10.0/24 dev enp0s8 proto kernel scope link src 192.168.10.11 metric 100

  root@k8s-node1:~# ping -w 1 -W 1 8.8.8.8
  PING 8.8.8.8 (8.8.8.8) 56(84) bytes of data.
  ^C
  --- 8.8.8.8 ping statistics ---
  1 packets transmitted, 0 received, 100% packet loss, time 0ms

  root@k8s-node1:~# curl www.google.com
  curl: (6) Could not resolve host: www.google.com
  root@k8s-node1:~# cat /etc/resolv.conf
  # Generated by NetworkManager
  root@k8s-node1:~# cat << EOF > /etc/resolv.conf
  nameserver 168.126.63.1
  nameserver 8.8.8.8
  EOF
  root@k8s-node1:~# curl www.google.com

NTP 설정

[admin]NTP 서버설정

  root@admin:~# systemctl status chronyd.service --no-pager
  ● chronyd.service - NTP client/server
       Loaded: loaded (/usr/lib/systemd/system/chronyd.service; enabled; preset: enabled)
       Active: active (running) since Fri 2026-02-13 21:33:01 KST; 14min ago
   Invocation: d599d3cbe51f4af0b3582d164c7e7afd
         Docs: man:chronyd(8)
               man:chrony.conf(5)
     Main PID: 753 (chronyd)
        Tasks: 1 (limit: 12339)
       Memory: 4.8M (peak: 5.5M)
          CPU: 110ms
       CGroup: /system.slice/chronyd.service
               └─753 /usr/sbin/chronyd -F 2

  Feb 13 21:33:23 admin chronyd[753]: Source 2001:678:8::123 offline
  Feb 13 21:33:23 admin chronyd[753]: Source 240b:400d:3:3300:aeda:71da:9779:d8f1 offline
  Feb 13 21:33:23 admin chronyd[753]: Source 240b:400d:3:3300:aeda:71da:9779:d4f1 offline
  Feb 13 21:33:23 admin chronyd[753]: Source 2401:c080:1c00:24a1:5400:5ff:fe04:720 offline
  Feb 13 21:33:26 admin chronyd[753]: Source 2001:678:8::123 online
  Feb 13 21:33:26 admin chronyd[753]: Source 240b:400d:3:3300:aeda:71da:9779:d8f1 online
  Feb 13 21:33:26 admin chronyd[753]: Source 240b:400d:3:3300:aeda:71da:9779:d4f1 online
  Feb 13 21:33:26 admin chronyd[753]: Source 2401:c080:1c00:24a1:5400:5ff:fe04:720 online
  Feb 13 21:34:17 admin chronyd[753]: Selected source 175.195.167.194 (2.rocky.pool.ntp.org)
  Feb 13 21:34:54 admin chronyd[753]: Selected source 221.151.118.78 (2.rocky.pool.ntp.org)
  root@admin:~# grep "^[^#]" /etc/chrony.conf
  pool 2.rocky.pool.ntp.org iburst
  sourcedir /run/chrony-dhcp
  driftfile /var/lib/chrony/drift
  makestep 1.0 3
  rtcsync
  ntsdumpdir /var/lib/chrony
  logdir /var/log/chrony
  root@admin:~# chronyc sources -v

    .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
   / .- Source state '*' = current best, '+' = combined, '-' = not combined,
  | /             'x' = may be in error, '~' = too variable, '?' = unusable.
  ||                                                 .- xxxx [ yyyy ] +/- zzzz
  ||      Reachability register (octal) -.           |  xxxx = adjusted offset,
  ||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
  ||                                \     |          |  zzzz = estimated error.
  ||                                 |    |           \
  MS Name/IP address         Stratum Poll Reach LastRx Last sample
  ===============================================================================
  ^- 175.210.18.47                 2   6   377     7   -562us[ -562us] +/-   17ms
  ^- mail.innotab.com              3   6   377     8  -1275us[-1275us] +/-   38ms
  ^* time.ravnus.com               2   6   377    33    -73us[+1359ns] +/- 2687us
  ^+ ec2-3-39-176-65.ap-north>     2   6   377     7   +157us[ +157us] +/- 5593us
  root@admin:~# dig +short 2.rocky.pool.ntp.org
  175.195.167.194
  158.247.202.103
  221.151.118.78
  root@admin:~# cp /etc/chrony.conf /etc/chrony.bak
  root@admin:~# cat << EOF > /etc/chrony.conf
  # 외부 한국 공용 NTP 서버 설정
  server pool.ntp.org iburst
  server kr.pool.ntp.org iburst

  # 내부망(192.168.10.0/24)에서 이 서버에 접속하여 시간 동기화 허용
  allow 192.168.10.0/24

  # 외부망이 끊겼을 때도 로컬 시계를 기준으로 내부망에 시간 제공 (선택 사항)
  local stratum 10

  # 로그
  logdir /var/log/chrony
  EOF
  root@admin:~# systemctl restart chronyd.service
  root@admin:~# systemctl status chronyd.service --no-pager
  ● chronyd.service - NTP client/server
       Loaded: loaded (/usr/lib/systemd/system/chronyd.service; enabled; preset: enabled)
       Active: active (running) since Fri 2026-02-13 21:47:46 KST; 3s ago
   Invocation: ed143eef1e0145ba87bd062f11301cad
         Docs: man:chronyd(8)
               man:chrony.conf(5)
      Process: 5758 ExecStart=/usr/sbin/chronyd $OPTIONS (code=exited, status=0/SUCCESS)
     Main PID: 5760 (chronyd)
        Tasks: 1 (limit: 12339)
       Memory: 1.1M (peak: 2.9M)
          CPU: 34ms
       CGroup: /system.slice/chronyd.service
               └─5760 /usr/sbin/chronyd -F 2

  Feb 13 21:47:46 admin systemd[1]: Starting chronyd.service - NTP client/server...
  Feb 13 21:47:46 admin chronyd[5760]: chronyd version 4.6.1 starting (+CMDMON +NTP +REFCLOCK +RTC +PRIVDROP +SCF… +DEBUG)
  Feb 13 21:47:46 admin chronyd[5760]: Initial frequency -541.138 ppm
  Feb 13 21:47:46 admin chronyd[5760]: Loaded seccomp filter (level 2)
  Feb 13 21:47:46 admin systemd[1]: Started chronyd.service - NTP client/server.
  Hint: Some lines were ellipsized, use -l to show in full.
  root@admin:~# timedatectl status
                 Local time: Fri 2026-02-13 21:47:52 KST
             Universal time: Fri 2026-02-13 12:47:52 UTC
                   RTC time: Fri 2026-02-13 12:47:51
                  Time zone: Asia/Seoul (KST, +0900)
  System clock synchronized: yes
                NTP service: active
            RTC in local TZ: no
  root@admin:~# chronyc sources -v

    .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
   / .- Source state '*' = current best, '+' = combined, '-' = not combined,
  | /             'x' = may be in error, '~' = too variable, '?' = unusable.
  ||                                                 .- xxxx [ yyyy ] +/- zzzz
  ||      Reachability register (octal) -.           |  xxxx = adjusted offset,
  ||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
  ||                                \     |          |  zzzz = estimated error.
  ||                                 |    |           \
  MS Name/IP address         Stratum Poll Reach LastRx Last sample
  ===============================================================================
  ^- 121.134.215.104               2   6    17     3    -94us[  -94us] +/- 2838us
  ^* 211.108.117.211               2   6    17     4    -11us[+1053us] +/- 2114us

[k8snode] ntp client 설정

  root@k8s-node1:~# timedatectl status
                 Local time: Fri 2026-02-13 21:50:15 KST
             Universal time: Fri 2026-02-13 12:50:15 UTC
                   RTC time: Fri 2026-02-13 12:50:15
                  Time zone: Asia/Seoul (KST, +0900)
  System clock synchronized: yes
                NTP service: active
            RTC in local TZ: no
  root@k8s-node1:~# chronyc sources -v

    .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
   / .- Source state '*' = current best, '+' = combined, '-' = not combined,
  | /             'x' = may be in error, '~' = too variable, '?' = unusable.
  ||                                                 .- xxxx [ yyyy ] +/- zzzz
  ||      Reachability register (octal) -.           |  xxxx = adjusted offset,
  ||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
  ||                                \     |          |  zzzz = estimated error.
  ||                                 |    |           \
  MS Name/IP address         Stratum Poll Reach LastRx Last sample
  ===============================================================================
  ^- 121.174.142.82                3   7   360   444   +988us[ +988us] +/-   43ms
  ^- 175.195.167.194               3   7    34   509   -309us[ -360us] +/-   35ms
  ^- 121.174.142.81                3   7   340   484   -132us[ -132us] +/-   43ms
  ^* 211.108.117.211               2   6   300   504   -264us[ -316us] +/- 2203us
  root@k8s-node1:~#
  root@k8s-node1:~#
  root@k8s-node1:~# cp /etc/chrony.conf /etc/chrony.bak
  root@k8s-node1:~# cat << EOF > /etc/chrony.conf
  server 192.168.10.10 iburst
  logdir /var/log/chrony
  EOF
  root@k8s-node1:~# systemctl restart chronyd.service
  root@k8s-node1:~# systemctl status chronyd.service --no-pager
  ● chronyd.service - NTP client/server
       Loaded: loaded (/usr/lib/systemd/system/chronyd.service; enabled; preset: enabled)
       Active: active (running) since Fri 2026-02-13 21:52:50 KST; 1s ago
   Invocation: 41174c2716074722b33c8f5c506d64c5
         Docs: man:chronyd(8)
               man:chrony.conf(5)
      Process: 5662 ExecStart=/usr/sbin/chronyd $OPTIONS (code=exited, status=0/SUCCESS)
     Main PID: 5665 (chronyd)
        Tasks: 1 (limit: 12339)
       Memory: 892K (peak: 2.9M)
          CPU: 30ms
       CGroup: /system.slice/chronyd.service
               └─5665 /usr/sbin/chronyd -F 2

  Feb 13 21:52:50 k8s-node1 systemd[1]: Starting chronyd.service - NTP client/server...
  Feb 13 21:52:50 k8s-node1 chronyd[5665]: chronyd version 4.6.1 starting (+CMDMON +NTP +REFCLOCK +RTC +PRIVDROP … +DEBUG)
  Feb 13 21:52:50 k8s-node1 chronyd[5665]: Initial frequency -540.965 ppm
  Feb 13 21:52:50 k8s-node1 chronyd[5665]: Loaded seccomp filter (level 2)
  Feb 13 21:52:50 k8s-node1 systemd[1]: Started chronyd.service - NTP client/server.
  Hint: Some lines were ellipsized, use -l to show in full.
  root@k8s-node1:~# timedatectl status
                 Local time: Fri 2026-02-13 21:52:55 KST
             Universal time: Fri 2026-02-13 12:52:55 UTC
                   RTC time: Fri 2026-02-13 12:52:54
                  Time zone: Asia/Seoul (KST, +0900)
  System clock synchronized: yes
                NTP service: active
            RTC in local TZ: no
  root@k8s-node1:~# chronyc sources -v

    .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
   / .- Source state '*' = current best, '+' = combined, '-' = not combined,
  | /             'x' = may be in error, '~' = too variable, '?' = unusable.
  ||                                                 .- xxxx [ yyyy ] +/- zzzz
  ||      Reachability register (octal) -.           |  xxxx = adjusted offset,
  ||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
  ||                                \     |          |  zzzz = estimated error.
  ||                                 |    |           \
  MS Name/IP address         Stratum Poll Reach LastRx Last sample
  ===============================================================================
  ^* admin                         3   6    17     1    -64us[-2630ns] +/- 5878us

  ##어드민 상태확인
  root@admin:~# chronyc clients
  Hostname                      NTP   Drop Int IntL Last     Cmd   Drop Int  Last
  ===============================================================================
  k8s-node2                       6      0   5   -     4       0      0   -     -
  k8s-node1                       4      0   1   -     4       0      0   -     -

DNS설정

[admin] DNS 서버(bind) 설정

  root@admin:~# dnf install -y bind bind-utils
  Last metadata expiration check: 0:22:21 ago on Fri 13 Feb 2026 09:33:32 PM KST.
  Package bind-utils-32:9.18.33-4.el10_0.x86_64 is already installed.
  Dependencies resolved.
  ========================================================================================================================
   Package                           Architecture     Version                                   Repository           Size
  ========================================================================================================================
  Installing:
   bind                              x86_64           32:9.18.33-10.el10_1.2                    appstream           333 k
  Upgrading:
   bind-libs                         x86_64           32:9.18.33-10.el10_1.2                    appstream           1.3 M
   bind-license                      noarch           32:9.18.33-10.el10_1.2                    appstream            13 k
   bind-utils                        x86_64           32:9.18.33-10.el10_1.2                    appstream           225 k
   crypto-policies                   noarch           20250905-2.gitc7eb7b2.el10_1.1            baseos               94 k
   crypto-policies-scripts           noarch           20250905-2.gitc7eb7b2.el10_1.1            baseos              134 k
   openssl                           x86_64           1:3.5.1-7.el10_1                          baseos              1.2 M
   openssl-libs                      x86_64           1:3.5.1-7.el10_1                          baseos              2.2 M
  Installing dependencies:
   openssl-fips-provider             x86_64           1:3.5.1-7.el10_1                          baseos              812 k
  Installing weak dependencies:
   bind-dnssec-utils                 x86_64           32:9.18.33-10.el10_1.2                    appstream           151 k

  Transaction Summary
  ========================================================================================================================
  Install  3 Packages

  root@admin:~# named-checkconf /etc/named.conf
  root@admin:~# systemctl enable --now named
  Created symlink '/etc/systemd/system/multi-user.target.wants/named.service' → '/usr/lib/systemd/system/named.service'.
  root@admin:~#
  root@admin:~# echo "nameserver 192.168.10.10" > /etc/resolv.conf
  root@admin:~# dig +short google.com @192.168.10.10
  172.217.213.139
  172.217.213.113
  172.217.213.138
  172.217.213.100
  172.217.213.102
  172.217.213.101

[k8snode] DNS 클라이언트 설정 : NetworkManager DNS 관리 종료

  root@k8s-node1:~# cat /etc/NetworkManager/conf.d/99-dns-none.conf
  cat: /etc/NetworkManager/conf.d/99-dns-none.conf: No such file or directory
  root@k8s-node1:~# cat << EOF > /etc/NetworkManager/conf.d/99-dns-none.conf
  [main]
  dns=none
  EOF
  root@k8s-node1:~# systemctl restart NetworkManager
  root@k8s-node1:~# echo "nameserver 192.168.10.10" > /etc/resolv.conf
  root@k8s-node1:~# dig +short google.com @192.168.10.10
  172.217.213.138
  172.217.213.113
  172.217.213.101
  172.217.213.102
  172.217.213.100
  172.217.213.139

Kubespray Offline 설치소개

Kubespray : Ansible 기반 Kubernetes 배포 도구로, 오프라인(Air-Gap) 환경에서 Kubernetes를 설치할 수 있도록 사전 다운로드·미러링·이미지 관리 편의 기능을 지원

1️⃣ 오프라인 배포 준비 기능

Kubernetes 설치 시 필요한 바이너리 파일 목록 및 컨테이너 이미지 목록 자동 생성
필요한 컨테이너 이미지 사전 다운로드
다운로드한 이미지를 내부 프라이빗 레지스트리에 업로드(등록)
필수 파일(바이너리 등) 다운로드 후 Nginx 컨테이너를 통해 내부 HTTP 파일 서버 제공
외부 인터넷이 수행하는 다운로드 역할을 내부 환경에서 대체하도록 지원

2️⃣ Kubespray Offline 동작 흐름

다운로드 대상 파일 및 이미지 목록 생성
외부망에서 모든 바이너리·이미지 사전 다운로드
내부 Registry 및 Web 서버 구성
내부 노드들은 외부가 아닌 내부 미러/레지스트리에서만 다운로드
Kubernetes 클러스터 배포 수행

기본환경준비

download.sh 수행 및 용량확인

  root@admin:~/kubespray-offline# ./download-all.sh
  ###중략##########
  root@admin:~/kubespray-offline# du -sh ~/.venv
  491M    /root/.venv

  root@admin:~/kubespray-offline# tree ~/.venv | more
  /root/.venv
  └── 3.12
      ├── bin
      │   ├── activate
      │   ├── activate.csh
      │   ├── activate.fish
      │   ├── Activate.ps1
      │   ├── ansible
      │   ├── ansible-community
      │   ├── ansible-config
      │   ├── ansible-connection
      │   ├── ansible-console
      │   ├── ansible-doc
      │   ├── ansible-galaxy
      │   ├── ansible-inventory
      │   ├── ansible-playbook
      │   ├── ansible-pull

  root@admin:~/kubespray-offline# tree /root/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/
  /root/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/
  ├── docker-daemon.json
  ├── generate_list.sh
  ├── generate_list.yml
  ├── manage-offline-container-images.sh
  ├── manage-offline-files.sh
  ├── nginx.conf
  ├── README.md
  ├── registries.conf
  ├── temp
  │   ├── files.list
  │   ├── files.list.template
  │   ├── images.list
  │   └── images.list.template
  └── upload2artifactory.py

  2 directories, 13 files

  root@admin:~/kubespray-offline# du -sh /root/kubespray-offline/outputs/
  3.7G    /root/kubespray-offline/outputs/

[1] outputs 디렉터리 이동 후 setup-container.sh 실행 : 추가로 install-containerd.sh 실행됨

  root@admin:~/kubespray-offline# cd outputs/

  root@admin:~/kubespray-offline/outputs# ./setup-container.sh
  ==> Install runc
  ==> Install nerdctl
  nerdctl
  containerd-rootless-setuptool.sh
  containerd-rootless.sh
  ==> Install containerd
  bin/containerd-stress
  bin/containerd
  bin/ctr
  bin/containerd-shim-runc-v2
  ==> Start containerd
  Created symlink '/etc/systemd/system/multi-user.target.wants/containerd.service' → '/etc/systemd/system/containerd.service'.
  ==> Install CNI plugins
  ./
  ./README.md
  ./static
  ./host-device
  ./ipvlan
  ./dhcp
  ./LICENSE
  ./portmap
  ./tap
  ./host-local
  ./vlan
  ./loopback
  ./sbr
  ./firewall
  ./bandwidth
  ./bridge
  ./vrf
  ./macvlan
  ./tuning
  ./dummy
  ./ptp
  ==> Load registry, nginx images
  unpacking docker.io/library/registry:2.8.1 (sha256:1e6c7d1be0dd576c7e50f786e3333382e209907eba72f5414a91025af241e16d)...
  Loaded image: registry:2.8.1
  unpacking docker.io/library/registry:3.0.0 (sha256:09d6d68c85b98bac6699850ad2c071714e01a3bb7f67f68e636b98e4123275d2)...
  Loaded image: registry:3.0.0
  unpacking docker.io/library/nginx:1.28.0-alpine (sha256:dc8e6d3967a06c0c9bb10d16cfc5770686de05da4c34d4224ef2aec61142e8f1)...
  Loaded image: nginx:1.28.0-alpine
  unpacking docker.io/library/nginx:1.29.4 (sha256:93c49ce72e039396ca3c51a43e2703bfc165500d1fe0faa697fb60c9e60fe99f)...
  Loaded image: nginx:1.29.4

  root@admin:~/kubespray-offline/outputs# cat /etc/containerd/config.toml
  version = 2
  root = "/var/lib/containerd"
  state = "/run/containerd"
  oom_score = 0

  [grpc]
    address = "/run/containerd/containerd.sock"
    uid = 0
    gid = 0

  [debug]
    address = "/run/containerd/debug.sock"
    uid = 0
    gid = 0
    level = "info"

  [metrics]
    address = ""
    grpc_histogram = false

  [cgroup]
    path = ""

  [plugins]
    [plugins."io.containerd.grpc.v1.cri".containerd]
      default_runtime_name = "runc"
      snapshotter = "overlayfs"
    [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc]
      runtime_type = "io.containerd.runc.v2"
    [plugins."io.containerd.grpc.v1.cri".containerd.runtimes.runc.options]
      systemdCgroup = true
  root@admin:~/kubespray-offline/outputs# cat /etc/systemd/system/containerd.service
  # Copyright The containerd Authors.
  #
  # Licensed under the Apache License, Version 2.0 (the "License");
  # you may not use this file except in compliance with the License.
  # You may obtain a copy of the License at
  #
  #     http://www.apache.org/licenses/LICENSE-2.0
  #
  # Unless required by applicable law or agreed to in writing, software
  # distributed under the License is distributed on an "AS IS" BASIS,
  # WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
  # See the License for the specific language governing permissions and
  # limitations under the License.

  [Unit]
  Description=containerd container runtime
  Documentation=https://containerd.io
  After=network.target local-fs.target

  [Service]
  ExecStartPre=-/sbin/modprobe overlay
  ExecStart=/usr/local/bin/containerd

  Type=notify
  Delegate=yes
  KillMode=process
  Restart=always
  RestartSec=5
  # Having non-zero Limit*s causes performance problems due to accounting overhead
  # in the kernel. We recommend using cgroups to do container-local accounting.
  LimitNPROC=infinity
  LimitCORE=infinity
  LimitNOFILE=infinity
  # Comment TasksMax if your systemd version does not supports it.
  # Only systemd 226 and above support this version.
  TasksMax=infinity
  OOMScoreAdjust=-999

  [Install]
  WantedBy=multi-user.target
  root@admin:~/kubespray-offline/outputs# systemctl status containerd.service --no-pager
  ● containerd.service - containerd container runtime
       Loaded: loaded (/etc/systemd/system/containerd.service; enabled; preset: disabled)
       Active: active (running) since Fri 2026-02-13 22:30:24 KST; 1min 12s ago
   Invocation: 642c661b243c4e7198228361ee5c4310
         Docs: https://containerd.io
      Process: 19509 ExecStartPre=/sbin/modprobe overlay (code=exited, status=0/SUCCESS)
     Main PID: 19511 (containerd)
        Tasks: 10
       Memory: 634.9M (peak: 636.7M)
          CPU: 3.348s
       CGroup: /system.slice/containerd.service
               └─19511 /usr/local/bin/containerd

  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267143354+09:00" level=info msg="Start strea… server"
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267151440+09:00" level=info msg="Registered …ith NRI"
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267158303+09:00" level=info msg="runtime int…g up..."
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267163092+09:00" level=info msg="starting plugins..."
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267173832+09:00" level=info msg="Synchronizi…e state"
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.267988368+09:00" level=info msg=serving... a…bug.sock
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.268123675+09:00" level=info msg=serving... a…ck.ttrpc
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.268172639+09:00" level=info msg=serving... a…erd.sock
  Feb 13 22:30:24 admin containerd[19511]: time="2026-02-13T22:30:24.268615622+09:00" level=info msg="containerd …091145s"
  Feb 13 22:30:24 admin systemd[1]: Started containerd.service - containerd container runtime.
  Hint: Some lines were ellipsized, use -l to show in full.
  root@admin:~/kubespray-offline/outputs# nerdctl images
  REPOSITORY    TAG              IMAGE ID        CREATED               PLATFORM       SIZE       BLOB SIZE
  nginx         1.29.4           93c49ce72e03    About a minute ago    linux/amd64    171MB      164.3MB
  nginx         1.28.0-alpine    dc8e6d3967a0    About a minute ago    linux/amd64    51.18MB    49.69MB
  registry      3.0.0            09d6d68c85b9    About a minute ago    linux/amd64    58.44MB    58.26MB
  registry      2.8.1            1e6c7d1be0dd    About a minute ago    linux/amd64    26.65MB    26.49MB

[2] start-nginx.sh 실행 : 웹 서버로 files, images, pypi, rpms 제공

  root@admin:~/kubespray-offline/outputs# cp nginx-default.conf nginx-default.bak
  root@admin:~/kubespray-offline/outputs# cat << EOF > nginx-default.conf
  server {
      listen       80;
      listen  [::]:80;
      server_name  localhost;

      location / {
          root   /usr/share/nginx/html;
          # index  index.html index.htm;

          autoindex on;                 # 디렉터리 목록 표시
          autoindex_exact_size off;     # 파일 크기 KB/MB/GB 단위로 보기 좋게
          autoindex_localtime on;       # 서버 로컬 타임으로 표시
      }

      error_page   500 502 503 504  /50x.html;
      location = /50x.html {
          root   /usr/share/nginx/html;
      }

      # Force sendfile to off
      sendfile off;
  }
  EOF
  root@admin:~/kubespray-offline/outputs# ./start-nginx.sh
  ===> Stop nginx
  nginx
  nginx
  ===> Start nginx
  f6c4f06c2d2cb8e2c70dca6eb4c4d1e1a2afe3449df46064c99e53695a8da371
  root@admin:~/kubespray-offline/outputs# nerdctl ps
  CONTAINER ID    IMAGE                             COMMAND                   CREATED          STATUS    PORTS    NAMES
  f6c4f06c2d2c    docker.io/library/nginx:1.29.4    "/docker-entrypoint.…"    5 seconds ago    Up                 nginx
  root@admin:~/kubespray-offline/outputs# ss -tnlp | grep nginx
  LISTEN 0      511          0.0.0.0:80         0.0.0.0:*    users:(("nginx",pid=19951,fd=6),("nginx",pid=19950,fd=6),("nginx",pid=19949,fd=6),("nginx",pid=19948,fd=6),("nginx",pid=19912,fd=6))
  LISTEN 0      511             [::]:80            [::]:*    users:(("nginx",pid=19951,fd=7),("nginx",pid=19950,fd=7),("nginx",pid=19949,fd=7),("nginx",pid=19948,fd=7),("nginx",pid=19912,fd=7))

[3] setup-offline.sh 실행 : offline repo 설정, pypi mirror 전역 설정

  root@admin:~/kubespray-offline/outputs# cat /etc/redhat-release
  Rocky Linux release 10.0 (Red Quartz)
  root@admin:~/kubespray-offline/outputs# ./setup-offline.sh
  /bin/rm: cannot remove '/etc/yum.repos.d/offline.repo': No such file or directory
  ===> Disable all yumrepositories
  ===> Setup local yum repository
  [offline-repo]
  name=Offline repo
  baseurl=http://localhost/rpms/local/
  enabled=1
  gpgcheck=0
  ===> Setup PyPI mirror
  root@admin:~/kubespray-offline/outputs# tree /etc/yum.repos.d/
  /etc/yum.repos.d/
  ├── offline.repo
  ├── rocky-addons.repo.original
  ├── rocky-devel.repo.original
  ├── rocky-extras.repo.original
  └── rocky.repo.original

  1 directory, 5 files

  root@admin:~/kubespray-offline/outputs# cat ~/.config/pip/pip.conf
  [global]
  index = http://localhost/pypi/
  index-url = http://localhost/pypi/
  trusted-host = localhost

[4] setup-py.sh 실행 : offline repo 로 부터 python${PY} 설치 시도 → offline repo 동작 여부 확인

  root@admin:~/kubespray-offline/outputs# ./setup-py.sh
  ===> Install python, venv, etc
  Offline repo                                                                            9.6 MB/s |  85 kB     00:00
  Package python3-3.12.12-3.el10_1.x86_64 is already installed.
  Dependencies resolved.
  Nothing to do.
  Complete!
  root@admin:~/kubespray-offline/outputs# source pyver.sh
  root@admin:~/kubespray-offline/outputs# echo -e "python_version $python${PY}"
  python_version 3.12
  root@admin:~/kubespray-offline/outputs# dnf info python3
  Last metadata expiration check: 0:00:11 ago on Fri 13 Feb 2026 10:34:50 PM KST.
  Installed Packages
  Name         : python3
  Version      : 3.12.12
  Release      : 3.el10_1
  Architecture : x86_64
  Size         : 31 k
  Source       : python3.12-3.12.12-3.el10_1.src.rpm
  Repository   : @System
  From repo    : baseos
  Summary      : Python 3.12 interpreter
  URL          : https://www.python.org/
  License      : Python-2.0.1

[5] start-registry.sh 실행 : (컨테이너) 이미지 저장소 컨테이너로 기동

  root@admin:~/kubespray-offline/outputs# ./start-registry.sh
  ===> Start registry
  62e114b329464d54f5c06611b8b2ef55add063a821ef9fc0bfa00d5ca123ff34
  root@admin:~/kubespray-offline/outputs# source config.sh
  root@admin:~/kubespray-offline/outputs# echo -e "registry_port: $REGISTRY_PORT"
  registry_port: 35000
  root@admin:~/kubespray-offline/outputs# nerdctl ps
  CONTAINER ID    IMAGE                               COMMAND                   CREATED          STATUS    PORTS    NAMES
  62e114b32946    docker.io/library/registry:3.0.0    "/entrypoint.sh /etc…"    9 seconds ago    Up                 registry
  f6c4f06c2d2c    docker.io/library/nginx:1.29.4      "/docker-entrypoint.…"    4 minutes ago    Up                 nginx
  root@admin:~/kubespray-offline/outputs# ss -tnlp | grep registry
  LISTEN 0      4096               *:5001             *:*    users:(("registry",pid=20064,fd=7))
  LISTEN 0      4096               *:35000            *:*    users:(("registry",pid=20064,fd=3))

  root@admin:~/kubespray-offline/outputs# curl 192.168.10.10:5001/metrics
  # HELP go_gc_duration_seconds A summary of the wall-time pause (stop-the-world) duration in garbage collection cycles.
  # TYPE go_gc_duration_seconds summary
  go_gc_duration_seconds{quantile="0"} 0.000606569
  go_gc_duration_seconds{quantile="0.25"} 0.000606569
  go_gc_duration_seconds{quantile="0.5"} 0.000680398
  go_gc_duration_seconds{quantile="0.75"} 0.000680398
  go_gc_duration_seconds{quantile="1"} 0.000680398
  go_gc_duration_seconds_sum 0.001286967
  go_gc_duration_seconds_count 2

[6] load-push-images.sh 실행 : (컨테이너) 이미지 저장소에 이미지 push

  root@admin:~/kubespray-offline/outputs# echo -e "cpu arch: $IMAGE_ARCH"
  cpu arch: amd64
  root@admin:~/kubespray-offline/outputs# echo -e "Additional container registry hosts: $ADDITIONAL_CONTAINER_REGISTRY_LIST"
  Additional container registry hosts: myregistry.io
  root@admin:~/kubespray-offline/outputs# ls -l images/*.tar.gz
  -rw-r--r--. 1 root root  11194751 Feb 13 22:21 images/docker.io_amazon_aws-alb-ingress-controller-v1.1.9.tar.gz
  -rw-r--r--. 1 root root 175407403 Feb 13 22:22 images/docker.io_amazon_aws-ebs-csi-driver-v0.5.0.tar.gz
  -rw-r--r--. 1 root root 101536170 Feb 13 22:18 images/docker.io_cloudnativelabs_kube-router-v2.1.1.tar.gz
  -rw-r--r--. 1 root root   4735281 Feb 13 22:16 images/docker.io_flannel_flannel-cni-plugin-v1.7.1-flannel1.tar.gz

  load_images() {
      for image in $BASEDIR/images/*.tar.gz; do
          echo "===> Loading $image"
          sudo $NERDCTL load --all-platforms -i $image || exit 1
      done
  }

  root@admin:~/kubespray-offline/outputs# nerdctl images | more
  REPOSITORY                                               TAG
   IMAGE ID        CREATED               PLATFORM       SIZE       BLOB SIZE
  localhost:35000/kube-proxy                               v1.34.3
   fbe99026b627    34 seconds ago        linux/amd64    75.24MB    73.14MB
  localhost:35000/kube-scheduler                           v1.34.3
   f9e384f4d1e8    35 seconds ago        linux/amd64    55.6MB     53.85MB
  localhost:35000/kube-controller-manager                  v1.34.3
   685d1c802d6c    40 seconds ago        linux/amd64    77.75MB    76MB
  localhost:35000/kube-apiserver                           v1.34.3
   7dd47dd94b4d    46 seconds ago        linux/amd64    90.79MB    89.04MB
  localhost:35000/metallb/controller                       v0.13.9
   b9859bda36a2    51 seconds ago        linux/amd64    64.36MB    64.35MB
  localhost:35000/metallb/speaker                          v0.13.9
   36f24e20f6aa    57 seconds ago        linux/amd64    114MB      114MB
  localhost:35000/kubernetesui/metrics-scraper             v1.0.8
   04131c31ea1c    58 seconds ago        linux/amd64    43.82MB    43.82MB
  localhost:35000/kubernetesui/dashboard                   v2.7.0

  root@admin:~/kubespray-offline/outputs# nerdctl images | grep -i kube-proxy
  localhost:35000/kube-proxy                               v1.34.3                                                         fbe99026b627    52 seconds ago        linux/amd64    75.24MB    73.14MB
  registry.k8s.io/kube-proxy                               v1.34.3                                                         fbe99026b627    5 minutes ago         linux/amd64    75.24MB    73.14MB

  root@admin:~/kubespray-offline/outputs# nerdctl images | grep localhost | wc -l
  55
  root@admin:~/kubespray-offline/outputs# nerdctl images | grep -v localhost | wc -l
  56

  root@admin:~/kubespray-offline/outputs# curl -s http://localhost:35000/v2/_catalog | jq
  {
    "repositories": [
      "amazon/aws-alb-ingress-controller",
      "amazon/aws-ebs-csi-driver",
      "calico/apiserver",
      "calico/cni",
      "calico/kube-controllers",
      "calico/node",
      "calico/typha",
      "cilium/certgen",

[7] extract-kubespary.sh 실행 : kubespary 저장소 압축 해제

  root@admin:~/kubespray-offline/outputs# ls -lh files/kubespray-*
  -rw-r--r--. 1 root root 2.5M Feb 13 22:06 files/kubespray-2.30.0.tar.gz
  root@admin:~/kubespray-offline/outputs# tree patches/
  patches/
  └── 2.18.0
      ├── 0001-nerdctl-insecure-registry-config-8339.patch
      ├── 0002-Update-config.toml.j2-8340.patch
      └── 0003-generate-list-8537.patch

  2 directories, 3 files
  root@admin:~/kubespray-offline/outputs# ./extract-kubespray.sh
  kubespray-2.30.0/
  kubespray-2.30.0/.ansible-lint
  kubespray-2.30.0/.ansible-lint-ignore
  kubespray-2.30.0/.editorconfig
  kubespray-2.30.0/.gitattributes
  kubespray-2.30.0/.github/
  kubespray-2.30.0/.github/ISSUE_TEMPLATE/
  kubespray-2.30.0/.github/ISSUE_TEMPLATE/bug-report.yaml
  kubespray-2.30.0/.github/ISSUE_TEMPLATE/config.yml
  kubespray-2.30.0/.github/ISSUE_TEMPLATE/enhancement.yaml
  kubespray-2.30.0/.github/ISSUE_TEMPLATE/failing-test.yaml
  kubespray-2.30.0/.github/PULL_REQUEST_TEMPLATE.md
  kubespray-2.30.0/.github/dependabot.yml
  kubespray-2.30.0/.github/workflows/

  ########## 중략 #################

  root@admin:~/kubespray-offline/outputs# tree kubespray-2.30.0/ -L 1
  kubespray-2.30.0/
  ├── ansible.cfg
  ├── CHANGELOG.md
  ├── cluster.yml
  ├── CNAME
  ├── code-of-conduct.md
  ├── _config.yml
  ├── contrib
  ├── CONTRIBUTING.md
  ├── Dockerfile
  ├── docs
  ├── extra_playbooks
  ├── galaxy.yml
  ├── index.html
  ├── inventory
  ├── library
  ├── LICENSE
  ├── logo
  ├── meta
  ├── OWNERS
  ├── OWNERS_ALIASES
  ├── pipeline.Dockerfile
  ├── playbooks
  ├── plugins
  ├── README.md
  ├── recover-control-plane.yml
  ├── RELEASE.md
  ├── remove-node.yml
  ├── remove_node.yml
  ├── requirements.txt
  ├── reset.yml
  ├── roles
  ├── scale.yml
  ├── scripts
  ├── SECURITY_CONTACTS
  ├── test-infra
  ├── tests
  ├── upgrade-cluster.yml
  ├── upgrade_cluster.yml
  └── Vagrantfile

  14 directories, 26 files

kubespray 설치

kubespray설치

  root@admin:~/kubespray-offline/outputs# python --version
  Python 3.12.12
  root@admin:~/kubespray-offline/outputs# python3.12 -m venv ~/.venv/3.12
  root@admin:~/kubespray-offline/outputs# source ~/.venv/3.12/bin/activate
  ((3.12) ) root@admin:~/kubespray-offline/outputs# which ansible
  /root/.venv/3.12/bin/ansible
  ((3.12) ) root@admin:~/kubespray-offline/outputs# tree ~/.venv/3.12/ -L 4
  /root/.venv/3.12/
  ├── bin
  │   ├── activate
  │   ├── activate.csh
  │   ├── activate.fish

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node1 dnf repolist
  repo id                          repo name
  appstream                        Rocky Linux 10 - AppStream
  baseos                           Rocky Linux 10 - BaseOS
  extras                           Rocky Linux 10 - Extras
  offline-repo                     Offline repo for kubespray

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node2 dnf repolist
  repo id                          repo name
  offline-repo                     Offline repo for kubespray
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node1 dnf repolist
  repo id                          repo name
  offline-repo                     Offline repo for kubespray

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node2 cat /etc/resolv.conf
  nameserver 192.168.10.10
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node2 cat /etc/NetworkManager/conf.d/dns.conf

  [global-dns-domain-*]
  servers = 10.233.0.3,192.168.10.10
  [global-dns]
  searches = default.svc.cluster.local,svc.cluster.local
  options = ndots:2,timeout:2,attempts:2

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# kubectl get deploy,sts,ds -n kube-system -owide
  NAME                             READY   UP-TO-DATE   AVAILABLE   AGE     CONTAINERS       IMAGES                                                     SELECTOR
  deployment.apps/coredns          2/2     2            2           3m24s   coredns          192.168.10.10:35000/coredns/coredns:v1.12.1                k8s-app=kube-dns
  deployment.apps/metrics-server   1/1     1            1           3m3s    metrics-server   192.168.10.10:35000/metrics-server/metrics-server:v0.8.0   app.kubernetes.io/name=metrics-server,version=0.8.0

  NAME                                     DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE     CONTAINERS     IMAGES                                        SELECTOR
  daemonset.apps/kube-flannel              2         2         2       2            2           <none>                   3m41s   kube-flannel   192.168.10.10:35000/flannel/flannel:v0.27.3   app=flannel
  daemonset.apps/kube-flannel-ds-arm       0         0         0       0            0           <none>                   3m41s   kube-flannel   192.168.10.10:35000/flannel/flannel:v0.27.3   app=flannel
  daemonset.apps/kube-flannel-ds-arm64     0         0         0       0            0           <none>                   3m41s   kube-flannel   192.168.10.10:35000/flannel/flannel:v0.27.3   app=flannel
  daemonset.apps/kube-flannel-ds-ppc64le   0         0         0       0            0           <none>                   3m41s   kube-flannel   192.168.10.10:35000/flannel/flannel:v0.27.3   app=flannel
  daemonset.apps/kube-flannel-ds-s390x     0         0         0       0            0           <none>                   3m41s   kube-flannel   192.168.10.10:35000/flannel/flannel:v0.27.3   app=flannel
  daemonset.apps/kube-proxy                2         2         2       2            2           kubernetes.io/os=linux   4m27s   kube-proxy     192.168.10.10:35000/kube-proxy:v1.34.3        k8s-app=kube-proxy

[k8s-node] 이미지 저장소 관련 정보 확인

  root@k8s-node1:~# crictl images
  IMAGE                                               TAG                 IMAGE ID            SIZE
  192.168.10.10:35000/coredns/coredns                 v1.12.1             52546a367cc9e       76.1MB
  192.168.10.10:35000/flannel/flannel-cni-plugin      v1.7.1-flannel1     48b5d33f9a21f       11MB
  192.168.10.10:35000/flannel/flannel                 v0.27.3             3475d115f79b6       92.2MB
  192.168.10.10:35000/kube-apiserver                  v1.34.3             aa27095f56193       89MB
  192.168.10.10:35000/kube-controller-manager         v1.34.3             5826b25d990d7       76MB
  192.168.10.10:35000/kube-proxy                      v1.34.3             36eef8e07bdd6       73.1MB
  192.168.10.10:35000/kube-scheduler                  v1.34.3             aec12dadf56dd       53.8MB
  192.168.10.10:35000/metrics-server/metrics-server   v0.8.0              b9e1e3849e070       83.7MB
  192.168.10.10:35000/pause                           3.10.1              cd073f4c5f6a8       739kB
  root@k8s-node1:~# cat /etc/containerd/certs.d/192.168.10.10\:35000/hosts.toml
  server = "https://192.168.10.10:35000"
  [host."http://192.168.10.10:35000"]
    capabilities = ["pull","resolve"]
    skip_verify = true
    override_path = false

kubespary-offline 에 kube_version 변경 적용하여 관련 파일 다운로드

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# cd /root/kubespray-offline
  ((3.12) ) root@admin:~/kubespray-offline# tree cache/kubespray-2.30.0/contrib/offline/temp/
  cache/kubespray-2.30.0/contrib/offline/temp/
  ├── files.list
  ├── files.list.template
  ├── images.list
  └── images.list.template

  1 directory, 4 files
  ((3.12) ) root@admin:~/kubespray-offline# mv cache/kubespray-2.30.0/contrib/offline/temp/files.list cache/kubespray-2.30.0/contrib/offline/temp/files-2.list
  ((3.12) ) root@admin:~/kubespray-offline# mv cache/kubespray-2.30.0/contrib/offline/temp/images.list cache/kubespray-2.30.0/contrib/offline/temp/images-2.list
  ((3.12) ) root@admin:~/kubespray-offline# cat download-kubespray-files.sh
  #!/bin/bash

  umask 022

  source ./config.sh
  source scripts/common.sh
  source scripts/images.sh

  KUBESPRAY_DIR=./cache/kubespray-${KUBESPRAY_VERSION}
  if [ ! -e $KUBESPRAY_DIR ]; then
      echo "No kubespray dir at $KUBESPRAY_DIR"
      exit 1
  fi

  FILES_DIR=outputs/files

  # Decide relative directory of file from URL
  #
  # kubernetes/vx.x.x        : kubeadm/kubectl/kubelet
  # kubernetes/etcd          : etcd
  # kubernetes/cni           : CNI plugins
  # kubernetes/cri-tools     : crictl
  # kubernetes/calico/vx.x.x : calico
  # kubernetes/calico        : calicoctl
  # runc/vx.x.x              : runc
  # cilium-cli/vx.x.x        : cilium-cli
  # gvisor/{ver}/{arch}      : gvisor (sunrc, containerd-shim)
  # scopeo/vx.x.x            : scopeo
  # yq/vx.x.x                : yq
  #
  decide_relative_dir() {
      local url=$1
      local rdir
      rdir=$url
      rdir=$(echo $rdir | sed "s@.*/\(v[0-9.]*\)/.*/kube\(adm\|ctl\|let\)@kubernetes/\1@g")
      rdir=$(echo $rdir | sed "s@.*/etcd-.*.tar.gz@kubernetes/etcd@")
      rdir=$(echo $rdir | sed "s@.*/cni-plugins.*.tgz@kubernetes/cni@")
      rdir=$(echo $rdir | sed "s@.*/crictl-.*.tar.gz@kubernetes/cri-tools@")
      rdir=$(echo $rdir | sed "s@.*/\(v.*\)/calicoctl-.*@kubernetes/calico/\1@")
      rdir=$(echo $rdir | sed "s@.*/\(v.*\)/runc.${IMAGE_ARCH}@runc/\1@")
      rdir=$(echo $rdir | sed "s@.*/\(v.*\)/cilium-linux-.*@cilium-cli/\1@")
      rdir=$(echo $rdir | sed "s@.*/\([^/]*\)/\([^/]*\)/runsc@gvisor/\1/\2@")
      rdir=$(echo $rdir | sed "s@.*/\([^/]*\)/\([^/]*\)/containerd-shim-runsc-v1@gvisor/\1/\2@")
      rdir=$(echo $rdir | sed "s@.*/\(v[^/]*\)/skopeo-linux-.*@skopeo/\1@")
      rdir=$(echo $rdir | sed "s@.*/\(v[^/]*\)/yq_linux_*@yq/\1@")
      if [ "$url" != "$rdir" ]; then
          echo $rdir
          return
      fi

      rdir=$(echo $rdir | sed "s@.*/calico/.*@kubernetes/calico@")
      if [ "$url" != "$rdir" ]; then
          echo $rdir
      else
          echo ""
      fi
  }

  get_url() {
      url=$1
      filename="${url##*/}"

      rdir=$(decide_relative_dir $url)

      if [ -n "$rdir" ]; then
          if [ ! -d $FILES_DIR/$rdir ]; then
              mkdir -p $FILES_DIR/$rdir
          fi
      else
          rdir="."
      fi

      if [ ! -e $FILES_DIR/$rdir/$filename ]; then
          echo "==> Download $url"
          for i in {1..3}; do
              curl --location --show-error --fail --output $FILES_DIR/$rdir/$filename $url && return
              echo "curl failed. Attempt=$i"
          done
          echo "Download failed, exit : $url"
          exit 1
      else
          echo "==> Skip $url"
      fi
  }

  # execute offline generate_list.sh
  generate_list() {
      #if [ $KUBESPRAY_VERSION == "2.18.0" ]; then
      #    export containerd_version=${containerd_version:-1.5.8}
      #    export host_os=linux
      #    export image_arch=amd64
      #fi
      LANG=C /bin/bash ${KUBESPRAY_DIR}/contrib/offline/generate_list.sh || exit 1

      #if [ $KUBESPRAY_VERSION == "2.18.0" ]; then
      #    # check roles/download/default/main.yml to decide version
      #    snapshot_controller_tag=${snapshot_controller_tag:-v4.2.1}
      #    sed -i "s@\(.*/snapshot-controller:\)@\1${snapshot_controller_tag}@" ${KUBESPRAY_DIR}/contrib/offline/temp/images.list || exit 1
      #fi
  }

  . ./target-scripts/venv.sh

  generate_list

  mkdir -p $FILES_DIR

  cp ${KUBESPRAY_DIR}/contrib/offline/temp/files.list $FILES_DIR/
  cp ${KUBESPRAY_DIR}/contrib/offline/temp/images.list $IMAGES_DIR/

  # download files
  files=$(cat ${FILES_DIR}/files.list)
  for i in $files; do
      get_url $i
  done

  # download images
  ./download-images.sh || exit 1
  ((3.12) ) root@admin:~/kubespray-offline# cp download-kubespray-files.sh download-kubespray-files.bak
  ((3.12) ) root@admin:~/kubespray-offline# sed -i '/generate_list$/,$ { /generate_list/!d }' download-kubespray-files.sh
  ((3.12) ) root@admin:~/kubespray-offline# diff download-kubespray-files.sh download-kubespray-files.bak
  104a105,118
  >
  > mkdir -p $FILES_DIR
  >
  > cp ${KUBESPRAY_DIR}/contrib/offline/temp/files.list $FILES_DIR/
  > cp ${KUBESPRAY_DIR}/contrib/offline/temp/images.list $IMAGES_DIR/
  >
  > # download files
  > files=$(cat ${FILES_DIR}/files.list)
  > for i in $files; do
  >     get_url $i
  > done
  >
  > # download images
  > ./download-images.sh || exit 1
  ((3.12) ) root@admin:~/kubespray-offline# sed -i 's|offline/generate_list.sh|offline/generate_list.sh -e kube_version=1.33.7|g' download-kubespray-files.sh
  ((3.12) ) root@admin:~/kubespray-offline# cat download-kubespray-files.sh | grep kube_version
      LANG=C /bin/bash ${KUBESPRAY_DIR}/contrib/offline/generate_list.sh -e kube_version=1.33.7 || exit 1
  ((3.12) ) root@admin:~/kubespray-offline# ./download-kubespray-files.sh
  python3 = python3.12
  VENV_DIR = /root/.venv/3.12
  [WARNING]: No inventory was parsed, only implicit localhost is available
  [WARNING]: provided hosts list is empty, only localhost is available. Note that the implicit localhost does not match
  'all'

  PLAY [Collect container images for offline deployment] *****************************************************************
  Friday 13 February 2026  23:07:52 +0900 (0:00:00.016)       0:00:00.016 *******
  Friday 13 February 2026  23:07:52 +0900 (0:00:00.013)       0:00:00.030 *******
  Friday 13 February 2026  23:07:52 +0900 (0:00:00.015)       0:00:00.045 *******
  Friday 13 February 2026  23:07:52 +0900 (0:00:00.015)       0:00:00.061 *******
  Friday 13 February 2026  23:07:52 +0900 (0:00:00.014)       0:00:00.075 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.012)       0:00:00.088 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.021)       0:00:00.110 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.013)       0:00:00.123 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.016)       0:00:00.139 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.011)       0:00:00.150 *******
  Friday 13 February 2026  23:07:53 +0900 (0:00:00.423)       0:00:00.574 *******

  TASK [Collect container images for offline deployment] *****************************************************************
  changed: [localhost] => (item=files)
  changed: [localhost] => (item=images)

  PLAY RECAP *************************************************************************************************************
  localhost                  : ok=1    changed=1    unreachable=0    failed=0    skipped=10   rescued=0    ignored=0

  Friday 13 February 2026  23:07:54 +0900 (0:00:00.937)       0:00:01.512 *******
  ===============================================================================
  Collect container images for offline deployment ----------------------------------------------------------------- 0.94s
  download : Download | Download files / images ------------------------------------------------------------------- 0.42s
  download : Prep_download | Register docker images info ---------------------------------------------------------- 0.02s
  download : Prep_download | Create local cache for files and images on control node ------------------------------ 0.02s
  download : Prep_download | On localhost, check if passwordless root is possible --------------------------------- 0.02s
  download : Prep_download | On localhost, check if user has access to the container runtime without using sudo --- 0.02s
  download : Prep_download | Parse the outputs of the previous commands ------------------------------------------- 0.01s
  download : Prep_download | Set a few facts ---------------------------------------------------------------------- 0.01s
  download : Prep_download | Create staging directory on remote node ---------------------------------------------- 0.01s
  download : Prep_download | Check that local user is in group or can become root --------------------------------- 0.01s
  download : Download | Get kubeadm binary and list of required images -------------------------------------------- 0.01s
  ((3.12) ) root@admin:~/kubespray-offline# cd cache/kubespray-2.30.0/contrib/offline/temp
  ((3.12) ) root@admin:~/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/temp# diff files-2.list files.list
  1,3c1,3
  < https://dl.k8s.io/release/v1.34.3/bin/linux/amd64/kubelet
  < https://dl.k8s.io/release/v1.34.3/bin/linux/amd64/kubectl
  < https://dl.k8s.io/release/v1.34.3/bin/linux/amd64/kubeadm
  ---
  > https://dl.k8s.io/release/v1.33.7/bin/linux/amd64/kubelet
  > https://dl.k8s.io/release/v1.33.7/bin/linux/amd64/kubectl
  > https://dl.k8s.io/release/v1.33.7/bin/linux/amd64/kubeadm
  9,10c9,10
  < https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.34.0/crictl-v1.34.0-linux-amd64.tar.gz
  < https://storage.googleapis.com/cri-o/artifacts/cri-o.amd64.v1.34.4.tar.gz
  ---
  > https://github.com/kubernetes-sigs/cri-tools/releases/download/v1.33.0/crictl-v1.33.0-linux-amd64.tar.gz
  > https://storage.googleapis.com/cri-o/artifacts/cri-o.amd64.v1.33.8.tar.gz

K8S 관련 폐쇄망 실습

샘플앱배포

nginx[alpine]

   ((3.12) ) root@admin:~/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/temp# cat << EOF | kubectl apply -f -
  apiVersion: apps/v1
  kind: Deployment
  metadata:
    name: nginx
    labels:
      app: nginx
  spec:
    replicas: 1
    selector:
      matchLabels:
        app: nginx
    template:
      metadata:
        labels:
          app: nginx
      spec:
        containers:
          - name: nginx
            image: nginx:alpine   # docker.io/library/nginx:alpine
            ports:
              - containerPort: 80
  EOF

  ##배포 시도해도 실패
   ((3.12) ) root@admin:~/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/temp# kubectl describe pod
    Warning  Failed     8s    kubelet            Failed to pull image "nginx:alpine": rpc error: code = DeadlineExceeded desc = failed to pull and unpack image "docker.io/library/nginx:alpine": failed to resolve image: failed to do request: Head "https://registry-1.docker.io/v2/library/nginx/manifests/alpine": dial tcp 98.95.137.26:443: i/o timeout
    Warning  Failed     8s    kubelet            Error: ErrImagePull
    Normal   BackOff    8s    kubelet            Back-off pulling image "nginx:alpine"
    Warning  Failed     8s    kubelet            Error: ImagePullBackOff

(컨테이너) 이미지 저장소에 이미지 push

  ((3.12) ) root@admin:~/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/temp# podman pull nginx:alpine
  ✔ docker.io/library/nginx:alpine
  Trying to pull docker.io/library/nginx:alpine...
  Getting image source signatures
  Copying blob 955a8478f9ac done   |
  Copying blob 589002ba0eae done   |
  Copying blob 3e2c181db1b0 done   |
  Copying blob bca5d04786e1 done   |
  Copying blob 6b7b6c7061b7 done   |
  Copying blob 399d0898a94e done   |
  Copying blob 6d397a54a185 done   |
  Copying blob 5e7756927bef done   |
  Copying config b76de378d5 done   |
  Writing manifest to image destination
  b76de378d57272a1dd9091a05dd548a3639dfb792ebdbf95d06704d2950afdea
  ((3.12) ) root@admin:~/kubespray-offline/cache/kubespray-2.30.0/contrib/offline/temp# podman images | grep nginx
  docker.io/library/nginx                                alpine                                                        b76de378d572  8 days ago     63.5 MB
  docker.io/library/nginx                                1.29.4                                                        248d2326f351  10 days ago    164 MB
  registry.k8s.io/ingress-nginx/controller               v1.13.3                                                       c44d76c3213e  4 months ago   334 MB
  docker.io/library/nginx                                1.28.0-alpine                                                 c318e336065b  9 months ago   49.7 MB

  ((3.12) ) root@admin:~# curl -s 192.168.10.10:35000/v2/library/nginx/tags/list | jq
  {
    "name": "library/nginx",
    "tags": [
      "1.28.0-alpine",
      "1.29.4"
    ]
  }

kubespary 에 containerd_registries_mirrors values 설정 후 적용 --tags containerd

  ((3.12) ) root@admin:~# cat /root/kubespray-offline/outputs/kubespray-2.30.0/inventory/mycluster/group_vars/all/offline.yml | head -n 15
  #
  # offline.yml sample
  #

  http_server: "http://192.168.10.10"
  registry_host: "192.168.10.10:35000"

  # Insecure registries for containerd
  containerd_registries_mirrors:
    - prefix: "{{ registry_host }}"
      mirrors:
        - host: "http://{{ registry_host }}"
          capabilities: ["pull", "resolve"]
          skip_verify: true
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml -e kube_version="1.34.3" --tags containerd
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node2 tree /etc/containerd
  /etc/containerd
  ├── certs.d
  │   ├── 192.168.10.10:35000
  │   │   └── hosts.toml
  │   ├── docker.io
  │   │   └── hosts.toml
  │   ├── quay.io
  │   │   └── hosts.toml
  │   └── registry-1.docker.io
  │       └── hosts.toml
  ├── config.toml
  └── cri-base.json
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# ssh k8s-node2 cat /etc/containerd/certs.d/quay.io/hosts.toml
  server = "https://quay.io"
  [host."http://192.168.10.10:35000"]
    capabilities = ["pull","resolve"]
    skip_verify = true
    override_path = false

헬름 차트 저장소

nginx helm 차트 작성, 배포 및 tgz 패키징

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# podman images
  REPOSITORY                                             TAG                                                           IMAGE ID      CREATED        SIZE
  docker.io/library/nginx                                alpine                                                        b76de378d572  8 days ago     63.5 MB
  192.168.10.10:35000/library/nginx                      alpine
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# podman pull nginx:1.28.0-alpine
  Trying to pull docker.io/library/nginx:1.28.0-alpine...

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# podman tag nginx:1.28.0-alpine 192.168.10.10:35000/library/nginx:1.28.0-alpine

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0# curl -s 192.168.10.10:35000/v2/library/nginx/tags/list | jq
  {
    "name": "library/nginx",
    "tags": [
      "1.28.0-alpine",
      "1.29.4",
      "alpine"
    ]
  }

  ##차트작성
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# tree
  .
  ├── Chart.yaml
  ├── templates
  │   ├── deployment.yaml
  │   └── service.yaml
  └── values.yaml

  2 directories, 4 files

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm package .
  Successfully packaged chart and saved it to: /root/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart/nginx-chart-1.0.0.tgz
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# tar -tzf nginx-chart-1.0.0.tgz
  nginx-chart/Chart.yaml
  nginx-chart/values.yaml
  nginx-chart/templates/deployment.yaml
  nginx-chart/templates/service.yaml
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# zcat nginx-chart-1.0.0.tgz | tar -xOf - nginx-chart/Chart.yaml
  apiVersion: v2
  appVersion: 1.28.0-alpine
  description: A Helm chart for deploying Nginx with custom index.html
  name: nginx-chart
  type: application
  version: 1.0.0
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm uninstall dev-nginx
  release "dev-nginx" uninstalled
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm list
  NAME    NAMESPACE       REVISION        UPDATED STATUS  CHART   APP VERSION

외부 공용 차트 tgz 패키징 다운로드 후 배포 서버에 복사 후 사용

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# podman pull docker.io/bitnami/nginx:latest
  Trying to pull docker.io/bitnami/nginx:latest...
  Getting image source signatures
  Copying blob 39137f68a782 done   |
  Copying config f335e22d6b done   |
  Writing manifest to image destination
  f335e22d6b5abdfc5de5c5d8fd54f6af452e0e4cf7c6c003e7ddf1649e2d0387
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# podman tag bitnami/nginx:latest 192.168.10.10:35000/bitnami/nginx:latest
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# podman push 192.168.10.10:35000/bitnami/nginx:latest
  Getting image source signatures
  Copying blob 83eeb01b5597 done   |
  Copying config f335e22d6b done   |
  Writing manifest to image destination

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm get metadata my-nginx
  NAME: my-nginx
  CHART: nginx
  VERSION: 22.4.7
  APP_VERSION: 1.29.5
  ANNOTATIONS: fips=true,images=- name: git
    version: 2.53.0
    image: registry-1.docker.io/bitnami/git:latest
  - name: nginx
    version: 1.29.5
    image: registry-1.docker.io/bitnami/nginx:latest
  - name: nginx-exporter
    version: 1.5.1
    image: registry-1.docker.io/bitnami/nginx-exporter:latest
  ,licenses=Apache-2.0,tanzuCategory=clusterUtility
  DEPENDENCIES: common
  NAMESPACE: default
  REVISION: 1
  STATUS: deployed
  DEPLOYED_AT: 2026-02-13T23:38:51+09:00
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm list
  NAME            NAMESPACE       REVISION        UPDATED                                 STATUS          CHART          APP VERSION
  my-nginx        default         1               2026-02-13 23:38:51.442908021 +0900 KST deployed        nginx-22.4.7   1.29.5
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# kubectl get deploy -owide
  NAME       READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES                                      SELECTOR
  my-nginx   1/1     1            1           14s   nginx        registry-1.docker.io/bitnami/nginx:latest   app.kubernetes.io/instance=my-nginx,app.kubernetes.io/name=nginx
  nginx      1/1     1            1           15m   nginx        nginx:alpine                                app=nginx
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm get manifest my-nginx | grep 'image:'
            image: registry-1.docker.io/bitnami/nginx:latest
            image: registry-1.docker.io/bitnami/nginx:latest

내부망에 Helm Chart 저장소(ChartMuseum) 구축 후 nginx 차트 업로드 후 사용

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# chmod 777 /data/chartmuseum/charts
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# podman run -d \
    --name chartmuseum \
    -p 8080:8080 \
    -v /data/chartmuseum/charts:/charts \
    -e STORAGE=local \
    -e STORAGE_LOCAL_ROOTDIR=/charts \
    -e DEBUG=true \
    ghcr.io/helm/chartmuseum:v0.16.4
  Trying to pull ghcr.io/helm/chartmuseum:v0.16.4...
  Getting image source signatures
  Copying blob 589002ba0eae skipped: already exists
  Copying blob aa06029dd384 done   |
  Copying blob c1c9b34da041 done   |
  Copying config 281626b9b5 done   |
  Writing manifest to image destination
  fb47663c6e175287500ddfffbf200aead634d15fb00e719adf8716953d462841

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm repo add internal http://192.168.10.10:8080
  "internal" has been added to your repositories
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm repo update
  Hang tight while we grab the latest from your chart repositories...
  ...Successfully got an update from the "internal" chart repository
  Update Complete. ⎈Happy Helming!⎈
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-oci-reg# helm repo list
  NAME            URL
  internal        http://192.168.10.10:8080

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# curl -s http://192.168.10.10:8080/api/charts | jq
  {
    "nginx-chart": [
      {
        "name": "nginx-chart",
        "version": "1.0.0",
        "description": "A Helm chart for deploying Nginx with custom index.html",
        "apiVersion": "v2",
        "appVersion": "1.28.0-alpine",
        "type": "application",
        "urls": [
          "charts/nginx-chart-1.0.0.tgz"
        ],
        "created": "2026-02-13T14:44:08.758241429Z",
        "digest": "35ce014a79d3c92287d0784aef47e0fc021f42371141536fbaf410da2271c6fd"
      }
    ]
  }

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm repo update
  Hang tight while we grab the latest from your chart repositories...
  ...Successfully got an update from the "internal" chart repository
  Update Complete. ⎈Happy Helming!⎈
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm install my-nginx internal/nginx-chart
  NAME: my-nginx
  LAST DEPLOYED: Fri Feb 13 23:44:34 2026
  NAMESPACE: default
  STATUS: deployed
  REVISION: 1
  TEST SUITE: None
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# helm list
  NAME            NAMESPACE       REVISION        UPDATED                                 STATUS          CHART                   APP VERSION
  my-nginx        default         1               2026-02-13 23:44:34.773014407 +0900 KST deployed        nginx-chart-1.0.0       1.28.0-alpine

Private PyPI(Python Package Index) Mirror

[k8s-node] pip 설정 및 사용

  root@k8s-node1:~# curl http://192.168.10.10/pypi/
  <!DOCTYPE html>
  <html>
    <head>
      <title>Simple index</title>
    </head>
    <body>
      <a href="ansible/index.html">ansible</a>
      <a href="ansible-core/index.html">ansible-core</a>
      <a href="cffi/index.html">cffi</a>
      <a href="cryptography/index.html">cryptography</a>
      <a href="cython/index.html">Cython</a>
      <a href="distro/index.html">distro</a>
      <a href="flit-core/index.html">flit_core</a>
      <a href="jinja2/index.html">Jinja2</a>
      <a href="jmespath/index.html">jmespath</a>
      <a href="markupsafe/index.html">MarkupSafe</a>
      <a href="netaddr/index.html">netaddr</a>
      <a href="packaging/index.html">packaging</a>
      <a href="pip/index.html">pip</a>
      <a href="pycparser/index.html">pycparser</a>
      <a href="pyyaml/index.html">PyYAML</a>
      <a href="resolvelib/index.html">resolvelib</a>
      <a href="ruamel-yaml/index.html">ruamel.yaml</a>
      <a href="selinux/index.html">selinux</a>
      <a href="setuptools/index.html">setuptools</a>
      <a href="wheel/index.html">wheel</a>
    </body>

  root@k8s-node1:~# pip list | grep -i netaddr
root@k8s-node1:~# pip install netaddr
Looking in indexes: http://192.168.10.10/pypi
Collecting netaddr
  Downloading http://192.168.10.10/pypi/netaddr/netaddr-1.3.0-py3-none-any.whl (2.3 MB)
     ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 2.3/2.3 MB 46.0 MB/s eta 0:00:00
Installing collected packages: netaddr
Successfully installed netaddr-1.3.0
WARNING: Running pip as the 'root' user can result in broken permissions and conflicting behaviour with the system package manager. It is recommended to use a virtual environment instead: https://pip.pypa.io/warnings/venv
root@k8s-node1:~# pip list | grep -i netaddr
netaddr                   1.3.0

root@k8s-node1:~# pip install httpx
Looking in indexes: http://192.168.10.10/pypi
ERROR: Could not find a version that satisfies the requirement httpx (from versions: none)
ERROR: No matching distribution found for httpx

```

pypi 추가패키지설치후 사용

  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# cat /root/.config/pip/pip.conf
  [global]
  index = http://localhost/pypi/
  index-url = http://localhost/pypi/
  trusted-host = localhost
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# mv /root/.config/pip/pip.conf /root/.config/pip/pip.bak
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# pip install httpx
  Collecting httpx
    Downloading httpx-0.28.1-py3-none-any.whl.metadata (7.1 kB)
  Collecting anyio (from httpx)
    Downloading anyio-4.12.1-py3-none-any.whl.metadata (4.3 kB)
  Collecting certifi (from httpx)
    Downloading certifi-2026.1.4-py3-none-any.whl.metadata (2.5 kB)
  Collecting httpcore==1.* (from httpx)
    Downloading httpcore-1.0.9-py3-none-any.whl.metadata (21 kB)
  Collecting idna (from httpx)
    Downloading idna-3.11-py3-none-any.whl.metadata (8.4 kB)
  Collecting h11>=0.16 (from httpcore==1.*->httpx)
    Downloading h11-0.16.0-py3-none-any.whl.metadata (8.3 kB)
  Collecting typing_extensions>=4.5 (from anyio->httpx)
    Downloading typing_extensions-4.15.0-py3-none-any.whl.metadata (3.3 kB)
  Downloading httpx-0.28.1-py3-none-any.whl (73 kB)
  Downloading httpcore-1.0.9-py3-none-any.whl (78 kB)
  Downloading h11-0.16.0-py3-none-any.whl (37 kB)
  Downloading anyio-4.12.1-py3-none-any.whl (113 kB)
  Downloading idna-3.11-py3-none-any.whl (71 kB)
  Downloading typing_extensions-4.15.0-py3-none-any.whl (44 kB)
  Downloading certifi-2026.1.4-py3-none-any.whl (152 kB)
  Installing collected packages: typing_extensions, idna, h11, certifi, httpcore, anyio, httpx
  Successfully installed anyio-4.12.1 certifi-2026.1.4 h11-0.16.0 httpcore-1.0.9 httpx-0.28.1 idna-3.11 typing_extensions-4.15.0
  ((3.12) ) root@admin:~/kubespray-offline/outputs/kubespray-2.30.0/nginx-chart# pip list | grep httpx
  httpx              0.28.1

  ((3.12) ) root@admin:~/kubespray-offline# curl http://192.168.10.10/pypi/
  <!DOCTYPE html>
  <html>
    <head>
      <title>Simple index</title>
    </head>
    <body>
      <a href="ansible/index.html">ansible</a>
      <a href="ansible-core/index.html">ansible-core</a>
      <a href="cffi/index.html">cffi</a>
      <a href="cryptography/index.html">cryptography</a>
      <a href="cython/index.html">Cython</a>
      <a href="distro/index.html">distro</a>
      <a href="flit-core/index.html">flit_core</a>
      <a href="httpx/index.html">httpx</a>
      <a href="jinja2/index.html">Jinja2</a>
      <a href="jmespath/index.html">jmespath</a>
      <a href="markupsafe/index.html">MarkupSafe</a>
      <a href="netaddr/index.html">netaddr</a>
      <a href="packaging/index.html">packaging</a>
      <a href="pip/index.html">pip</a>
      <a href="pycparser/index.html">pycparser</a>
      <a href="pyyaml/index.html">PyYAML</a>
      <a href="resolvelib/index.html">resolvelib</a>
      <a href="ruamel-yaml/index.html">ruamel.yaml</a>
      <a href="selinux/index.html">selinux</a>
      <a href="setuptools/index.html">setuptools</a>
      <a href="wheel/index.html">wheel</a>
    </body>
  </html>((3.12) ) root@admin:~/kubespray-offline# pip install httpx
  Requirement already satisfied: httpx in /root/.venv/3.12/lib64/python3.12/site-packages (0.28.1)
  Requirement already satisfied: anyio in /root/.venv/3.12/lib64/python3.12/site-packages (from httpx) (4.12.1)
  Requirement already satisfied: certifi in /root/.venv/3.12/lib64/python3.12/site-packages (from httpx) (2026.1.4)
  Requirement already satisfied: httpcore==1.* in /root/.venv/3.12/lib64/python3.12/site-packages (from httpx) (1.0.9)
  Requirement already satisfied: idna in /root/.venv/3.12/lib64/python3.12/site-packages (from httpx) (3.11)
  Requirement already satisfied: h11>=0.16 in /root/.venv/3.12/lib64/python3.12/site-packages (from httpcore==1.*->httpx) (0.16.0)
  Requirement already satisfied: typing_extensions>=4.5 in /root/.venv/3.12/lib64/python3.12/site-packages (from anyio->httpx) (4.15.0)

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 7주차 과제 (0)	2026.02.18
K8S ) 5주차 과제 (0)	2026.02.06
K8S) 4주차 과제 (0)	2026.01.31
K8S)3주차 과제 (0)	2026.01.24
K8S)2주차 과제 (0)	2026.01.15

K8S ) 5주차 과제

zosys 2026. 2. 6. 14:04

2026. 2. 6. 14:04

실습 환경 배포

NAME	Description	CPU	RAM	NIC1	NIC2	Init Script
admin-lb	kubespary 실행, API LB	2	1GB	10.0.2.15	192.168.10.10	admin-lb.sh
k8s-node1	K8S ControlPlane	4	2GB	10.0.2.15	192.168.10.11	init-cfg.sh
k8s-node2	K8S ControlPlane	4	2GB	10.0.2.15	192.168.10.12	init-cfg.sh
k8s-node3	K8S ControlPlane	4	2GB	10.0.2.15	192.168.10.13	init-cfg.sh
k8s-node4	K8S Worker	4	2GB	10.0.2.15	192.168.10.14	init-cfg.sh
k8s-node5	K8S Worker	4	2GB	10.0.2.15	192.168.10.15	init-cfg.sh

1. 실습환경배포

 howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/k8s-ha-kubespary  curl -O https://raw.githubusercontent.com/gasida/vagrant-lab/refs/heads/main/k8s-ha-kubespary/Vagrantfile
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100  1894  100  1894    0     0   4894      0 --:--:-- --:--:-- --:--:--  4906
 howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/k8s-ha-kubespary  curl -O https://raw.githubusercontent.com/gasida/vagrant-lab/refs/heads/main/k8s-ha-kubespary/admin-lb.sh
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100  6930  100  6930    0     0  10127      0 --:--:-- --:--:-- --:--:-- 10116
 howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/k8s-ha-kubespary  curl -O https://raw.githubusercontent.com/gasida/vagrant-lab/refs/heads/main/k8s-ha-kubespary/init_cfg.sh
  % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                 Dload  Upload   Total   Spent    Left  Speed
100  1709  100  1709    0     0   5381      0 --:--:-- --:--:-- --:--:--  5374

howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/k8s-ha-kubespary  vagrant up
Bringing machine 'k8s-node1' up with 'virtualbox' provider...
Bringing machine 'k8s-node2' up with 'virtualbox' provider...
Bringing machine 'k8s-node3' up with 'virtualbox' provider...
Bringing machine 'k8s-node4' up with 'virtualbox' provider...
Bringing machine 'k8s-node5' up with 'virtualbox' provider...
Bringing machine 'admin-lb' up with 'virtualbox' provider...
==> k8s-node1: Cloning VM...
==> k8s-node1: Matching MAC address for NAT networking...
==> k8s-node1: Checking if box 'bento/rockylinux-10.0' version '202510.26.0' is up to date...
==> k8s-node1: Setting the name of the VM: k8s-node1
==> k8s-node1: Clearing any previously set network interfaces...
==> k8s-node1: Preparing network interfaces based on configuration...
    k8s-node1: Adapter 1: nat
    k8s-node1: Adapter 2: hostonly
==> k8s-node1: Forwarding ports...
    k8s-node1: 22 (guest) => 60001 (host) (adapter 1)
==> k8s-node1: Running 'pre-boot' VM customizations...
==> k8s-node1: Booting VM...
==> k8s-node1: Waiting for machine to boot. This may take a few minutes...
    k8s-node1: SSH address: 127.0.0.1:60001
    k8s-node1: SSH username: vagrant
    k8s-node1: SSH auth method: private key
                                                                    .
                                                                    .
                                                                    .

    admin-lb: curl: (6) Could not resolve host: raw.githubusercontent.com
    admin-lb: [TASK 16] ETC
    admin-lb: >>>> Initial Config End <<<<

howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/k8s-ha-kubespary  vagrant status
Current machine states:

k8s-node1                 running (virtualbox)
k8s-node2                 running (virtualbox)
k8s-node3                 running (virtualbox)
k8s-node4                 running (virtualbox)
k8s-node5                 running (virtualbox)
admin-lb                  running (virtualbox)

howoo@ttokkang-ui-MacBookAir ~/ vagrant ssh admin-lb

root@admin-lb:~# sh admin-lb.sh 5
>>>> Initial Config Start <<<<
[TASK 1] Change Timezone and Enable NTP
[TASK 2] Disable firewalld and selinux
[TASK 3] Setting Local DNS Using Hosts file
admin-lb.sh: line 20: ((: i<=: syntax error: operand expected (error token is "<=")
[TASK 4] Delete default routing - enp0s9 NIC
[TASK 5] Install kubectl
                                                                        .
                                                                        .
                                                                        .

+ echo 'sudo su -'
+ echo '>>>> Initial Config End <<<<'
>>>> Initial Config End <<<<

## Ansible로 k8s_node server에 init_cfg.sh 배포
root@admin-lb:~# cat /etc/ansible/hosts
[k8s_nodes]
k8s-node1 ansible_host=192.168.10.11
k8s-node2 ansible_host=192.168.10.12
k8s-node3 ansible_host=192.168.10.13
k8s-node4 ansible_host=192.168.10.14
k8s-node5 ansible_host=192.168.10.15

[k8s_nodes:vars]
ansible_user=root

ssh-copy-id root@192.168.10.11
ssh-copy-id root@192.168.10.12
ssh-copy-id root@192.168.10.13
ssh-copy-id root@192.168.10.14
ssh-copy-id root@192.168.10.15

ansible k8s_nodes -m copy -a "src=/root/init_cfg.sh dest=/root/init_cfg.sh mode=0755"
ansible k8s_nodes -m shell -a "/root/init_cfg.sh"

TASK [Copy init script] ***************************************************************************************************************************************
ok: [k8s-node1]
ok: [k8s-node3]
ok: [k8s-node5]
ok: [k8s-node4]
ok: [k8s-node2]

TASK [Run init script] ****************************************************************************************************************************************
changed: [k8s-node4]
changed: [k8s-node2]
changed: [k8s-node5]
changed: [k8s-node1]
changed: [k8s-node3]

PLAY RECAP ****************************************************************************************************************************************************
k8s-node1                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
k8s-node2                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
k8s-node3                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
k8s-node4                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0
k8s-node5                  : ok=3    changed=1    unreachable=0    failed=0    skipped=0    rescued=0    ignored=0

# HAProxy 상태 확인
systemctl status haproxy.service --no-pager
journalctl -u haproxy.service --no-pager
**ss -tnlp | grep haproxy**
*LISTEN 0      3000         0.0.0.0:6443       0.0.0.0:*    users:(("haproxy",pid=4915,fd=7))  # k8s api loadbalancer
LISTEN 0      3000         0.0.0.0:9000       0.0.0.0:*    users:(("haproxy",pid=4915,fd=8))  # haproxy stat dashbaord
LISTEN 0      3000         0.0.0.0:8405       0.0.0.0:*    users:(("haproxy",pid=4915,fd=9))  # metrics exporter*

# 통계 페이지 접속
open http://192.168.10.10:9000/haproxy_stats

# (참고) 프로테우스 메트릭 엔드포인트 접속
curl http://192.168.10.10:8405/metrics
                                                                        .
                                                                        .
                                                                        .
haproxy_resolver_truncated{resolver="default",nameserver="0.192.249.101"} 0
haproxy_resolver_truncated{resolver="default",nameserver="8.8.8.8"} 0
# HELP haproxy_resolver_outdated Outdated
# TYPE haproxy_resolver_outdated gauge
haproxy_resolver_outdated{resolver="default",nameserver="0.192.249.101"} 0
haproxy_resolver_outdated{resolver="default",nameserver="8.8.8.8"} 0

kubespray를 통한 k8s 배포

                                                                            .
                                                                            .
                                                                            .
        ]
    },
    "kube_node": {
        "hosts": [
            "k8s-node4"
        ]
    }
}
root@admin-lb:~/kubespray# ansible-inventory -i /root/kubespray/inventory/mycluster/inventory.ini --graph
@all:
  |--@ungrouped:
  |--@etcd:
  |  |--@kube_control_plane:
  |  |  |--k8s-node1
  |  |  |--k8s-node2
  |  |  |--k8s-node3
  |--@kube_node:
  |  |--k8s-node4


root@admin-lb:~/kubespray# sed -i 's|kube_owner: kube|kube_owner: root|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@admin-lb:~/kubespray# sed -i 's|kube_network_plugin: calico|kube_network_plugin: flannel|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@admin-lb:~/kubespray# sed -i 's|kube_proxy_mode: ipvs|kube_proxy_mode: iptables|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@admin-lb:~/kubespray# sed -i 's|enable_nodelocaldns: true|enable_nodelocaldns: false|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@admin-lb:~/kubespray# grep -iE 'kube_owner|kube_network_plugin:|kube_proxy_mode|enable_nodelocaldns:' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
kube_owner: root
kube_network_plugin: flannel
kube_proxy_mode: iptables
enable_nodelocaldns: false
root@admin-lb:~/kubespray# echo "enable_dns_autoscaler: false" >> inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@admin-lb:~/kubespray# echo "flannel_interface: enp0s9" >> inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
root@admin-lb:~/kubespray# grep "^[^#]" inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
flannel_interface: enp0s9
root@admin-lb:~/kubespray# sed -i 's|metrics_server_enabled: false|metrics_server_enabled: true|g' inventory/mycluster/group_vars/k8s_cluster/addons.yml
root@admin-lb:~/kubespray# grep -iE 'metrics_server_enabled:' inventory/mycluster/group_vars/k8s_cluster/addons.yml
metrics_server_enabled: true
root@admin-lb:~/kubespray# echo "metrics_server_requests_cpu: 25m"     >> inventory/mycluster/group_vars/k8s_cluster/addons.yml
root@admin-lb:~/kubespray# echo "metrics_server_requests_memory: 16Mi" >> inventory/mycluster/group_vars/k8s_cluster/addons.yml
root@admin-lb:~/kubespray# cat roles/kubespray_defaults/vars/main/checksums.yml | grep -i kube -A40
kubelet_checksums:
  arm64:
    1.33.7: sha256:3035c44e0d429946d6b4b66c593d371cf5bbbfc85df39d7e2a03c422e4fe404a
    1.33.6: sha256:7d8b7c63309cfe2da2331a1ae13cce070b9ba01e487099e7881a4281667c131d

root@admin-lb:~/kubespray# ANSIBLE_FORCE_COLOR=true ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml -e kube_version="1.32.9" | tee kubespray_install.log
                                                                                .
                                                                                .
                                                                                .
Wednesday 04 February 2026  10:49:23 +0900 (0:00:00.043)       0:08:56.430 ****
===============================================================================
system_packages : Manage packages ------------------------------------- 106.28s
kubernetes/kubeadm : Join to cluster if needed ------------------------- 22.68s
download : Download_file | Download item ------------------------------- 16.14s
download : Download_file | Download item ------------------------------- 15.23s
download : Download_file | Download item ------------------------------- 14.49s
download : Download_file | Download item ------------------------------- 14.25s
container-engine/containerd : Download_file | Download item ------------ 13.63s
download : Download_container | Download image if required ------------- 13.49s
download : Download_container | Download image if required ------------- 13.32s
download : Download_container | Download image if required ------------- 12.83s
download : Download_container | Download image if required ------------- 12.62s
container-engine/crictl : Download_file | Download item ---------------- 11.10s
download : Download_container | Download image if required ------------- 10.18s
container-engine/runc : Download_file | Download item ------------------- 9.95s
download : Download_container | Download image if required -------------- 9.56s
download : Download_container | Download image if required -------------- 9.27s
container-engine/nerdctl : Download_file | Download item ---------------- 9.26s
kubernetes/control-plane : Joining control plane node to the cluster. --- 8.97s
download : Download_file | Download item -------------------------------- 8.25s
download : Download_file | Download item -------------------------------- 7.91s

root@admin-lb:~/kubespray# tree /tmp/
/tmp/
├── k8s-node1
├── k8s-node2
├── k8s-node3
├── k8s-node4
├── k8s-node5
├── k9s_linux_arm64.tar.gz
├── k9s_linux_arm64.tar.gz.1
├── LICENSE
├── README.md
├── systemd-private-0fed2a33a5284513bc7e6d84016170ad-chronyd.service-1oIvH2
│   └── tmp
├── systemd-private-0fed2a33a5284513bc7e6d84016170ad-dbus-broker.service-5V53JE
│   └── tmp
├── systemd-private-0fed2a33a5284513bc7e6d84016170ad-irqbalance.service-Bvj3Gc
│   └── tmp
├── systemd-private-0fed2a33a5284513bc7e6d84016170ad-polkit.service-SBFN4q
│   └── tmp
├── systemd-private-0fed2a33a5284513bc7e6d84016170ad-systemd-logind.service-eYQyW3
│   └── tmp
└── vagrant-shell

11 directories, 10 files
root@admin-lb:~/kubespray# ssh k8s-node1 tree /tmp/releases
/tmp/releases
├── cni-plugins-linux-arm64-1.8.0.tgz
├── containerd-2.1.5-linux-arm64.tar.gz
├── containerd-rootless-setuptool.sh
├── containerd-rootless.sh
├── crictl
├── crictl-1.32.0-linux-arm64.tar.gz
├── etcd-3.5.25-linux-arm64.tar.gz
├── etcd-v3.5.25-linux-arm64
│   ├── Documentation
│   │   ├── dev-guide
│   │   │   └── apispec
│   │   │       └── swagger
│   │   │           ├── rpc.swagger.json
│   │   │           ├── v3election.swagger.json
│   │   │           └── v3lock.swagger.json
│   │   └── README.md
│   ├── etcd
│   ├── etcdctl
│   ├── etcdutl
│   ├── README-etcdctl.md
│   ├── README-etcdutl.md
│   ├── README.md
│   └── READMEv2-etcdctl.md
├── images
├── kubeadm-1.32.9-arm64
├── kubectl-1.32.9-arm64
├── kubelet-1.32.9-arm64
├── nerdctl
├── nerdctl-2.1.6-linux-arm64.tar.gz
└── runc-1.3.4.arm64

7 directories, 24 files

## ETCD backup 확인
root@admin-lb:~/kubespray# for i in {1..3}; do echo ">> k8s-node$i <<"; ssh k8s-node$i tree /var/backups; echo; done
>> k8s-node1 <<
/var/backups
└── etcd-2026-02-04_10:55:41
    ├── member
    │   ├── snap
    │   │   └── db
    │   └── wal
    │       └── 0000000000000000-0000000000000000.wal
    └── snapshot.db

5 directories, 3 files

>> k8s-node2 <<
/var/backups
└── etcd-2026-02-04_10:55:40
    ├── member
    │   ├── snap
    │   │   └── db
    │   └── wal
    │       └── 0000000000000000-0000000000000000.wal
    └── snapshot.db

5 directories, 3 files

>> k8s-node3 <<
/var/backups
└── etcd-2026-02-04_10:55:41
    ├── member
    │   ├── snap
    │   │   └── db
    │   └── wal
    │       └── 0000000000000000-0000000000000000.wal
    └── snapshot.db

5 directories, 3 files

## k8s 호출 확인
root@admin-lb:~/kubespray# for i in {1..3}; do echo ">> k8s-node$i <<"; curl -sk https://192.168.10.1$i:6443/version | grep Version; echo; done
>> k8s-node1 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

>> k8s-node2 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

>> k8s-node3 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

root@admin-lb:~/kubespray# for i in {1..3}; do echo ">> k8s-node$i <<"; curl -sk https://k8s-node$i:6443/version | grep Version; echo; done
>> k8s-node1 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

>> k8s-node2 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

>> k8s-node3 <<
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

  ## k8s 자격증명 확인
root@admin-lb:~/kubespray# for i in {1..3}; do echo ">> k8s-node$i <<"; ssh k8s-node$i kubectl cluster-info -v=6; echo; done
>> k8s-node1 <<
I0204 11:00:47.227034   29567 loader.go:402] Config loaded from file:  /root/.kube/config
I0204 11:00:47.227368   29567 envvar.go:172] "Feature gate default state" feature="ClientsPreferCBOR" enabled=false
I0204 11:00:47.227378   29567 envvar.go:172] "Feature gate default state" feature="InformerResourceVersion" enabled=false
I0204 11:00:47.227380   29567 envvar.go:172] "Feature gate default state" feature="WatchListClient" enabled=false
I0204 11:00:47.227381   29567 envvar.go:172] "Feature gate default state" feature="ClientsAllowCBOR" enabled=false
I0204 11:00:47.235211   29567 round_trippers.go:560] GET https://127.0.0.1:6443/api/v1/namespaces/kube-system/services?labelSelector=kubernetes.io%2Fcluster-service%3Dtrue 200 OK in 5 milliseconds
Kubernetes control plane is running at https://127.0.0.1:6443

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

>> k8s-node2 <<
I0204 11:00:47.479391   28901 loader.go:402] Config loaded from file:  /root/.kube/config
I0204 11:00:47.479691   28901 envvar.go:172] "Feature gate default state" feature="ClientsAllowCBOR" enabled=false
I0204 11:00:47.479700   28901 envvar.go:172] "Feature gate default state" feature="ClientsPreferCBOR" enabled=false
I0204 11:00:47.479703   28901 envvar.go:172] "Feature gate default state" feature="InformerResourceVersion" enabled=false
I0204 11:00:47.479704   28901 envvar.go:172] "Feature gate default state" feature="WatchListClient" enabled=false
I0204 11:00:47.483018   28901 round_trippers.go:560] GET https://127.0.0.1:6443/api?timeout=32s 200 OK in 3 milliseconds
I0204 11:00:47.484053   28901 round_trippers.go:560] GET https://127.0.0.1:6443/apis?timeout=32s 200 OK in 0 milliseconds
I0204 11:00:47.490292   28901 round_trippers.go:560] GET https://127.0.0.1:6443/api/v1/namespaces/kube-system/services?labelSelector=kubernetes.io%2Fcluster-service%3Dtrue 200 OK in 3 milliseconds
Kubernetes control plane is running at https://127.0.0.1:6443

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

>> k8s-node3 <<
I0204 11:00:47.714411   28937 loader.go:402] Config loaded from file:  /root/.kube/config
I0204 11:00:47.714828   28937 envvar.go:172] "Feature gate default state" feature="ClientsAllowCBOR" enabled=false
I0204 11:00:47.714839   28937 envvar.go:172] "Feature gate default state" feature="ClientsPreferCBOR" enabled=false
I0204 11:00:47.714841   28937 envvar.go:172] "Feature gate default state" feature="InformerResourceVersion" enabled=false
I0204 11:00:47.714843   28937 envvar.go:172] "Feature gate default state" feature="WatchListClient" enabled=false
I0204 11:00:47.721851   28937 round_trippers.go:560] GET https://127.0.0.1:6443/api/v1/namespaces/kube-system/services?labelSelector=kubernetes.io%2Fcluster-service%3Dtrue 200 OK in 5 milliseconds
Kubernetes control plane is running at https://127.0.0.1:6443

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

root@admin-lb:~/kubespray# mkdir /root/.kube
root@admin-lb:~/kubespray# scp k8s-node1:/root/.kube/config /root/.kube/
config                                                                                                                       100% 5661     6.7MB/s   00:00
root@admin-lb:~/kubespray# cat /root/.kube/config | grep server
    server: https://127.0.0.1:6443

root@admin-lb:~/kubespray# ssh k8s-node1 etcdctl.sh member list -w table
+------------------+---------+-------+----------------------------+----------------------------+------------+
|        ID        | STATUS  | NAME  |         PEER ADDRS         |        CLIENT ADDRS        | IS LEARNER |
+------------------+---------+-------+----------------------------+----------------------------+------------+
|  8b0ca30665374b0 | started | etcd3 | https://192.168.10.13:2380 | https://192.168.10.13:2379 |      false |
| 2106626b12a4099f | started | etcd2 | https://192.168.10.12:2380 | https://192.168.10.12:2379 |      false |
| c6702130d82d740f | started | etcd1 | https://192.168.10.11:2380 | https://192.168.10.11:2379 |      false |
+------------------+---------+-------+----------------------------+----------------------------+------------+
root@admin-lb:~/kubespray# for i in {1..3}; do echo ">> k8s-node$i <<"; ssh k8s-node$i etcdctl.sh endpoint status -w table; echo; done
>> k8s-node1 <<
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|    ENDPOINT    |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 127.0.0.1:2379 | c6702130d82d740f |  3.5.25 |  6.3 MB |      true |      false |         4 |       3103 |               3103 |        |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

>> k8s-node2 <<
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|    ENDPOINT    |        ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 127.0.0.1:2379 | 2106626b12a4099f |  3.5.25 |  6.3 MB |     false |      false |         4 |       3103 |               3103 |        |
+----------------+------------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

>> k8s-node3 <<
+----------------+-----------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
|    ENDPOINT    |       ID        | VERSION | DB SIZE | IS LEADER | IS LEARNER | RAFT TERM | RAFT INDEX | RAFT APPLIED INDEX | ERRORS |
+----------------+-----------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+
| 127.0.0.1:2379 | 8b0ca30665374b0 |  3.5.25 |  6.3 MB |     false |      false |         4 |       3103 |               3103 |        |
+----------------+-----------------+---------+---------+-----------+------------+-----------+------------+--------------------+--------+

환경 설정 확인

root@admin-lb:~/kubespray# kubectl get svc -n kube-system coredns
NAME      TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)                  AGE
coredns   ClusterIP   10.233.0.3   <none>        53/UDP,53/TCP,9153/TCP   65m

root@admin-lb:~/kubespray# kubectl get cm -n kube-system kubelet-config -o yaml | grep clusterDNS -A2
    clusterDNS:
    - 10.233.0.3
    clusterDomain: cluster.local

root@admin-lb:~/kubespray# kubectl get svc,ep -n kube-system
NAME                     TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)                  AGE
service/coredns          ClusterIP   10.233.0.3     <none>        53/UDP,53/TCP,9153/TCP   66m
service/metrics-server   ClusterIP   10.233.53.50   <none>        443/TCP                  66m

NAME                       ENDPOINTS                                                  AGE
endpoints/coredns          10.233.65.2:53,10.233.66.2:53,10.233.65.2:53 + 3 more...   66m
endpoints/metrics-server   10.233.66.3:10250                                          66m

root@admin-lb:~/kubespray# ssh k8s-node4 curl -sk https://127.0.0.1:6443/version | grep Version
  "gitVersion": "v1.32.9",
  "goVersion": "go1.23.12",

  root@admin-lb:~/kubespray# ssh k8s-node4 ss -tnlp | grep nginx
LISTEN 0      511        127.0.0.1:6443       0.0.0.0:*    users:(("nginx",pid=17935,fd=5),("nginx",pid=17934,fd=5),("nginx",pid=17904,fd=5))
LISTEN 0      511          0.0.0.0:8081       0.0.0.0:*    users:(("nginx",pid=17935,fd=6),("nginx",pid=17934,fd=6),("nginx",pid=17904,fd=6))

Control plane node component → k8s api enpoint 분석

root@admin-lb:~/kubespray# kubectl describe pod -n kube-system kube-apiserver-k8s-node1 | grep -E 'address|secure-port'
Annotations:          kubeadm.kubernetes.io/kube-apiserver.advertise-address.endpoint: 192.168.10.11:6443
      --advertise-address=192.168.10.11
      --bind-address=::
      --kubelet-preferred-address-types=InternalDNS,InternalIP,Hostname,ExternalDNS,ExternalIP
      --secure-port=6443

root@admin-lb:~/kubespray# kubectl get cm -n kube-system kube-proxy -o yaml | grep server
        server: https://127.0.0.1:6443

External LB → HA control plane node ( 3대 ) + Worker Client-Side LoadBalancing )

root@admin-lb:~/kubespray# helm install kube-ops-view geek-cookbook/kube-ops-view --version 1.2.2 \
  --set service.main.type=NodePort,service.main.ports.http.nodePort=30000 \
  --set env.TZ="Asia/Seoul" --namespace kube-system \
  --set image.repository="abihf/kube-ops-view" --set image.tag="latest"

NAME: kube-ops-view
LAST DEPLOYED: Wed Feb  4 12:13:20 2026
NAMESPACE: kube-system
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:
1. Get the application URL by running these commands:
  export NODE_PORT=$(kubectl get --namespace kube-system -o jsonpath="{.spec.ports[0].nodePort}" services kube-ops-view)
  export NODE_IP=$(kubectl get nodes --namespace kube-system -o jsonpath="{.items[0].status.addresses[0].address}")
  echo http://$NODE_IP:$NODE_PORT

 root@admin-lb:~/kubespray# kubectl get deploy,pod,svc,ep -n kube-system -l app.kubernetes.io/instance=kube-ops-view
NAME                            READY   UP-TO-DATE   AVAILABLE   AGE
deployment.apps/kube-ops-view   1/1     1            1           35s

NAME                                 READY   STATUS    RESTARTS   AGE
pod/kube-ops-view-8484bdc5df-cfb22   1/1     Running   0          35s

NAME                    TYPE       CLUSTER-IP      EXTERNAL-IP   PORT(S)          AGE
service/kube-ops-view   NodePort   10.233.59.124   <none>        8080:30000/TCP   35s

NAME                      ENDPOINTS          AGE
endpoints/kube-ops-view   10.233.66.4:8080   35s

root@admin-lb:~/kubespray# kubectl get deploy,svc,ep webpod -owide
NAME                     READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES           SELECTOR
deployment.apps/webpod   2/2     2            2           77m   webpod       traefik/whoami   app=webpod

NAME             TYPE       CLUSTER-IP     EXTERNAL-IP   PORT(S)        AGE   SELECTOR
service/webpod   NodePort   10.233.51.23   <none>        80:30003/TCP   77m   app=webpod

NAME               ENDPOINTS                       AGE
endpoints/webpod   10.233.66.5:80,10.233.66.6:80   77m

root@admin-lb:~/kubespray# ssh k8s-node1 curl -s webpod -I
HTTP/1.1 200 OK
Date: Wed, 04 Feb 2026 04:49:40 GMT
Content-Length: 202
Content-Type: text/plain; charset=utf-8

root@admin-lb:~/kubespray# ssh k8s-node1 curl -s webpod.default -I
HTTP/1.1 200 OK
Date: Wed, 04 Feb 2026 04:49:59 GMT
Content-Length: 210
Content-Type: text/plain; charset=utf-8

( 장애 재현 ) 만약 컨트롤 플레인 1번 노드 장애 발생시 영향도

a. Terminal * 4EA로 모니터링

root@k8s-node1:~# poweroff
root@k8s-node1:~# Connection to k8s-node1 closed by remote host.
Connection to k8s-node1 closed.

root@admin-lb:~/kubespray# while true; do kubectl get node ; echo ; curl -sk https://192.168.10.12:6443/version | grep gitVersion ; sleep 1; echo ; done
Unable to connect to the server: dial tcp 192.168.10.11:6443: connect: no route to host
                                                                        .
                                                                        .
                                                                        .
nable to connect to the server: dial tcp 192.168.10.11:6443: connect: no route to host

  "gitVersion": "v1.32.9",

root@admin-lb:~/kubespray# ^C
root@admin-lb:~/kubespray# sed -i 's/192.168.10.11/192.168.10.12/g' /root/.kube/config
root@admin-lb:~/kubespray# while true; do kubectl get node ; echo ; curl -sk https://192.168.10.12:6443/version | grep gitVersion ; sleep 1; echo ; done
NAME        STATUS     ROLES           AGE    VERSION
k8s-node1   NotReady   control-plane   3h6m   v1.32.9
k8s-node2   Ready      control-plane   3h6m   v1.32.9
k8s-node3   Ready      control-plane   3h6m   v1.32.9
k8s-node4   Ready      <none>          3h6m   v1.32.9

b. VirtualBox에서 k8s-node1 머신 시작

External LB → HA 컨트롤플레인 노드 ( 3대 ) : k8s apiserver 호출 설정

root@admin-lb:~/kubespray# curl -sk https://192.168.10.10:6443/version | grep gitVersion
  "gitVersion": "v1.32.9",
root@admin-lb:~/kubespray# sed -i 's/192.168.10.12/192.168.10.10/g' /root/.kube/config

root@admin-lb:~/kubespray# kubectl get node
E0204 14:08:19.726144   21183 memcache.go:265] "Unhandled Error" err="couldn't get current server API group list: Get \"https://192.168.10.10:6443/api?timeout=32s\": tls: failed to verify certificate: x509: certificate is valid for 10.233.0.1, 192.168.10.11, 127.0.0.1, ::1, 192.168.10.12, 192.168.10.13, 10.0.2.15, fd17:625c:f037:2:a00:27ff:fe90:eaeb, not 192.168.10.10"

root@admin-lb:~/kubespray# ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "control-plane" --list-tasks
Using /root/kubespray/ansible.cfg as config file
[WARNING]: Could not match supplied host pattern, ignoring: bastion
[WARNING]: Could not match supplied host pattern, ignoring: k8s_cluster
[WARNING]: Could not match supplied host pattern, ignoring: calico_rr
[WARNING]: Could not match supplied host pattern, ignoring:
_kubespray_needs_etcd
                                                                            .
                                                                            .
                                                                            .
      kubernetes/preinstall : Create kubernetes directories   TAGS: [apps, bootstrap_os, control-plane, kube-apiserver, kube-controller-manager, kubelet, network, node, resolvconf]
      kubernetes/preinstall : Create other directories of root owner   TAGS: [apps, bootstrap_os, control-plane, kube-apiserver, kube-controller-manager, kubelet, network, node, resolvconf]

**ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "control-plane" --limit kube_control_plane -e kube_version="1.32.9"
                                                                            .
                                                                            .
                                                                            .
Gather necessary facts (network) ---------------------------------------- 0.23s
kubernetes/control-plane : Kubeadm | aggregate all SANs ----------------- 0.22s
etcd : Gen_certs | Get etcd certificate serials ------------------------- 0.19s

root@admin-lb:~/kubespray# kubectl get node -v=6
I0204 14:11:19.264116   23169 loader.go:402] Config loaded from file:  /root/.kube/config
I0204 14:11:19.264614   23169 envvar.go:172] "Feature gate default state" feature="ClientsAllowCBOR" enabled=false
I0204 14:11:19.264640   23169 envvar.go:172] "Feature gate default state" feature="ClientsPreferCBOR" enabled=false
I0204 14:11:19.264684   23169 envvar.go:172] "Feature gate default state" feature="InformerResourceVersion" enabled=false
I0204 14:11:19.264700   23169 envvar.go:172] "Feature gate default state" feature="WatchListClient" enabled=false
I0204 14:11:19.272759   23169 round_trippers.go:560] GET https://192.168.10.10:6443/api/v1/nodes?limit=500 200 OK in 5 milliseconds
NAME        STATUS   ROLES           AGE     VERSION
k8s-node1   Ready    control-plane   3h15m   v1.32.9
k8s-node2   Ready    control-plane   3h15m   v1.32.9
k8s-node3   Ready    control-plane   3h15m   v1.32.9
k8s-node4   Ready    <none>          3h14m   v1.32.9**

노드 관리

a. 노드 추가

root@admin-lb:~/kubespray# cat << EOF > /root/kubespray/inventory/mycluster/inventory.ini
[kube_control_plane]
k8s-node1 ansible_host=192.168.10.11 ip=192.168.10.11 etcd_member_name=etcd1
k8s-node2 ansible_host=192.168.10.12 ip=192.168.10.12 etcd_member_name=etcd2
k8s-node3 ansible_host=192.168.10.13 ip=192.168.10.13 etcd_member_name=etcd3

[etcd:children]
kube_control_plane

[kube_node]
k8s-node4 ansible_host=192.168.10.14 ip=192.168.10.14
k8s-node5 ansible_host=192.168.10.15 ip=192.168.10.15
EOF
root@admin-lb:~/kubespray# ansible-inventory -i /root/kubespray/inventory/mycluster/inventory.ini --graph
@all:
  |--@ungrouped:
  |--@etcd:
  |  |--@kube_control_plane:
  |  |  |--k8s-node1
  |  |  |--k8s-node2
  |  |  |--k8s-node3
  |--@kube_node:
  |  |--k8s-node4
  |  |--k8s-node5

  root@admin-lb:~/kubespray# ansible -i inventory/mycluster/inventory.ini k8s-node5 -m ping
k8s-node5 | SUCCESS => {
    "changed": false,
    "ping": "pong"
}

ansible-playbook -i inventory/mycluster/inventory.ini -v scale.yml --list-tasks
                                                                            .
                                                                            .
                                                                            .
      kubernetes/preinstall : Flush handlers    TAGS: [resolvconf]
      kubernetes/preinstall : Check if we are running inside a Azure VM        TAGS: [bootstrap_os, resolvconf]
      Run calico checks TAGS: [resolvconf]

ANSIBLE_FORCE_COLOR=true **ansible-playbook -i inventory/mycluster/inventory.ini -v scale.yml --limit=k8s-node5 -e kube_version="1.32.9" | tee kubespray_add_worker_node.log
                                                                            .
                                                                            .
                                                                            .
download : Extract_file | Unpacking archive ----------------------------- 1.50s
container-engine/nerdctl : Extract_file | Unpacking archive ------------- 1.38s
network_plugin/cni : CNI | Copy cni plugins ----------------------------- 1.21s

root@admin-lb:~/kubespray# kubectl get node -owide
NAME        STATUS   ROLES           AGE     VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                        KERNEL-VERSION                  CONTAINER-RUNTIME
k8s-node1   Ready    control-plane   3h43m   v1.32.9   192.168.10.11   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node2   Ready    control-plane   3h42m   v1.32.9   192.168.10.12   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node3   Ready    control-plane   3h42m   v1.32.9   192.168.10.13   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node4   Ready    <none>          3h42m   v1.32.9   192.168.10.14   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node5   Ready    <none>          46s     v1.32.9   192.168.10.15   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5

root@admin-lb:~/kubespray# kubectl get pod -n kube-system -owide | grep k8s-node5
kube-flannel-ds-arm64-rsd9r         1/1     Running   2 (63s ago)   68s     192.168.10.15   k8s-node5   <none>           <none>
kube-proxy-q4clq                    1/1     Running   0             68s     192.168.10.15   k8s-node5   <none>           <none>
nginx-proxy-k8s-node5               1/1     Running   0             67s     192.168.10.15   k8s-node5   <none>           <none>

root@admin-lb:~/kubespray# kubectl get pod -owide
NAME                      READY   STATUS    RESTARTS   AGE    IP            NODE        NOMINATED NODE   READINESS GATES
webpod-697b545f57-bhhvl   1/1     Running   0          130m   10.233.66.6   k8s-node4   <none>           <none>
webpod-697b545f57-hdq76   1/1     Running   0          130m   10.233.66.5   k8s-node4   <none>           <none>
root@admin-lb:~/kubespray# kubectl scale deployment webpod --replicas 1
deployment.apps/webpod scaled
root@admin-lb:~/kubespray# kubectl get pod -owide
NAME                      READY   STATUS    RESTARTS   AGE    IP            NODE        NOMINATED NODE   READINESS GATES
webpod-697b545f57-hdq76   1/1     Running   0          130m   10.233.66.5   k8s-node4   <none>           <none>
root@admin-lb:~/kubespray# kubectl scale deployment webpod --replicas 2
deployment.apps/webpod scaled
root@admin-lb:~/kubespray# kubectl get pod -owide
NAME                      READY   STATUS              RESTARTS   AGE    IP            NODE        NOMINATED NODE   READINESS GATES
webpod-697b545f57-2fdql   0/1     ContainerCreating   0          2s     <none>        k8s-node5   <none>           <none>
webpod-697b545f57-hdq76   1/1     Running             0          130m   10.233.66.5   k8s-node4   <none>           <none>**

b. 노드 제거

root@admin-lb:~/kubespray# cat <<EOF | kubectl apply -f -
apiVersion: policy/v1
kind: PodDisruptionBudget
metadata:
  name: webpod
  namespace: default
spec:
  maxUnavailable: 0
  selector:
    matchLabels:
      app: webpod
EOF
poddisruptionbudget.policy/webpod created
root@admin-lb:~/kubespray# kubectl get pdb
NAME     MIN AVAILABLE   MAX UNAVAILABLE   ALLOWED DISRUPTIONS   AGE
webpod   N/A             0                 0                     4s

ansible-playbook -i inventory/mycluster/inventory.ini -v remove-node.yml --list-tags
**ansible-playbook -i inventory/mycluster/inventory.ini -v remove-node.yml -e node=k8s-node5

cat << EOF > /root/kubespray/inventory/mycluster/inventory.ini**
*[**kube_control_plane**]
k8s-node1 ansible_host=192.168.10.11 ip=192.168.10.11 etcd_member_name=etcd1
k8s-node2 ansible_host=192.168.10.12 ip=192.168.10.12 etcd_member_name=etcd2
k8s-node3 ansible_host=192.168.10.13 ip=192.168.10.13 etcd_member_name=etcd3

[**etcd**:children]
kube_control_plane

[**kube_node**]
k8s-node4 ansible_host=192.168.10.14 ip=192.168.10.14
**k8s-node5 ansible_host=192.168.10.15 ip=192.168.10.15***
EOF

****ANSIBLE_FORCE_COLOR=true **ansible-playbook -i inventory/mycluster/inventory.ini -v scale.yml --limit=k8s-node5 -e kube_version="1.32.9" | tee kubespray_add_worker_node.log

root@admin-lb:~/kubespray# kubectl get node -owide
NAME        STATUS                     ROLES           AGE     VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                        KERNEL-VERSION                  CONTAINER-RUNTIME
k8s-node1   Ready                      control-plane   4h51m   v1.32.9   192.168.10.11   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node2   Ready                      control-plane   4h51m   v1.32.9   192.168.10.12   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node3   Ready                      control-plane   4h51m   v1.32.9   192.168.10.13   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node4   Ready                      <none>          4h51m   v1.32.9   192.168.10.14   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node5   Ready,SchedulingDisabled   <none>          69m     v1.32.9   192.168.10.15   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5

root@admin-lb:~/kubespray# kubectl scale deployment webpod --replicas 1
deployment.apps/webpod scaled

root@admin-lb:~/kubespray# kubectl get node -owide
NAME        STATUS                     ROLES           AGE     VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                        KERNEL-VERSION                  CONTAINER-RUNTIME
k8s-node1   Ready                      control-plane   4h52m   v1.32.9   192.168.10.11   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node2   Ready                      control-plane   4h52m   v1.32.9   192.168.10.12   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node3   Ready                      control-plane   4h52m   v1.32.9   192.168.10.13   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node4   Ready                      <none>          4h52m   v1.32.9   192.168.10.14   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node5   Ready,SchedulingDisabled   <none>          70m     v1.32.9   192.168.10.15   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5

root@admin-lb:~/kubespray# kubectl scale deployment webpod --replicas 2
deployment.apps/webpod scaled**

모니터링 설정

root@admin-lb:~/kubespray# kubectl create ns nfs-provisioner
namespace/nfs-provisioner created
root@admin-lb:~/kubespray# helm repo add nfs-subdir-external-provisioner https://kubernetes-sigs.github.io/nfs-subdir-external-provisioner/
"nfs-subdir-external-provisioner" has been added to your repositories
root@admin-lb:~/kubespray# helm install nfs-provisioner nfs-subdir-external-provisioner/nfs-subdir-external-provisioner -n nfs-provisioner \
    --set nfs.server=192.168.10.10 \
    --set nfs.path=/srv/nfs/share \
    --set storageClass.defaultClass=true
NAME: nfs-provisioner
LAST DEPLOYED: Wed Feb  4 17:31:58 2026
NAMESPACE: nfs-provisioner
STATUS: deployed
REVISION: 1
TEST SUITE: None
root@admin-lb:~/kubespray# kubectl get sc
NAME                   PROVISIONER                                                     RECLAIMPOLICY   VOLUMEBINDINGMODE   ALLOWVOLUMEEXPANSION   AGE
nfs-client (default)   cluster.local/nfs-provisioner-nfs-subdir-external-provisioner   Delete          Immediate           true                   43s
root@admin-lb:~/kubespray# kubectl get pod -n nfs-provisioner -owide
NAME                                                              READY   STATUS    RESTARTS   AGE   IP            NODE        NOMINATED NODE   READINESS GATES
nfs-provisioner-nfs-subdir-external-provisioner-b549b9dff-l25n2   1/1     Running   0          79s   10.233.66.8   k8s-node4   <none>           <none>

root@admin-lb:~/kubespray# helm repo add prometheus-community https://prometheus-community.github.io/helm-charts
"prometheus-community" has been added to your repositories
root@admin-lb:~/kubespray# cat <<EOT > monitor-values.yaml
prometheus:
  prometheusSpec:
    scrapeInterval: "20s"
    evaluationInterval: "20s"
    storageSpec:
      volumeClaimTemplate:
        spec:
          accessModes: ["ReadWriteOnce"]
          resources:
            requests:
              storage: 10Gi
    additionalScrapeConfigs:
      - job_name: 'haproxy-metrics'
        static_configs:
          - targets:
              - '192.168.10.10:8405'
    externalLabels:
      cluster: "myk8s-cluster"
  service:
    type: NodePort
    nodePort: 30001

grafana:
  defaultDashboardsTimezone: Asia/Seoul
  adminPassword: prom-operator
  service:
    type: NodePort
    nodePort: 30002

alertmanager:
  enabled: false
defaultRules:
  create: false
kubeProxy:
  enabled: false
prometheus-windows-exporter:
  prometheus:
    monitor:
      enabled: false
EOT

helm install kube-prometheus-stack prometheus-community/kube-prometheus-stack --version **80.13.3** \
-f **monitor-values.yaml** --create-namespace --namespace **monitoring**

root@admin-lb:~/kubespray# kubectl exec -it sts/prometheus-kube-prometheus-stack-prometheus -n monitoring -c prometheus -- prometheus --version
prometheus, version 3.9.1 (branch: HEAD, revision: 9ec59baffb547e24f1468a53eb82901e58feabd8)
  build user:       root@61c3a9212c9e
  build date:       20260107-16:11:39
  go version:       go1.25.5
  platform:         linux/arm64
  tags:             netgo,builtinassets

root@admin-lb:~/kubespray# sed -i -e 's/${DS_PROMETHEUS}/prometheus/g' 12693_rev12.json
root@admin-lb:~/kubespray# sed -i -e 's/${DS__VICTORIAMETRICS-PROD-ALL}/prometheus/g' 15661_rev2.json
root@admin-lb:~/kubespray# sed -i -e 's/${DS_PROMETHEUS}/prometheus/g' k8s-system-api-server.json

root@admin-lb:~/kubespray# kubectl create configmap my-dashboard  --from-file=12693_rev12.json --from-file=15661_rev2.json --from-file=k8s-system-api-server.json -n monitoring
configmap/my-dashboard created
root@admin-lb:~/kubespray# kubectl label configmap my-dashboard grafana_dashboard="1" -n monitoring
configmap/my-dashboard labeled
root@admin-lb:~/kubespray# kubectl exec -it -n monitoring deploy/kube-prometheus-stack-grafana -- ls -l /tmp/dashboards
error: cannot exec into a container in a completed pod; current phase is Succeeded

root@admin-lb:~/kubespray# cat << EOF >> inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
etcd_metrics: true
etcd_listen_metrics_urls: "http://0.0.0.0:2381"
EOF

ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "etcd" --list-tasks
**ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "etcd" --limit etcd -e kube_version="1.32.9"**

root@admin-lb:~/kubespray# ssh k8s-node1 etcdctl.sh member list -w table
+------------------+---------+-------+----------------------------+----------------------------+------------+
|        ID        | STATUS  | NAME  |         PEER ADDRS         |        CLIENT ADDRS        | IS LEARNER |
+------------------+---------+-------+----------------------------+----------------------------+------------+
|  8b0ca30665374b0 | started | etcd3 | https://192.168.10.13:2380 | https://192.168.10.13:2379 |      false |
| 2106626b12a4099f | started | etcd2 | https://192.168.10.12:2380 | https://192.168.10.12:2379 |      false |
| c6702130d82d740f | started | etcd1 | https://192.168.10.11:2380 | https://192.168.10.11:2379 |      false |
+------------------+---------+-------+----------------------------+----------------------------+------------+

root@admin-lb:~/kubespray# helm upgrade kube-prometheus-stack prometheus-community/kube-prometheus-stack --version 80.13.3 \
--reuse-values -f monitor-add-values.yaml --namespace monitoring

root@admin-lb:~/kubespray# helm upgrade kube-prometheus-stack prometheus-community/kube-prometheus-stack --version 80.13.3 \
--reuse-values -f monitor-add-values.yaml --namespace monitoring
Release "kube-prometheus-stack" has been upgraded. Happy Helming!
NAME: kube-prometheus-stack
LAST DEPLOYED: Wed Feb  4 17:45:41 2026
NAMESPACE: monitoring
STATUS: deployed
REVISION: 2
NOTES:
kube-prometheus-stack has been installed. Check its status by running:
  kubectl --namespace monitoring get pods -l "release=kube-prometheus-stack"

Get Grafana 'admin' user password by running:

  kubectl --namespace monitoring get secrets kube-prometheus-stack-grafana -o jsonpath="{.data.admin-password}" | base64 -d ; echo

Access Grafana local instance:

  export POD_NAME=$(kubectl --namespace monitoring get pod -l "app.kubernetes.io/name=grafana,app.kubernetes.io/instance=kube-prometheus-stack" -oname)
  kubectl --namespace monitoring port-forward $POD_NAME 3000

Get your grafana admin user password by running:

  kubectl get secret --namespace monitoring -l app.kubernetes.io/component=admin-secret -o jsonpath="{.items[0].data.admin-password}" | base64 --decode ; echo

Visit https://github.com/prometheus-operator/kube-prometheus for instructions on how to create & configure Alertmanager and Prometheus instances using the Operator.

업그레이드

# 관련 변수 검색
grep -Rni "flannel" inventory/mycluster/ playbooks/ roles/ --include="*.yml" -A2 -B1
                                                                            .
                                                                            .
                                                                            .
roles/validate_inventory/tasks/main.yml-169-    that:
roles/validate_inventory/tasks/main.yml:170:      - kube_network_plugin in ['calico', 'flannel', 'cloud', 'cilium', 'cni', 'kube-ovn', 'kube-router', 'macvlan', 'custom_cni', 'none']
roles/validate_inventory/tasks/main.yml-171-      - dns_mode in ['coredns', 'coredns_dual', 'manual', 'none']
roles/validate_inventory/tasks/main.yml-172-      - kube_proxy_mode in ['iptables', 'ipvs', 'nftables']

root@admin-lb:~/kubespray# kubectl get ds -n kube-system -owide
NAME                      DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE   CONTAINERS     IMAGES                               SELECTOR
kube-flannel              0         0         0       0            0           <none>                   22h   kube-flannel   docker.io/flannel/flannel:v0.27.3    app=flannel
kube-flannel-ds-arm       0         0         0       0            0           <none>                   22h   kube-flannel   docker.io/flannel/flannel:v0.27.3    app=flannel
kube-flannel-ds-arm64     5         5         5       5            5           <none>                   22h   kube-flannel   docker.io/flannel/flannel:v0.27.3    app=flannel
kube-flannel-ds-ppc64le   0         0         0       0            0           <none>                   22h   kube-flannel   docker.io/flannel/flannel:v0.27.3    app=flannel
kube-flannel-ds-s390x     0         0         0       0            0           <none>                   22h   kube-flannel   docker.io/flannel/flannel:v0.27.3    app=flannel
kube-proxy                5         5         5       5            5           kubernetes.io/os=linux   22h   kube-proxy     registry.k8s.io/kube-proxy:v1.32.9   k8s-app=kube-proxy

root@admin-lb:~/kubespray# cat << EOF >> inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
flannel_version: 0.27.4
EOF
root@admin-lb:~/kubespray# grep "^[^#]" inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
flannel_interface: enp0s9
flannel_version: 0.27.4

ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml --tags "flannel" --list-tasks
**ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml --tags "flannel" --limit k8s-node3 -e kube_version="1.32.9"**

**ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml --tags "flannel" -e kube_version="1.32.9"

root@admin-lb:~/kubespray# kubectl get ds -n kube-system -owide
NAME                      DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE   CONTAINERS     IMAGES                               SELECTOR
kube-flannel              0         0         0       0            0           <none>                   28h   kube-flannel   docker.io/flannel/flannel:v0.27.4    app=flannel
kube-flannel-ds-arm       0         0         0       0            0           <none>                   28h   kube-flannel   docker.io/flannel/flannel:v0.27.4    app=flannel
kube-flannel-ds-arm64     5         5         4       4            4           <none>                   28h   kube-flannel   docker.io/flannel/flannel:v0.27.4    app=flannel
kube-flannel-ds-ppc64le   0         0         0       0            0           <none>                   28h   kube-flannel   docker.io/flannel/flannel:v0.27.4    app=flannel
kube-flannel-ds-s390x     0         0         0       0            0           <none>                   28h   kube-flannel   docker.io/flannel/flannel:v0.27.4    app=flannel
kube-proxy                5         5         5       5            5           kubernetes.io/os=linux   28h   kube-proxy     registry.k8s.io/kube-proxy:v1.32.9   k8s-app=kube-proxy

root@admin-lb:~/kubespray# kubectl get pod -n kube-system -l app=flannel -owide
NAME                          READY   STATUS    RESTARTS   AGE    IP              NODE        NOMINATED NODE   READINESS GATES
kube-flannel-ds-arm64-5v4wx   1/1     Running   0          71s    192.168.10.11   k8s-node1   <none>           <none>
kube-flannel-ds-arm64-62btm   1/1     Running   0          94s    192.168.10.12   k8s-node2   <none>           <none>
kube-flannel-ds-arm64-6xvwt   1/1     Running   0          61s    192.168.10.13   k8s-node3   <none>           <none>
kube-flannel-ds-arm64-mqpgb   1/1     Running   0          106s   192.168.10.15   k8s-node5   <none>           <none>
kube-flannel-ds-arm64-xlkdc   1/1     Running   0          83s    192.168.10.14   k8s-node4   <none>           <none>**

# limit 사용 전 모든 노드의 facts 캐시 최신화
ansible-playbook playbooks/facts.yml -b -i inventory/sample/hosts.ini

# 컨트롤 플레인
ansible-playbook upgrade-cluster.yml -b -i inventory/sample/hosts.ini -e kube_version=1.20.7 --limit "kube_control_plane:etcd"

# 워커 노드
ansible-playbook upgrade-cluster.yml -b -i inventory/sample/hosts.ini -e kube_version=1.20.7 --limit "node4:node6:node7:node12"
ansible-playbook upgrade-cluster.yml -b -i inventory/sample/hosts.ini -e kube_version=1.20.7 --limit "node5*"

# 워컨 노드 1번에 1대의 노드만 업그레이드
ansible-playbook upgrade-cluster.yml -b -i inventory/sample/hosts.ini -e kube_version=1.20.7 **-e "serial=1"**

10-1. k8s upgrade : 1.32.9 → 1.32.10

ANSIBLE_FORCE_COLOR=true **ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml -e kube_version="1.32.10" --limit "kube_control_plane:etcd"** **| tee kubespray_upgrade.log
                                                            .
                                                            .
                                                            .
download : Download_file | Download item -------------------------------- 7.85s
network_plugin/cni : CNI | Copy cni plugins ----------------------------- 7.61s
etcd : Gen_certs | Write etcd member/admin and kube_control_plane client certs to other etcd nodes --- 6.91s
network_plugin/cni : CNI | Copy cni plugins ----------------------------- 6.61s
system_packages : Manage packages --------------------------------------- 6.53s
container-engine/containerd : Containerd | Unpack containerd archive ---- 5.73s
download : Prep_kubeadm_images | Copy kubeadm binary from download dir to system path --- 4.90s

root@admin-lb:~/kubespray# kubectl get node -owide
NAME        STATUS                     ROLES           AGE   VERSION    INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                        KERNEL-VERSION                  CONTAINER-RUNTIME
k8s-node1   Ready                      control-plane   29h   v1.32.10   192.168.10.11   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node2   Ready                      control-plane   29h   v1.32.10   192.168.10.12   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node3   Ready                      control-plane   29h   v1.32.10   192.168.10.13   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node4   Ready                      <none>          29h   v1.32.9    192.168.10.14   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5
k8s-node5   Ready,SchedulingDisabled   <none>          25h   v1.32.9    192.168.10.15   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.aarch64   containerd://2.1.5**

ansible-playbook upgrade-cluster.yml -b -i inventory/sample/hosts.ini -e kube_version=1.20.7 **-e "serial=1"
# wk upgrade 2분 + 2분 소요 : (최초 한번) kube-proxy ds all node 재기동??? 1.32.9 → 1.32.10
ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml -e kube_version="1.32.10" --limit "k8s-node5"**
# 확인 후 나머지 노드 실행
**ansible-playbook -i inventory/mycluster/inventory.ini -v upgrade-cluster.yml -e kube_version="1.32.10" --limit "k8s-node4"

TASK [upgrade/pre-upgrade : Cordon node] ***************************************
changed: [k8s-node4 -> k8s-node1(192.168.10.11)] => {"changed": true, "cmd": ["/usr/local/bin/kubectl", "--kubeconfig", "/etc/kubernetes/admin.conf", "cordon", "k8s-node4"], "delta": "0:00:00.073049", "end": "2026-02-05 16:14:18.040359", "msg": "", "rc": 0, "start": "2026-02-05 16:14:17.967310", "stderr": "", "stderr_lines": [], "stdout": "node/k8s-node4 cordoned", "stdout_lines": ["node/k8s-node4 cordoned"]}
Thursday 05 February 2026  15:55:32 +0900 (0:00:00.245)       0:01:00.392 *****
                                                        .
                                                        .
                                                        .**

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 7주차 과제 (0)	2026.02.18
K8S ) 6주차 과제 (1)	2026.02.13
K8S) 4주차 과제 (0)	2026.01.31
K8S)3주차 과제 (0)	2026.01.24
K8S)2주차 과제 (0)	2026.01.15

K8S) 4주차 과제

zosys 2026. 1. 31. 11:02

2026. 1. 31. 11:02

a. Kubespray란?

Kubespray는 Ansible 기반으로 k8s cluster를 자동으로 설치/업그레이드/관리하기 위한 오프소스 배포 도구이다 ( kubeadm 처럼 k8s 관련 도구 중 1 )
- 역할 및 기능 ( 클러스터 운영 전반을 지원 )
  - 신규 클러스터 생성
  - ( Control Plane ) 클러스터 업그레이드
  - 클러스터 스케일링
  - 노드 관리 - 노드 추가, 노드 제거
  - 클러스터 재설정
  - 설정 관리
  - 백업 / 복구, 업그레이드시 ETCD 스냅샷 수행
- Kubespray 한 버전당 Kubernetes 3개 minor 지원
  - 항상 1~2 버전 늦춰서 안정화 후 포함
  - 운영 시 버전 추천
    - Dev 환경 : Kubespray 최신 + K8s N-1
    - Prd 환경 : Kubespray 최신-1 + K8s N-2

kubespray 소개 및 사용 이유 : Ansible 기반이기에 ssh만 연결된다면 관리에 용이하다.
퍼블릭/폐쇄망의 서버환경에서도 쿠버네티스가 사용가능하다.
컨트롤 플레인과 ETCD에 대한 HA환경을 지원한다.
Client Side LB를 지원하여 분산 접속을 가능하게끔 지원한다.(kubeadm의 경우 직접세팅필요)
Certificate에 대해서도 Auto Renew를 제공해서 자동으로 갱신처리한다.
BestPractice의 설정들을 Playbook형태로 제공을 해준다.
다양한 Linux배포판을 지원한다.

b. 실습 환경

사전 환경 설정

# 파일 다운로드
wget https://raw.githubusercontent.com/gasida/vagrant-lab/refs/heads/main/k8s-kubespary/Vagrantfile
wget https://raw.githubusercontent.com/gasida/vagrant-lab/refs/heads/main/k8s-kubespary/init_cfg.sh

## file 확인
ll
total 16
-rw-r--r--@ 1 howoo  staff   982B Jan 28 15:42 Vagrantfile
-rw-r--r--@ 1 howoo  staff   1.3K Jan 28 15:43 init_cfg.sh

## 실습 환경 배포
vagrant up
                                                                        .
                                                                        .
                                                                        .
    k8s-ctr: Running: /var/folders/s_/d0ls80f161x0q83j7lx_k5wh0000gn/T/vagrant-shell20260128-6889-zu7q2i.sh
    k8s-ctr: >>>> Initial Config Start <<<<
    k8s-ctr: [TASK 1] Change Timezone and Enable NTP
    k8s-ctr: [TASK 2] Disable firewalld and selinux
    k8s-ctr: [TASK 3] Disable and turn off SWAP & Delete swap partitions
    k8s-ctr: [TASK 4] Config kernel & module
    k8s-ctr: [TASK 5] Setting Local DNS Using Hosts file
    k8s-ctr: [TASK 6] Delete default routing - enp0s9 NIC
    k8s-ctr: >>>> Initial Config End <<<<
 howoo@ttokkang-ui-MacBookAir  ~/Desktop/work/Gasida_series/idc_k8s/k8s-kubespary  vagrant status
Current machine states:

k8s-ctr                   running (virtualbox)

The VM is running. To stop this VM, you can run `vagrant halt` to
shut it down forcefully, or you can run `vagrant suspend` to simply
suspend the virtual machine. In either case, to restart it again,
simply run `vagrant up`.

## ssh 접속 후 설정
vagrant status
Current machine states:

k8s-ctr                   running (virtualbox)
------------------------------
root@k8s-ctr:~# uname -a
Linux k8s-ctr 6.12.0-55.39.1.el10_0.aarch64 #1 SMP PREEMPT_DYNAMIC Wed Oct 15 11:18:23 EDT 2025 aarch64 GNU/Linux
root@k8s-ctr:~# which python  && python -V
/usr/bin/python
Python 3.12.9
root@k8s-ctr:~# which python3 && python3 -V
/usr/bin/python3
Python 3.12.9

oot@k8s-ctr:~# dnf install -y python3-pip git
Rocky Linux 10 - BaseOS                      0.0  B/s |   0  B     00:00
Errors during downloading metadata for repository 'baseos':
  - Curl error (6): Could not resolve hostname for https://mirrors.rockylinux.org/mirrorlist?arch=aarch64&repo=BaseOS-10 [Could not resolve host: mirrors.rockylinux.org]
Error: Failed to download metadata for repo 'baseos': Cannot prepare internal mirrorlist: Curl error (6): Could not resolve hostname for https://mirrors.rockylinux.org/mirrorlist?arch=aarch64&repo=BaseOS-10 [Could not resolve host: mirrors.rockylinux.org]
root@k8s-ctr:~# vim /etc/resolv.conf
root@k8s-ctr:~# dnf install -y python3-pip git
Rocky Linux 10 - BaseOS                      531 kB/s |  12 MB     00:23
Rocky Linux 10 - AppStream                   123 kB/s | 2.1 MB     00:17
Rocky Linux 10 - Extras                      384  B/s | 6.2 kB     00:16
Dependencies resolved.
                                                                .
                                                                .
                                                                .
Complete!

root@k8s-ctr:~# which pip  && pip -V
/usr/bin/pip
pip 23.3.2 from /usr/lib/python3.12/site-packages/pip (python 3.12)
root@k8s-ctr:~# which pip3 && pip3 -V
/usr/bin/pip3
pip 23.3.2 from /usr/lib/python3.12/site-packages/pip (python 3.12)

root@k8s-ctr:~# echo "root:qwe123" | chpasswd
root@k8s-ctr:~# cat << EOF >> /etc/ssh/sshd_config
PermitRootLogin yes
PasswordAuthentication yes
EOF
root@k8s-ctr:~# systemctl restart sshd

root@k8s-ctr:~# ssh-keygen -t rsa -N "" -f /root/.ssh/id_rsa
Generating public/private rsa key pair.
Your identification has been saved in /root/.ssh/id_rsa
Your public key has been saved in /root/.ssh/id_rsa.pub
The key fingerprint is:
SHA256:OdD1TkSOOxJl5wHu/WPmZQtqdOE3GS053Kjwxxvb8xU root@k8s-ctr
The key's randomart image is:
+---[RSA 3072]----+
|          =o=    |
|       . = B .   |
|      . o o =. +.|
|       . +.= .*.o|
|        S +o+o.Eo|
|         o oo+++.|
|          . .o*==|
|           ..++=+|
|          ..  ..+|
+----[SHA256]-----+

root@k8s-ctr:~# ls -al ~/.ssh/
total 8
drwx------. 2 root root   38 Jan 28 15:52 .
dr-xr-x---. 3 root root  119 Jan 28 15:49 ..
-rw-------. 1 root root 2602 Jan 28 15:52 id_rsa
-rw-r--r--. 1 root root  566 Jan 28 15:52 id_rsa.pub
root@k8s-ctr:~# ssh-copy-id -o StrictHostKeyChecking=no root@192.168.10.10
/usr/bin/ssh-copy-id: INFO: Source of key(s) to be installed: "/root/.ssh/id_rsa.pub"
/usr/bin/ssh-copy-id: INFO: attempting to log in with the new key(s), to filter out any that are already installed
/usr/bin/ssh-copy-id: INFO: 1 key(s) remain to be installed -- if you are prompted now it is to install the new keys
root@192.168.10.10's password:

Number of key(s) added: 1

Now try logging into the machine, with: "ssh -o 'StrictHostKeyChecking=no' 'root@192.168.10.10'"
and check to make sure that only the key(s) you wanted were added.

root@k8s-ctr:~# cat /root/.ssh/authorized_keys
ssh-rsa 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 root@k8s-ctr
root@k8s-ctr:~# ssh root@192.168.10.10 hostname
k8s-ctr
root@k8s-ctr:~# ssh -o StrictHostKeyChecking=no root@k8s-ctr hostname
Warning: Permanently added 'k8s-ctr' (ED25519) to the list of known hosts.
k8s-ctr
root@k8s-ctr:~# ssh root@k8s-ctr hostname
k8s-ctr

# 환경 설정
**pip3 install -r /root/kubespray/requirements.txt
                                                    .
                                                    .
                                                    .
Downloading ansible-10.7.0-py3-none-any.whl (51.6 MB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 51.6/51.6 MB 6.1 MB/s eta 0:00:00
Downloading cryptography-46.0.2-cp311-abi3-manylinux_2_34_aarch64.whl (4.3 MB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 4.3/4.3 MB 6.7 MB/s eta 0:00:00
Downloading jmespath-1.0.1-py3-none-any.whl (20 kB)
Downloading netaddr-1.3.0-py3-none-any.whl (2.3 MB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 2.3/2.3 MB 6.0 MB/s eta 0:00:00
Downloading ansible_core-2.17.14-py3-none-any.whl (2.2 MB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 2.2/2.2 MB 5.6 MB/s eta 0:00:00
Downloading cffi-2.0.0-cp312-cp312-manylinux2014_aarch64.manylinux_2_17_aarch64.whl (220 kB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 220.1/220.1 kB 6.5 MB/s eta 0:00:00
Downloading jinja2-3.1.6-py3-none-any.whl (134 kB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 134.9/134.9 kB 9.8 MB/s eta 0:00:00
Downloading resolvelib-1.0.1-py2.py3-none-any.whl (17 kB)
Downloading pycparser-3.0-py3-none-any.whl (48 kB)
   ━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━ 48.2/48.2 kB 3.6 MB/s eta 0:00:00
Downloading markupsafe-3.0.3-cp312-cp312-manylinux2014_aarch64.manylinux_2_17_aarch64.manylinux_2_28_aarch64.whl (24 kB)
Installing collected packages: resolvelib, pycparser, netaddr, MarkupSafe, jmespath, jinja2, cffi, cryptography, ansible-core, ansible
Successfully installed MarkupSafe-3.0.3 ansible-10.7.0 ansible-core-2.17.14 cffi-2.0.0 cryptography-46.0.2 jinja2-3.1.6 jmespath-1.0.1 netaddr-1.3.0 pycparser-3.0 resolvelib-1.0.1
WARNING: Running pip as the 'root' user can result in broken permissions and conflicting behaviour with the system package manager. It is recommended to use a virtual environment instead: https://pip.pypa.io/warnings/venv

root@k8s-ctr:~/kubespray# which ansible
/usr/local/bin/ansible
root@k8s-ctr:~/kubespray# ansible --version
ansible [core 2.17.14]
  config file = /root/kubespray/ansible.cfg
  configured module search path = ['/root/kubespray/library']
  ansible python module location = /usr/local/lib/python3.12/site-packages/ansible
  ansible collection location = /root/.ansible/collections:/usr/share/ansible/collections
  executable location = /usr/local/bin/ansible
  python version = 3.12.9 (main, Aug 14 2025, 00:00:00) [GCC 14.2.1 20250110 (Red Hat 14.2.1-7)] (/usr/bin/python3)
  jinja version = 3.1.6
  libyaml = True
root@k8s-ctr:~/kubespray# pip list
Package                   Version
------------------------- -----------
ansible                   10.7.0
ansible-core              2.17.14
attrs                     23.2.0
                                                                .
                                                                .
                                                                .**

Kubespray를 통한 K8s 배포

root@k8s-ctr:~/kubespray# cp -rfp /root/kubespray/inventory/sample /root/kubespray/inventory/mycluster
root@k8s-ctr:~/kubespray# tree inventory/mycluster/
inventory/mycluster/
├── group_vars
│   ├── all
│   │   ├── all.yml
                                        .
                                        .
                                        .

root@k8s-ctr:~/kubespray# cat << EOF > /root/kubespray/inventory/mycluster/inventory.ini
k8s-ctr ansible_host=192.168.10.10 ip=192.168.10.10

[kube_control_plane]
k8s-ctr

[etcd:children]
kube_control_plane

[kube_node]
k8s-ctr
EOF

# 테스트할 기능 관련 수정
root@k8s-ctr:~/kubespray# sed -i 's|kube_network_plugin: calico|kube_network_plugin: flannel|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@k8s-ctr:~/kubespray# sed -i 's|kube_proxy_mode: ipvs|kube_proxy_mode: iptables|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@k8s-ctr:~/kubespray# sed -i 's|enable_nodelocaldns: true|enable_nodelocaldns: false|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@k8s-ctr:~/kubespray# sed -i 's|auto_renew_certificates: false|auto_renew_certificates: true|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml
root@k8s-ctr:~/kubespray# sed -i 's|# auto_renew_certificates_systemd_calendar|auto_renew_certificates_systemd_calendar|g' inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml

# flannel 설정 수정
root@k8s-ctr:~/kubespray# echo "flannel_interface: enp0s9" >> inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
root@k8s-ctr:~/kubespray# grep "^[^#]" inventory/mycluster/group_vars/k8s_cluster/k8s-net-flannel.yml
flannel_interface: enp0s9

root@k8s-ctr:~/kubespray# sed -i 's|helm_enabled: false|helm_enabled: true|g' inventory/mycluster/group_vars/k8s_cluster/addons.yml
root@k8s-ctr:~/kubespray# sed -i 's|metrics_server_enabled: false|metrics_server_enabled: true|g' inventory/mycluster/group_vars/k8s_cluster/addons.yml
root@k8s-ctr:~/kubespray# sed -i 's|node_feature_discovery_enabled: false|node_feature_discovery_enabled: true|g' inventory/mycluster/group_vars/k8s_cluster/addons.yml

root@k8s-ctr:~/kubespray# ls -al ./*.txt
-rw-r--r--. 1 root root   631 Jan 28 16:04 ./df-1.txt
-rw-r--r--. 1 root root  3241 Jan 28 16:04 ./findmnt-1.txt
-rw-r--r--. 1 root root  1459 Jan 28 16:04 ./ip_addr-1.txt
-rw-r--r--. 1 root root   181 Jan 28 15:54 ./requirements.txt
-rw-r--r--. 1 root root   696 Jan 28 16:04 ./ss-1.txt
-rw-r--r--. 1 root root 44424 Jan 28 16:04 ./sysctl-1.txt

## 배포
ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml -e kube_version="1.33.3" **--list-tasks** # 배포 전, Task 목록 확인
ANSIBLE_FORCE_COLOR=true **ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml -e kube_version="1.33.3" | tee kubespray_install.log**
                                                                .
                                                                .
                                                                .
download : Download_file | Download item -------------------------------- 7.34s
container-engine/nerdctl : Download_file | Download item ---------------- 7.22s
container-engine/runc : Download_file | Download item ------------------- 7.17s

alias, 명령어 자동 완성

# Source the completion
source <(kubectl completion bash)
source <(kubeadm completion bash)

# Alias kubectl to k
alias k=kubectl
complete -o default -F __start_kubectl k

# k9s 설치 : https://github.com/derailed/k9s
CLI_ARCH=amd64
if [ "$(uname -m)" = "aarch64" ]; then CLI_ARCH=arm64; fi
wget https://github.com/derailed/k9s/releases/latest/download/k9s_linux_${CLI_ARCH}.tar.gz
tar -xzf k9s_linux_*.tar.gz
ls -al k9s
chown root:root k9s
mv k9s /usr/local/bin/
chmod +x /usr/local/bin/k9s
k9s

환경 설정 및 적용

root@k8s-ctr:~/kubespray# sysctl fs.file-max
fs.file-max = 9223372036854775807
root@k8s-ctr:~/kubespray# cat /proc/sys/fs/file-max
9223372036854775807
root@k8s-ctr:~/kubespray# ulimit -n
1024
root@k8s-ctr:~/kubespray# systemctl show kubelet | grep LimitNOFILE
LimitNOFILE=524288
LimitNOFILESoft=1024

root@k8s-ctr:~/kubespray# cat << EOF >> inventory/mycluster/group_vars/all/containerd.yml
containerd_default_base_runtime_spec_patch:
  process:
    rlimits: []
EOF

**ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "container-engine" --limit k8s-ctr -e kube_version="1.33.3"

root@k8s-ctr:~/kubespray# kubectl delete pod ubuntu
pod "ubuntu" deleted
root@k8s-ctr:~/kubespray# cat << EOF | kubectl apply -f -
apiVersion: v1
kind: Pod
metadata:
  name: ubuntu
spec:
  containers:
  - name: ubuntu
    image: ubuntu
    command: ["sh", "-c", "sleep infinity"]
    securityContext:
      privileged: true
EOF
pod/ubuntu created
root@k8s-ctr:~/kubespray# kubectl exec -it ubuntu -- sh -c 'ulimit -a'
time(seconds)        unlimited
file(blocks)         unlimited
data(kbytes)         unlimited
stack(kbytes)        8192
coredump(blocks)     unlimited
memory(kbytes)       unlimited
locked memory(kbytes) unlimited
process              unlimited
nofiles              1048576
vmemory(kbytes)      unlimited
locks                unlimited
rtprio               0

ansible-playbook -i inventory/mycluster/inventory.ini -v cluster.yml --tags "container-engine" --list-tasks
                                            .
                                            .
                                            .
  play #15 (k8s_cluster): Apply resolv.conf changes now that cluster DNS is up    TAGS: []
    tasks:

## Script 확인

                                            .
                                            .
                                            .
/registry/services/specs/node-feature-discovery/node-feature-discovery-master

compact_rev_key

root@k8s-ctr:~# etcdctl.sh member list -w table
+------------------+---------+-------+----------------------------+----------------------------+------------+
|        ID        | STATUS  | NAME  |         PEER ADDRS         |        CLIENT ADDRS        | IS LEARNER |
+------------------+---------+-------+----------------------------+----------------------------+------------+
| a997582217e26c7f | started | etcd1 | https://192.168.10.10:2380 | https://192.168.10.10:2379 |      false |
+------------------+---------+-------+----------------------------+----------------------------+------------+

# 설치된 정보 확인
root@k8s-ctr:~/kubespray# cat sysctl-1.txt | grep net.ipv4.ip_local_reserved_ports
net.ipv4.ip_local_reserved_ports =
root@k8s-ctr:~/kubespray# cat sysctl-2.txt | grep net.ipv4.ip_local_reserved_ports
net.ipv4.ip_local_reserved_ports = 30000-32767
root@k8s-ctr:~/kubespray# sysctl net.ipv4.ip_local_reserved_ports
net.ipv4.ip_local_reserved_ports = 30000-32767

# node별 최대 파드 배치 개수 확인
root@k8s-ctr:~/kubespray# kubectl describe node
  kube-system                 metrics-server-7cd7f9897-f9ngp                    100m (2%)     100m (2%)   200Mi (6%)       200Mi (6%)     2d3h
  node-feature-discovery      node-feature-discovery-gc-6c9b8f4657-drclc        0 (0%)        0 (0%)      0 (0%)           0 (0%)         2d3h
  node-feature-discovery      node-feature-discovery-master-6989794b78-gfvcx    0 (0%)        0 (0%)      0 (0%)           0 (0%)         2d3h
  node-feature-discovery      node-feature-discovery-worker-q44fg               0 (0%)        0 (0%)      0 (0%)           0 (0%)         2d3h
Allocated resources:
  (Total limits may be over 100 percent, i.e., overcommitted.)
  Resource           Requests        Limits
  --------           --------        ------
  cpu                920m (27%)      400m (11%)
  memory             349220Ki (11%)  1024288000 (33%)
  ephemeral-storage  0 (0%)          0 (0%)
  hugepages-1Gi      0 (0%)          0 (0%)
  hugepages-2Mi      0 (0%)          0 (0%)
  hugepages-32Mi     0 (0%)          0 (0%)
  hugepages-64Ki     0 (0%)          0 (0%)
Events:
  Type     Reason                   Age                From             Message
  ----     ------                   ----               ----             -------
  Normal   Starting                 10m                kube-proxy
  Normal   Starting                 11m                kubelet          Starting kubelet.
  Warning  InvalidDiskCapacity      11m                kubelet          invalid capacity 0 on image filesystem
  Normal   NodeHasSufficientMemory  11m (x8 over 11m)  kubelet          Node k8s-ctr status is now: NodeHasSufficientMemory
  Normal   NodeHasNoDiskPressure    11m (x8 over 11m)  kubelet          Node k8s-ctr status is now: NodeHasNoDiskPressure
  Normal   NodeHasSufficientPID     11m (x7 over 11m)  kubelet          Node k8s-ctr status is now: NodeHasSufficientPID
  Normal   NodeAllocatableEnforced  11m                kubelet          Updated Node Allocatable limit across pods
  Warning  Rebooted                 10m                kubelet          Node k8s-ctr has been rebooted, boot id: 1926a28f-f34f-4605-b1bd-98e6b897d174
  Normal   RegisteredNode           10m                node-controller  Node k8s-ctr event: Registered Node k8s-ctr in Controller
root@k8s-ctr:~/kubespray# kubectl describe node | grep pods
  pods:               110
  pods:               110
  Normal   NodeAllocatableEnforced  11m                kubelet          Updated Node Allocatable limit across pods

  # 설치된 정보 확인
root@k8s-ctr:~/kubespray# ls -al | grep block
root@k8s-ctr:~/kubespray# kubectl get pod -n kube-system -l tier=control-plane
NAME                              READY   STATUS    RESTARTS      AGE
kube-apiserver-k8s-ctr            1/1     Running   5 (14m ago)   2d3h
kube-controller-manager-k8s-ctr   1/1     Running   6 (14m ago)   2d3h
kube-scheduler-k8s-ctr            1/1     Running   5 (14m ago)   2d3h

CERTIFICATE AUTHORITY   EXPIRES                  RESIDUAL TIME   EXTERNALLY MANAGED
ca                      Jan 26, 2036 07:13 UTC   9y              no
front-proxy-ca          Jan 26, 2036 07:13 UTC   9y              no**

Invoke kubeadm and install a CNI

root@k8s-ctr:~/kubespray# tree roles/network_plugin/ -L 1
roles/network_plugin/
├── calico
├── calico_defaults
├── cilium
├── cni
├── custom_cni
├── flannel
├── kube-ovn
├── kube-router
├── macvlan
├── meta
├── multus
└── ovn4nfv

13 directories, 0 files

root@k8s-ctr:~/kubespray# tree roles/network_plugin/cni/
roles/network_plugin/cni/
├── defaults
│   └── main.yml
└── tasks
    └── main.yml

3 directories, 2 files
root@k8s-ctr:~/kubespray# tree roles/network_plugin/flannel/
roles/network_plugin/flannel/
├── defaults
│   └── main.yml
├── meta
│   └── main.yml
├── tasks
│   ├── main.yml
│   └── reset.yml
└── templates
    ├── cni-flannel-rbac.yml.j2
    └── cni-flannel.yml.j2

5 directories, 6 files

Core DNS & DNS-AutoScaler

root@k8s-ctr:~/kubespray# kubectl get deployment -n kube-system coredns dns-autoscaler -o wide
NAME             READY   UP-TO-DATE   AVAILABLE   AGE    CONTAINERS   IMAGES                                                       SELECTOR
coredns          1/1     1            1           2d4h   coredns      registry.k8s.io/coredns/coredns:v1.12.0                      k8s-app=kube-dns
dns-autoscaler   1/1     1            1           2d4h   autoscaler   registry.k8s.io/cpa/cluster-proportional-autoscaler:v1.8.8   k8s-app=dns-autoscaler

root@k8s-ctr:~/kubespray# kubectl describe cm -n kube-system coredns
Name:         coredns
Namespace:    kube-system
Labels:       addonmanager.kubernetes.io/mode=EnsureExists
Annotations:  <none>

Data
====
Corefile:
----
.:53 {
    errors {
    }
    health {
        lameduck 5s
    }
    ready
    kubernetes cluster.local in-addr.arpa ip6.arpa {
      pods insecure
      fallthrough in-addr.arpa ip6.arpa
    }
    prometheus :9153
    forward . /etc/resolv.conf {
      prefer_udp
      max_concurrent 1000
    }
    cache 30

    loop
    reload
    loadbalance
}

BinaryData
====

Events:  <none>

root@k8s-ctr:~/kubespray# kubectl describe cm -n kube-system dns-autoscaler
Name:         dns-autoscaler
Namespace:    kube-system
Labels:       <none>
Annotations:  <none>

Data
====
linear:
----
{"coresPerReplica":256,"min":1,"nodesPerReplica":16,"preventSinglePointFailure":false}

BinaryData
====

Events:  <none>

root@k8s-ctr:~/kubespray# tree /etc/kubernetes/addons/
/etc/kubernetes/addons/
├── metrics_server
│   ├── auth-delegator.yaml
│   ├── auth-reader.yaml
│   ├── metrics-apiservice.yaml
│   ├── metrics-server-deployment.yaml
│   ├── metrics-server-sa.yaml
│   ├── metrics-server-service.yaml
│   ├── resource-reader-clusterrolebinding.yaml
│   └── resource-reader.yaml
└── node_feature_discovery
    ├── nfd-api-crds.yaml
    ├── nfd-clusterrolebinding.yaml
    ├── nfd-clusterrole.yaml
    ├── nfd-gc.yaml
    ├── nfd-master-conf.yaml
    ├── nfd-master.yaml
    ├── nfd-ns.yaml
    ├── nfd-rolebinding.yaml
    ├── nfd-role.yaml
    ├── nfd-serviceaccount.yaml
    ├── nfd-service.yaml
    ├── nfd-topologyupdater-conf.yaml
    ├── nfd-worker-conf.yaml
    └── nfd-worker.yaml

3 directories, 22 files

root@k8s-ctr:~/kubespray# kubectl get pod -n kube-system -l app.kubernetes.io/name=metrics-server
NAME                             READY   STATUS    RESTARTS      AGE
metrics-server-7cd7f9897-f9ngp   1/1     Running   3 (86m ago)   2d4h

root@k8s-ctr:~/kubespray# kubectl top pod -A
NAMESPACE                NAME                                             CPU(cores)   MEMORY(bytes)
default                  ubuntu                                           0m           2Mi
kube-system              coredns-5d784884df-n4g5h                         4m           79Mi
kube-system              dns-autoscaler-676999957f-r8xx6                  1m           42Mi
kube-system              kube-apiserver-k8s-ctr                           43m          331Mi
kube-system              kube-controller-manager-k8s-ctr                  16m          145Mi
kube-system              kube-flannel-ds-arm64-n288c                      5m           64Mi
kube-system              kube-proxy-z846p                                 1m           87Mi
kube-system              kube-scheduler-k8s-ctr                           10m          87Mi
kube-system              metrics-server-7cd7f9897-f9ngp                   4m           88Mi
node-feature-discovery   node-feature-discovery-gc-6c9b8f4657-drclc       1m           48Mi
node-feature-discovery   node-feature-discovery-master-6989794b78-gfvcx   1m           70Mi
node-feature-discovery   node-feature-discovery-worker-q44fg              2m           55Mi

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 6주차 과제 (1)	2026.02.13
K8S ) 5주차 과제 (0)	2026.02.06
K8S)3주차 과제 (0)	2026.01.24
K8S)2주차 과제 (0)	2026.01.15
K8S) 1주차 과제 (0)	2026.01.08

K8S)3주차 과제

zosys 2026. 1. 24. 01:32

2026. 1. 24. 01:32

Kubeadm deep dive

Kubeadm 소개
- kubeadm init

  초기 Kubernetes 컨트롤 플레인 노드를 부트스트랩(초기 구성)하는 명령이다.
- kubeadm join

  Kubernetes 워커 노드 또는 추가 컨트롤 플레인 노드를 부트스트랩하여

  기존 Kubernetes 클러스터에 참여시키는 명령이다.
- kubeadm upgrade

  Kubernetes 클러스터를 더 최신 버전으로 업그레이드하는 명령이다.
- kubeadm reset

  이 호스트에서 kubeadm init 또는 kubeadm join 실행으로 인해 적용된

  모든 변경 사항을 되돌리는(초기화하는) 명령이다.

Kubeadm 실습 준비 ( Vagrantfile)


  PS C:\Users\bom\Desktop\스터디\week3> vagrant up
  Bringing machine 'k8s-ctr' up with 'virtualbox' provider...
  Bringing machine 'k8s-w1' up with 'virtualbox' provider...
  Bringing machine 'k8s-w2' up with 'virtualbox' provider...
  ==> k8s-ctr: Box 'bento/rockylinux-10.0' could not be found. Attempting to find and install...
      k8s-ctr: Box Provider: virtualbox
      k8s-ctr: Box Version: 202510.26.0

      #########중략#############

      k8s-w2: Inserting generated public key within guest...
      k8s-w2: Removing insecure key from the guest if it's present...
      k8s-w2: Key inserted! Disconnecting and reconnecting using new SSH key...
  ==> k8s-w2: Machine booted and ready!
  ==> k8s-w2: Checking for guest additions in VM...
  ==> k8s-w2: Setting hostname...
  ==> k8s-w2: Configuring and enabling network interfaces...

공통사전설정

기본정보확인

  PS C:\Users\bom\Desktop\스터디\week3> vagrant ssh k8s-ctr

  This system is built by the Bento project by Chef Software
  More information can be found at https://github.com/chef/bento

  Use of this system is acceptance of the OS vendor EULA and License Agreements.
  vagrant@k8s-ctr:~$

  vagrant@k8s-ctr:~$ whoami
  vagrant
  vagrant@k8s-ctr:~$ id
  uid=1000(vagrant) gid=1000(vagrant) groups=1000(vagrant) context=unconfined_u:unconfined_r:unconfined_t:s0-s0:c0.c1023
  vagrant@k8s-ctr:~$ pwd
  /home/vagrant

  vagrant@k8s-ctr:~$ rpm -aq | grep release
  rocky-release-10.0-1.6.el10.noarch

Time NTP 설정 : 인증서만료시간 , 로그 타임스탬프 등 모든 노드에 동기화된 시간이 필요 하다.

  root@k8s-ctr:~# timedatectl status
                 Local time: Wed 2026-01-21 14:11:22 UTC
             Universal time: Wed 2026-01-21 14:11:22 UTC
                   RTC time: Wed 2026-01-21 14:11:21
                  Time zone: UTC (UTC, +0000)
  System clock synchronized: yes
                NTP service: active
            RTC in local TZ: yes

  root@k8s-ctr:~# timedatectl set-timezone Asia/Seoul
  root@k8s-ctr:~# date
  Wed Jan 21 11:11:44 PM KST 2026

  root@k8s-ctr:~# chronyc sources -v

    .-- Source mode  '^' = server, '=' = peer, '#' = local clock.
   / .- Source state '*' = current best, '+' = combined, '-' = not combined,
  | /             'x' = may be in error, '~' = too variable, '?' = unusable.
  ||                                                 .- xxxx [ yyyy ] +/- zzzz
  ||      Reachability register (octal) -.           |  xxxx = adjusted offset,
  ||      Log2(Polling interval) --.      |          |  yyyy = measured offset,
  ||                                \     |          |  zzzz = estimated error.
  ||                                 |    |           \
  MS Name/IP address         Stratum Poll Reach LastRx Last sample
  ===============================================================================
  ^* time.ravnus.com               2   6   377    34    +85us[ +280us] +/- 2917us
  ^+ ec2-3-39-176-65.ap-north>     2   6   377    36   +383us[ +576us] +/- 5118us
  ^- 121.174.142.82                3   6   377    34  +1248us[+1248us] +/-   32ms
  ^- ipv4.ntp3.rbauman.com         2   6   377    56  +1540us[+1726us] +/-   18ms

Selinux, firewalld 종료

  root@k8s-ctr:~# getenforce
  Enforcing
  root@k8s-ctr:~# sestatus
  SELinux status:                 enabled
  SELinuxfs mount:                /sys/fs/selinux
  SELinux root directory:         /etc/selinux
  Loaded policy name:             targeted
  Current mode:                   enforcing
  Mode from config file:          enforcing
  Policy MLS status:              enabled
  Policy deny_unknown status:     allowed
  Memory protection checking:     actual (secure)
  Max kernel policy version:      33
  root@k8s-ctr:~# sestatus ^C
  root@k8s-ctr:~# setenforce 0
  root@k8s-ctr:~# sealert ^C
  root@k8s-ctr:~# sestatus
  SELinux status:                 enabled
  SELinuxfs mount:                /sys/fs/selinux
  SELinux root directory:         /etc/selinux
  Loaded policy name:             targeted
  Current mode:                   permissive
  Mode from config file:          enforcing
  Policy MLS status:              enabled
  Policy deny_unknown status:     allowed
  Memory protection checking:     actual (secure)
  Max kernel policy version:      33
  root@k8s-ctr:~# cat /etc/selinux/config | grep ^SELINUX
  SELINUX=enforcing
  SELINUXTYPE=targeted

  root@k8s-ctr:~# sed -i 's/^SELINUX=enforcing/SELINUX=permissive/' /etc/selinux/config
  cat /etc/selinux/config | grep ^SELINUX
  SELINUX=permissive
  SELINUXTYPE=targeted

  root@k8s-ctr:~# systemctl status firewalld
  ○ firewalld.service - firewalld - dynamic firewall daemon
       Loaded: loaded (/usr/lib/systemd/system/firewalld.service; disabled; preset: enabled)
       Active: inactive (dead)
         Docs: man:firewalld(1)

  Jan 21 23:02:55 localhost systemd[1]: Starting firewalld.service - firewalld - dynamic firewall daemon...
  Jan 21 23:02:56 localhost systemd[1]: Started firewalld.service - firewalld - dynamic firewall daemon.
  Jan 21 23:14:39 k8s-ctr systemd[1]: Stopping firewalld.service - firewalld - dynamic firewall daemon...
  Jan 21 23:14:39 k8s-ctr systemd[1]: firewalld.service: Deactivated successfully.
  Jan 21 23:14:39 k8s-ctr systemd[1]: Stopped firewalld.service - firewalld - dynamic firewall daemon.
  Jan 21 23:14:39 k8s-ctr systemd[1]: firewalld.service: Consumed 799ms CPU time, 69.6M memory peak.

Swap비활성화

  root@k8s-ctr:~# lsblk
  NAME   MAJ:MIN RM SIZE RO TYPE MOUNTPOINTS
  sda      8:0    0  64G  0 disk
  ├─sda1   8:1    0   1M  0 part
  ├─sda2   8:2    0   3G  0 part [SWAP]
  └─sda3   8:3    0  61G  0 part /
  root@k8s-ctr:~# swapoff -a
  root@k8s-ctr:~# lsblk
  NAME   MAJ:MIN RM SIZE RO TYPE MOUNTPOINTS
  sda      8:0    0  64G  0 disk
  ├─sda1   8:1    0   1M  0 part
  ├─sda2   8:2    0   3G  0 part
  └─sda3   8:3    0  61G  0 part /

커널 모듈 및 커널 파라미터 설정

  root@k8s-ctr:~# lsmod | grep -iE 'overlay|br_netfilter'
  root@k8s-ctr:~# modprobe overlay
  modprobe br_netfilter
  root@k8s-ctr:~# lsmod | grep -iE 'overlay|br_netfilter'
  br_netfilter           36864  0
  bridge                417792  1 br_netfilter
  overlay               245760  0

  root@k8s-ctr:~# cat <<EOF | tee /etc/sysctl.d/k8s.conf
  net.bridge.bridge-nf-call-iptables  = 1
  net.bridge.bridge-nf-call-ip6tables = 1
  net.ipv4.ip_forward                 = 1
  EOF
  net.bridge.bridge-nf-call-iptables  = 1
  net.bridge.bridge-nf-call-ip6tables = 1
  net.ipv4.ip_forward                 = 1
  root@k8s-ctr:~# tree /etc/sysctl.d/
  /etc/sysctl.d/
  ├── 99-sysctl.conf -> ../sysctl.conf
  └── k8s.conf

  1 directory, 2 files
  root@k8s-ctr:~# sysctl --system
  * Applying /usr/lib/sysctl.d/10-default-yama-scope.conf ...
  * Applying /usr/lib/sysctl.d/10-map-count.conf ...
  * Applying /usr/lib/sysctl.d/50-coredump.conf ...
  * Applying /usr/lib/sysctl.d/50-default.conf ...
  * Applying /usr/lib/sysctl.d/50-libkcapi-optmem_max.conf ...
  * Applying /usr/lib/sysctl.d/50-pid-max.conf ...
  * Applying /usr/lib/sysctl.d/50-redhat.conf ...
  * Applying /etc/sysctl.d/99-sysctl.conf ...
  * Applying /etc/sysctl.d/k8s.conf ...

hosts 설정

  root@k8s-ctr:~# cat /etc/hosts
  # Loopback entries; do not change.
  # For historical reasons, localhost precedes localhost.localdomain:
  127.0.0.1   localhost localhost.localdomain localhost4 localhost4.localdomain4
  ::1         localhost localhost.localdomain localhost6 localhost6.localdomain6
  # See hosts(5) for proper format and other examples:
  # 192.168.1.10 foo.example.org foo
  # 192.168.1.13 bar.example.org bar
  192.168.10.100 k8s-ctr
  192.168.10.101 k8s-w1
  192.168.10.102 k8s-w2

공통CRI설정(Contrainerd)

contrainerd(runc)설치 v2.1.5

원활한 실습을 위해 containerd 버젼은 2.1.5버젼으로 진행하도록한다.

  root@k8s-ctr:~# dnf repolist
  repo id                                             repo name
  appstream                                           Rocky Linux 10 - AppStream
  baseos                                              Rocky Linux 10 - BaseOS
  extras                                              Rocky Linux 10 - Extras

  root@k8s-ctr:~# dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
  Adding repo from: https://download.docker.com/linux/centos/docker-ce.repo
  root@k8s-ctr:~# dnf repolist
  repo id                                                repo name
  appstream                                              Rocky Linux 10 - AppStream
  baseos                                                 Rocky Linux 10 - BaseOS
  docker-ce-stable                                       Docker CE Stable - x86_64
  extras                                                 Rocky Linux 10 - Extras
  root@k8s-ctr:~# dnf makecache
  Docker CE Stable - x86_64                                                               188 kB/s |  16 kB     00:00
  Rocky Linux 10 - BaseOS                                                                 8.2 MB/s | 7.6 MB     00:00
  Rocky Linux 10 - AppStream                                                              3.0 MB/s | 2.1 MB     00:00
  Rocky Linux 10 - Extras                                                                  11 kB/s | 5.9 kB     00:00
  Metadata cache created.

  root@k8s-ctr:~# dnf list --showduplicates containerd.io
  Last metadata expiration check: 0:00:15 ago on Wed 21 Jan 2026 11:30:36 PM KST.
  Available Packages
  containerd.io.x86_64                                  1.7.23-3.1.el10                                   docker-ce-stable
  containerd.io.x86_64                                  1.7.24-3.1.el10                                   docker-ce-stable
  containerd.io.x86_64                                  1.7.25-3.1.el10                                   docker-ce-stable
  containerd.io.x86_64                                  1.7.26-3.1.el10                                   docker-ce-stable
  containerd.io.x86_64                                  1.7.27-3.1.el10                                   docker-ce-stable
  containerd.io.x86_64                                  1.7.28-1.el10                                     docker-ce-stable
  containerd.io.x86_64                                  1.7.28-2.el10                                     docker-ce-stable
  containerd.io.x86_64                                  1.7.29-1.el10                                     docker-ce-stable
  containerd.io.x86_64                                  2.1.5-1.el10                                      docker-ce-stable
  containerd.io.x86_64                                  2.2.0-2.el10                                      docker-ce-stable
  containerd.io.x86_64                                  2.2.1-1.el10

  root@k8s-ctr:~# dnf install -y containerd.io-2.1.5-1.el10
  Last metadata expiration check: 0:00:28 ago on Wed 21 Jan 2026 11:30:36 PM KST.
  Dependencies resolved.
  ========================================================================================================================
   Package                      Architecture          Version                       Repository                       Size
  ========================================================================================================================
  Installing:
   containerd.io                x86_64                2.1.5-1.el10                  docker-ce-stable                 34 M

  Transaction Summary
  ========================================================================================================================
  Install  1 Package

  ######################중략################################

  root@k8s-ctr:~# which runc && runc --version
  /usr/bin/runc
  runc version 1.3.3
  commit: v1.3.3-0-gd842d771
  spec: 1.2.1
  go: go1.24.9
  libseccomp: 2.5.3

  root@k8s-ctr:~# containerd config default | tee /etc/containerd/config.toml
  version = 3
  root = '/var/lib/containerd'
  state = '/run/containerd'
  temp = ''
  disabled_plugins = []
  required_plugins = []
  oom_score = 0
  imports = []

  root@k8s-ctr:~# sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml
  root@k8s-ctr:~# cat /etc/containerd/config.toml | grep -i systemdcgroup
              SystemdCgroup = true

    root@k8s-ctr:~# systemctl daemon-reload
    root@k8s-ctr:~# systemctl enable --now containerd
    Created symlink '/etc/systemd/system/multi-user.target.wants/containerd.service' → '/usr/lib/systemd/system/containerd.service'.
    root@k8s-ctr:~# systemctl status containerd --no-pager
    ● containerd.service - containerd container runtime
         Loaded: loaded (/usr/lib/systemd/system/containerd.service; enabled; preset: disabled)
         Active: active (running) since Wed 2026-01-21 23:33:28 KST; 5s ago
     Invocation: ef390d0ab56144b19688127d98415f72
           Docs: https://containerd.io

     root@k8s-ctr:~# containerd config dump | grep -n containerd.sock
    11:  address = '/run/containerd/containerd.sock'
    root@k8s-ctr:~# ss -xl | grep containerd
    u_str LISTEN 0      4096        /run/containerd/containerd.sock.ttrpc 20071            * 0
    u_str LISTEN 0      4096              /run/containerd/containerd.sock 20072            * 0
    root@k8s-ctr:~# ss -xnp | grep containerd
    u_str ESTAB 0      0                                                 * 20977            * 20069 users:(("containerd",pid=5439,fd=2),("containerd",pid=5439,fd=1))
    root@k8s-ctr:~# ctr --address /run/containerd/containerd.sock version
    Client:
      Version:  v2.1.5
      Revision: fcd43222d6b07379a4be9786bda52438f0dd16a1
      Go version: go1.24.9

    Server:
      Version:  v2.1.5
      Revision: fcd43222d6b07379a4be9786bda52438f0dd16a1
      UUID: c0182a7f-b72c-4269-ba99-f2cf345cdfdc
    ```

공통 kubeadm,kublet kubectl 설치 v1.32.11

kubeadm,kublet kubectl

  root@k8s-ctr:~# cat <<EOF | tee /etc/yum.repos.d/kubernetes.repo
  [kubernetes]
  name=Kubernetes
  baseurl=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/
  enabled=1
  gpgcheck=1
  gpgkey=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/repodata/repomd.xml.key
  exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni
  EOF
  [kubernetes]
  name=Kubernetes
  baseurl=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/
  enabled=1
  gpgcheck=1
  gpgkey=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/repodata/repomd.xml.key
  exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni

  root@k8s-ctr:~# dnf install -y kubelet kubeadm kubectl --disableexcludes=kubernetes
  Last metadata expiration check: 0:00:05 ago on Wed 21 Jan 2026 11:44:29 PM KST.
  Dependencies resolved.
  ========================================================================================================================
   Package                       Architecture          Version                            Repository                 Size
  ========================================================================================================================
  Installing:
   kubeadm                       x86_64                1.32.11-150500.1.1                 kubernetes                 12 M
   kubectl                       x86_64                1.32.11-150500.1.1                 kubernetes                 11 M
   kubelet                       x86_64                1.32.11-150500.1.1                 kubernetes                 15 M
  Installing dependencies:
   cri-tools                     x86_64                1.32.0-150500.1.1                  kubernetes                7.1 M
   kubernetes-cni                x86_64                1.6.0-150500.1.1                   kubernetes                8.0 M

  Transaction Summary
  ========================================================================================================================
  Install  5 Packages

  ################중략###########################

  root@k8s-ctr:~# systemctl enable --now kubelet
  Created symlink '/etc/systemd/system/multi-user.target.wants/kubelet.service' → '/usr/lib/systemd/system/kubelet.service'.
  root@k8s-ctr:~# systemctl status kubelet
  ● kubelet.service - kubelet: The Kubernetes Node Agent
       Loaded: loaded (/usr/lib/systemd/system/kubelet.service; enabled; preset: disabled)
      Drop-In: /usr/lib/systemd/system/kubelet.service.d
               └─10-kubeadm.conf
       Active: activating (auto-restart) (Result: exit-code) since Wed 2026-01-21 23:45:05 KST; 4s ago
   Invocation: 9290c9551a364306bdd2d324aca03c40
         Docs: https://kubernetes.io/docs/
      Process: 5703 ExecStart=/usr/bin/kubelet $KUBELET_KUBECONFIG_ARGS $KUBELET_CONFIG_ARGS $KUBELET_KUBEADM_ARGS $KUBEL>
     Main PID: 5703 (code=exited, status=1/FAILURE)
     Mem peak: 11.7M
          CPU: 79ms

  root@k8s-ctr:~# crictl info | jq
  {
    "cniconfig": {
      "Networks": [
        {
          "Config": {
            "CNIVersion": "0.3.1",
            "Name": "cni-loopback",
            "Plugins": [
              {
                "Network": {
                  "ipam": {},
                  "type": "loopback"
                },
                "Source": "{\"type\":\"loopback\"}"
              }
            ],
            "Source": "{\n\"cniVersion\": \"0.3.1\",\n\"name\": \"cni-loopback\",\n\"plugins\": [{\n  \"type\": \"loopback\"\n}]\n}"

  ##############중략############################

  root@k8s-ctr:~# systemctl is-active kubelet
  activating
  root@k8s-ctr:~# systemctl status kubelet --no-pager
  ● kubelet.service - kubelet: The Kubernetes Node Agent
       Loaded: loaded (/usr/lib/systemd/system/kubelet.service; enabled; preset: disabled)
      Drop-In: /usr/lib/systemd/system/kubelet.service.d
               └─10-kubeadm.conf
       Active: activating (auto-restart) (Result: exit-code) since Wed 2026-01-21 23:46:17 KST; 3s ago
   Invocation: 7ad519af585240e48db775d8ae3a190d
         Docs: https://kubernetes.io/docs/
      Process: 5778 ExecStart=/usr/bin/kubelet $KUBELET_KUBECONFIG_ARGS $KUBELET_CONFIG_ARGS $KUBELET_KUBEADM_ARGS $KUBELET_EXTRA_ARGS (code=exited, status=1/FAILURE)
     Main PID: 5778 (code=exited, status=1/FAILURE)
     Mem peak: 13.4M
          CPU: 77ms
  root@k8s-ctr:~# journalctl -u kubelet --no-pager
  Jan 21 23:45:05 k8s-ctr systemd[1]: Started kubelet.service - kubelet: The Kubernetes Node Agent.
  Jan 21 23:45:05 k8s-ctr (kubelet)[5703]: kubelet.service: Referenced but unset environment variable evaluates to an empty string: KUBELET_KUBEADM_ARGS
  Jan 21 23:45:05 k8s-ctr kubelet[5703]: E0121 23:45:05.839407    5703 run.go:72] "command failed" err="failed to load kubelet config file, path: /var/lib/kubelet/config.yaml, error: failed to load Kubelet config file /var/lib/kubelet/config.yaml, error failed to read kubelet config file \"/var/lib/kubelet/config.yaml\", error: open /var/lib/kubelet/config.yaml: no such file or directory"

  root@k8s-ctr:~# ls -l /run/containerd/containerd.sock
  srw-rw----. 1 root root 0 Jan 21 23:33 /run/containerd/containerd.sock
  root@k8s-ctr:~# ss -xl | grep containerd
  u_str LISTEN 0      4096        /run/containerd/containerd.sock.ttrpc 20071            * 0
  u_str LISTEN 0      4096              /run/containerd/containerd.sock 20072            * 0
  root@k8s-ctr:~# ss -xnp | grep containerd
  u_str ESTAB 0      0                                                 * 20977            * 20069 users:(("containerd",pid=5439,fd=2),("containerd",pid=5439,fd=1))

kubeadm으로 k8s 클러스터 구성 편의성설치 (중요)
- kubeadm init 수행
  - 사전 검사 수행: CRI 연결, root 권한, kubelet 최소 버전 충족 여부 확인
  - 보안 구성 생성: Control Plane 통신을 위한 인증서와 키를 /etc/kubernetes/pki에 생성
  - kubeconfig 생성: kubelet, controller-manager, scheduler, admin용 설정 파일 생성
  - Control Plane 구성요소 배포: kube-apiserver, controller-manager, scheduler, etcd를 Static Pod로 생성
  - kubelet 기동 및 대기: kubelet을 시작하고 API Server가 정상 상태가 될 때까지 대기
  - 클러스터 설정 저장: kubeadm ClusterConfiguration을 kubeadm-config ConfigMap에 저장
  - Control Plane 노드 지정: control-plane 라벨 부여 및 NoSchedule taint 적용
  - 부트스트랩 설정: bootstrap 토큰 생성 및 노드 조인을 위한 TLS/RBAC/cluster-info 구성
  - 필수 애드온 설치: kube-proxy(DaemonSet)와 CoreDNS 설치

```bash
root@k8s-ctr:~# cat kubeadm-init.yaml
apiVersion: kubeadm.k8s.io/v1beta4
kind: InitConfiguration
bootstrapTokens:
- token: "123456.1234567890123456"
  ttl: "0s"
  usages:
  - signing
  - authentication
    nodeRegistration:
    kubeletExtraArgs:
    - name: node-ip
      value: "192.168.10.100" # 미설정 시 10.0.2.15 맵핑
      criSocket: "unix:///run/containerd/containerd.sock"
      localAPIEndpoint:
      advertiseAddress: "192.168.10.100"
apiVersion: kubeadm.k8s.io/v1beta4
kind: ClusterConfiguration
kubernetesVersion: "1.32.11"
networking:
```
  podSubnet: "10.244.0.0/16"
  serviceSubnet: "10.96.0.0/16"
```
root@k8s-ctr:~# kubeadm init --config="kubeadm-init.yaml"
[init] Using Kubernetes version: v1.32.11
[preflight] Running pre-flight checks
[preflight] Pulling images required for setting up a Kubernetes cluster
[preflight] This might take a minute or two, depending on the speed of your internet connection
[preflight] You can also perform this action beforehand using 'kubeadm config images pull'
W0121 23:56:45.057914 6337 checks.go:843] detected that the sandbox image "" of the container runtime is inconsistent with that used by kubeadm.It is recommended to use "registry.k8s.io/pause:3.10" as the CRI sandbox image.

root@k8s-ctr:# mkdir -p /root/.kube
root@k8s-ctr:# cp -i /etc/kubernetes/admin.conf /root/.kube/config
root@k8s-ctr:# chown $(id -u):$(id -g) /root/.kube/config
root@k8s-ctr:# kubectl cluster-info
Kubernetes control plane is running at https://192.168.10.100:6443
CoreDNS is running at https://192.168.10.100:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxy

To further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
root@k8s-ctr:# kubectl get node -owide
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
k8s-ctr NotReady control-plane 3m6s v1.32.11 192.168.10.100 Rocky Linux 10.0 (Red Quartz) 6.12.0-55.39.1.el10_0.x86_64 containerd://2.1.5
root@k8s-ctr:# kubectl get pod -n kube-system -owide
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
coredns-668d6bf9bc-n2xwv 0/1 Pending 0 3m3s
coredns-668d6bf9bc-xsk2k 0/1 Pending 0 3m3s
etcd-k8s-ctr 1/1 Running 0 3m9s 192.168.10.100 k8s-ctr
kube-apiserver-k8s-ctr 1/1 Running 0 3m9s 192.168.10.100 k8s-ctr
kube-controller-manager-k8s-ctr 1/1 Running 0 3m9s 192.168.10.100 k8s-ctr
kube-proxy-9dpcs 1/1 Running 0 3m3s 192.168.10.100 k8s-ctr
kube-scheduler-k8s-ctr 1/1 Running 0 3m9s 192.168.10.100 k8s-ctr

root@k8s-ctr:# kubectl -n kube-public get configmap cluster-info
NAME DATA AGE
cluster-info 2 3m58s
root@k8s-ctr:# kubectl -n kube-public get configmap cluster-info -o yaml
apiVersion: v1
data:
```
  jws-kubeconfig-123456: eyJhbGciOiJIUzI1NiIsImtpZCI6IjEyMzQ1NiJ9..h64eqq42z6muTTM3tEU5EEZaBcK8--j1gmg7rtEXyo0
  kubeconfig: |
    apiVersion: v1
    clusters:
    - cluster:
        certificate-authority-data: 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
        server: https://192.168.10.100:6443
      name: ""
    contexts: null
    current-context: ""
    kind: Config
    preferences: {}
    users: null
```
kind: ConfigMap
metadata:
```
  creationTimestamp: "2026-01-21T14:57:19Z"
  name: cluster-info
  namespace: kube-public
  resourceVersion: "326"
  uid: 4f8df4c9-5dc4-4734-b1b7-e5a803feab7f
```

- 작업 편의성 설정

    ```bash

    root@k8s-ctr:~# alias k=kubectl
    root@k8s-ctr:~# complete -o default -F __start_kubectl k
    root@k8s-ctr:~# echo 'alias k=kubectl' >> /etc/profile
    root@k8s-ctr:~# echo 'complete -o default -F __start_kubectl k' >> /etc/profile
    root@k8s-ctr:~# k get node
    NAME      STATUS     ROLES           AGE     VERSION
    k8s-ctr   NotReady   control-plane   6m26s   v1.32.11
    root@k8s-ctr:~# dnf install -y 'dnf-command(config-manager)'
    Last metadata expiration check: 0:19:06 ago on Wed 21 Jan 2026 11:44:43 PM KST.
    Package dnf-plugins-core-4.7.0-8.el10.noarch is already installed.
    Dependencies resolved.
    ========================================================================================================================
     Package                                 Architecture          Version                      Repository             Size
    ========================================================================================================================
    Upgrading:
     dnf-plugins-core                        noarch                4.7.0-9.el10                 baseos                 43 k
     python3-dnf-plugins-core                noarch                4.7.0-9.el10                 baseos                315 k
     yum-utils                               noarch                4.7.0-9.el10                 baseos                 34 k

    Transaction Summary
    ========================================================================================================================
    Upgrade  3 Packages

    Total download size: 392 k
    Downloading Packages:
    (1/3): dnf-plugins-core-4.7.0-9.el10.noarch.rpm                                         1.2 MB/s |  43 kB     00:00
    (2/3): yum-utils-4.7.0-9.el10.noarch.rpm                                                869 kB/s |  34 kB     00:00
    (3/3): python3-dnf-plugins-core-4.7.0-9.el10.noarch.rpm                                 6.0 MB/s | 315 kB     00:00
    ------------------------------------------------------------------------------------------------------------------------
    Total                                                                                   729 kB/s | 392 kB     00:00
    Running transaction check
    Transaction check succeeded.
    Running transaction test
    Transaction test succeeded.
    Running transaction
      Preparing        :                                                                                                1/1
      Upgrading        : python3-dnf-plugins-core-4.7.0-9.el10.noarch                                                   1/6
      Upgrading        : dnf-plugins-core-4.7.0-9.el10.noarch                                                           2/6
      Upgrading        : yum-utils-4.7.0-9.el10.noarch                                                                  3/6
      Cleanup          : yum-utils-4.7.0-8.el10.noarch                                                                  4/6
      Cleanup          : dnf-plugins-core-4.7.0-8.el10.noarch                                                           5/6
      Cleanup          : python3-dnf-plugins-core-4.7.0-8.el10.noarch                                                   6/6
      Running scriptlet: python3-dnf-plugins-core-4.7.0-8.el10.noarch                                                   6/6

    Upgraded:
      dnf-plugins-core-4.7.0-9.el10.noarch   python3-dnf-plugins-core-4.7.0-9.el10.noarch   yum-utils-4.7.0-9.el10.noarch

    Complete!
    root@k8s-ctr:~# dnf config-manager --add-repo https://kubecolor.github.io/packages/rpm/kubecolor.repo
    Adding repo from: https://kubecolor.github.io/packages/rpm/kubecolor.repo
    root@k8s-ctr:~# dnf repolist
    repo id                                                repo name
    appstream                                              Rocky Linux 10 - AppStream
    baseos                                                 Rocky Linux 10 - BaseOS
    docker-ce-stable                                       Docker CE Stable - x86_64
    extras                                                 Rocky Linux 10 - Extras
    kubecolor                                              packages for kubecolor
    kubernetes                                             Kubernetes
    root@k8s-ctr:~# dnf install -y kubecolor
    packages for kubecolor                                                                   18 kB/s | 949  B     00:00
    Dependencies resolved.
    ========================================================================================================================
     Package                      Architecture              Version                      Repository                    Size
    ========================================================================================================================
    Installing:
     kubecolor                    x86_64                    0.5.3-1                      kubecolor                    2.6 M

    Transaction Summary
    ========================================================================================================================
    Install  1 Package

    Total download size: 2.6 M
    Installed size: 5.9 M
    Downloading Packages:
    kubecolor_0.5.3_linux_amd64.rpm                                                         8.2 MB/s | 2.6 MB     00:00
    ------------------------------------------------------------------------------------------------------------------------
    Total                                                                                   8.1 MB/s | 2.6 MB     00:00
    ##########중략#######

    root@k8s-ctr:~# kubecolor get node
    NAME      STATUS     ROLES           AGE     VERSION
    k8s-ctr   NotReady   control-plane   6m44s   v1.32.11
    root@k8s-ctr:~# alias kc=kubecolor
    root@k8s-ctr:~# echo 'alias kc=kubecolor' >> /etc/profile
    root@k8s-ctr:~# kc get node
    NAME      STATUS     ROLES           AGE     VERSION
    k8s-ctr   NotReady   control-plane   6m52s   v1.32.11
    root@k8s-ctr:~# kc describe node
    Name:               k8s-ctr
    Roles:              control-plane
    Labels:             beta.kubernetes.io/arch=amd64
                        beta.kubernetes.io/os=linux
                        kubernetes.io/arch=amd64
                        kubernetes.io/hostname=k8s-ctr
                        kubernetes.io/os=linux
                        node-role.kubernetes.io/control-plane=
                        node.kubernetes.io/exclude-from-external-load-balancers=
    Annotations:        kubeadm.alpha.kubernetes.io/cri-socket: unix:///run/containerd/containerd.sock
                        node.alpha.kubernetes.io/ttl: 0
                        volumes.kubernetes.io/controller-managed-attach-detach: true
    CreationTimestamp:  Wed, 21 Jan 2026 23:57:17 +0900
    Taints:             node-role.kubernetes.io/control-plane:NoSchedule
                        node.kubernetes.io/not-ready:NoSchedule
    Unschedulable:      false
    Lease:
      HolderIdentity:  k8s-ctr
      AcquireTime:     <unset>
      RenewTime:       Thu, 22 Jan 2026 00:04:11 +0900
    Conditions:
      Type             Status  LastHeartbeatTime                 LastTransitionTime                Reason                       Message
      ----             ------  -----------------                 ------------------                ------                       -------
      MemoryPressure   False   Thu, 22 Jan 2026 00:02:29 +0900   Wed, 21 Jan 2026 23:57:15 +0900   KubeletHasSufficientMemory   kubelet has sufficient memory available
      DiskPressure     False   Thu, 22 Jan 2026 00:02:29 +0900   Wed, 21 Jan 2026 23:57:15 +0900   KubeletHasNoDiskPressure     kubelet has no disk pressure
      PIDPressure      False   Thu, 22 Jan 2026 00:02:29 +0900   Wed, 21 Jan 2026 23:57:15 +0900   KubeletHasSufficientPID      kubelet has sufficient PID available
      Ready            False   Thu, 22 Jan 2026 00:02:29 +0900   Wed, 21 Jan 2026 23:57:15 +0900   KubeletNotReady              container runtime network not ready: NetworkReady=false reason:NetworkPluginNotReady message:Network plugin returns error: cni plugin not initialized
    Addresses:
      InternalIP:  192.168.10.100
      Hostname:    k8s-ctr
    Capacity:
      cpu:                4
      ephemeral-storage:  62374Mi
      hugepages-2Mi:      0
      memory:             3036932Ki
      pods:               110
    Allocatable:
      cpu:                4
      ephemeral-storage:  58863491385
      hugepages-2Mi:      0
      memory:             2934532Ki
      pods:               110
    System Info:
      Machine ID:                 fc9f882274fc4318b555010115a384ff
      System UUID:                f29c335e-dc4d-504d-b371-d8d01bebc7f7
      Boot ID:                    eb7b009f-47d6-4f8d-a944-97839286ddce
      Kernel Version:             6.12.0-55.39.1.el10_0.x86_64
      OS Image:                   Rocky Linux 10.0 (Red Quartz)
      Operating System:           linux
      Architecture:               amd64
      Container Runtime Version:  containerd://2.1.5
      Kubelet Version:            v1.32.11
      Kube-Proxy Version:         v1.32.11
    PodCIDR:                      10.244.0.0/24
    PodCIDRs:                     10.244.0.0/24
    Non-terminated Pods:          (5 in total)
      Namespace                   Name                               CPU Requests  CPU Limits  Memory Requests  Memory Limits  Age
      ---------                   ----                               ------------  ----------  ---------------  -------------  ---
      kube-system                 etcd-k8s-ctr                       100m (2%)     0 (0%)      100Mi (3%)       0 (0%)         6m51s
      kube-system                 kube-apiserver-k8s-ctr             250m (6%)     0 (0%)      0 (0%)           0 (0%)         6m51s
      kube-system                 kube-controller-manager-k8s-ctr    200m (5%)     0 (0%)      0 (0%)           0 (0%)         6m51s
      kube-system                 kube-proxy-9dpcs                   0 (0%)        0 (0%)      0 (0%)           0 (0%)         6m45s
      kube-system                 kube-scheduler-k8s-ctr             100m (2%)     0 (0%)      0 (0%)           0 (0%)         6m51s
    Allocated resources:
      (Total limits may be over 100 percent, i.e., overcommitted.)
      Resource           Requests    Limits
      --------           --------    ------
      cpu                650m (16%)  0 (0%)
      memory             100Mi (3%)  0 (0%)
      ephemeral-storage  0 (0%)      0 (0%)
      hugepages-2Mi      0 (0%)      0 (0%)
    Events:
      Type     Reason                   Age    From             Message
      ----     ------                   ----   ----             -------
      Normal   Starting                 6m44s  kube-proxy
      Normal   Starting                 6m51s  kubelet          Starting kubelet.
      Warning  InvalidDiskCapacity      6m51s  kubelet          invalid capacity 0 on image filesystem
      Normal   NodeAllocatableEnforced  6m51s  kubelet          Updated Node Allocatable limit across pods
      Normal   NodeHasSufficientMemory  6m51s  kubelet          Node k8s-ctr status is now: NodeHasSufficientMemory
      Normal   NodeHasNoDiskPressure    6m51s  kubelet          Node k8s-ctr status is now: NodeHasNoDiskPressure
      Normal   NodeHasSufficientPID     6m51s  kubelet          Node k8s-ctr status is now: NodeHasSufficientPID
      Normal   RegisteredNode           6m46s  node-controller  Node k8s-ctr event: Registered Node k8s-ctr in Controller
    root@k8s-ctr:~# dnf install -y git
    Last metadata expiration check: 0:00:18 ago on Thu 22 Jan 2026 12:03:57 AM KST.
    Dependencies resolved.
    ========================================================================================================================
     Package                         Architecture          Version                           Repository                Size
    ========================================================================================================================
    Installing:
     git                             x86_64                2.47.3-1.el10                     appstream                 50 k
    Installing dependencies:
     git-core                        x86_64                2.47.3-1.el10                     appstream                4.8 M
     git-core-doc                    noarch                2.47.3-1.el10                     appstream                3.1 M
     perl-Error                      noarch                1:0.17029-18.el10                 appstream                 40 k
     perl-File-Find                  noarch                1.44-512.2.el10_0                 appstream                 25 k
     perl-Git                        noarch                2.47.3-1.el10                     appstream                 37 k
     perl-TermReadKey                x86_64                2.38-24.el10                      appstream                 36 k
     perl-lib                        x86_64                0.65-512.2.el10_0                 appstream                 15 k

    Transaction Summary
    ========================================================================================================================
    Install  8 Packages

    ###################중략 #############################

    root@k8s-ctr:~# git clone https://github.com/ahmetb/kubectx /opt/kubectx
    Cloning into '/opt/kubectx'...
    remote: Enumerating objects: 1540, done.
    remote: Counting objects: 100% (469/469), done.
    remote: Compressing objects: 100% (110/110), done.
    remote: Total 1540 (delta 407), reused 360 (delta 359), pack-reused 1071 (from 2)
    #######################중략 ####################

    root@k8s-ctr:~# cat << "EOT" >> /root/.bash_profile
    source /root/kube-ps1/kube-ps1.sh
    KUBE_PS1_SYMBOL_ENABLE=true
    function get_cluster_short() {
      echo "$1" | cut -d . -f1
    }
    KUBE_PS1_CLUSTER_FUNCTION=get_cluster_short
    KUBE_PS1_SUFFIX=') '
    PS1='$(kube_ps1)'$PS1
    EOT
    ```

    ![image.png](attachment:f67d0bbe-b15c-4937-8fc0-b7a7bc377d9e:image.png)

- Flannel CNI 설치 ( flannel인터페이스 반드시확인)

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# kc describe pod -n kube-system kube-controller-manager-k8s-ctr
    Name:                 kube-controller-manager-k8s-ctr
    Namespace:            kube-system
    Priority:             2000001000
    Priority Class Name:  system-node-critical
    Node:                 k8s-ctr/192.168.10.100
    Start Time:           Wed, 21 Jan 2026 23:57:20 +0900
    Labels:               component=kube-controller-manager
                          tier=control-plane
    Annotations:          kubernetes.io/config.hash: 7314ab3f0ec6401c196ca943fad44a05
                          kubernetes.io/config.mirror: 7314ab3f0ec6401c196ca943fad44a05
                          kubernetes.io/config.seen: 2026-01-21T23:57:20.682508931+09:00
                          kubernetes.io/config.source: file
    Status:               Running
    SeccompProfile:       RuntimeDefault
    IP:                   192.168.10.100
    IPs:
      IP:           192.168.10.100
    Controlled By:  Node/k8s-ctr

    (⎈|HomeLab:default) root@k8s-ctr:~# helm repo add flannel https://flannel-io.github.io/flannel
    "flannel" has been added to your repositories
    (⎈|HomeLab:default) root@k8s-ctr:~#
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl create namespace kube-flannel
    namespace/kube-flannel created
    (⎈|HomeLab:default) root@k8s-ctr:~# cat << EOF > flannel.yaml
    podCidr: "10.244.0.0/16"
    flannel:
      cniBinDir: "/opt/cni/bin"
      cniConfDir: "/etc/cni/net.d"
      args:
      - "--ip-masq"
      - "--kube-subnet-mgr"
      **- "--iface=enp0s9"**
      backend: "vxlan"
    EOF
    (⎈|HomeLab:default) root@k8s-ctr:~# helm install flannel flannel/flannel --namespace kube-flannel --version 0.27.3 -f flannel.yaml
    NAME: flannel
    LAST DEPLOYED: Thu Jan 22 00:14:31 2026
    NAMESPACE: kube-flannel
    STATUS: deployed
    REVISION: 1
    TEST SUITE: None

    ########### **"--iface=enp0s9"가 아닌 enp0s8로 되어있어서 재구동진행 ########**
    (⎈|HomeLab:default) root@k8s-ctr:~# helm upgrade flannel flannel/flannel   -n kube-flannel   -f flannel.yaml
    Release "flannel" has been upgraded. Happy Helming!
    NAME: flannel
    LAST DEPLOYED: Thu Jan 22 00:24:14 2026
    NAMESPACE: kube-flannel
    STATUS: deployed
    REVISION: 2
    TEST SUITE: None

    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get pod -n kube-system -owide
    NAME                              READY   STATUS    RESTARTS   AGE   IP               NODE      NOMINATED NODE   READINESS GATES
    coredns-668d6bf9bc-n2xwv          1/1     Running   0          28m   10.244.0.3       k8s-ctr   <none>           <none>
    coredns-668d6bf9bc-xsk2k          1/1     Running   0          28m   10.244.0.2       k8s-ctr   <none>           <none>
    ```

- 노드 정보 확인 기본 환경 정보 출력

    kubelet,kubeadm 설치시 커널파라미터가 변경되는게있따

    ex) kernnel.panic = 0 > 10 변경

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# systemctl is-active kubelet
    active
    (⎈|HomeLab:default) root@k8s-ctr:~# kc describe node
    Name:               k8s-ctr
    Roles:              control-plane
    Labels:             beta.kubernetes.io/arch=amd64
                        beta.kubernetes.io/os=linux
                        kubernetes.io/arch=amd64
                        kubernetes.io/hostname=k8s-ctr
                        kubernetes.io/os=linux
                        node-role.kubernetes.io/control-plane=
                        node.kubernetes.io/exclude-from-external-load-balancers=
    Annotations:        flannel.alpha.coreos.com/backend-data: {"VNI":1,"VtepMAC":"3a:76:87:a6:2d:bf"}
                        flannel.alpha.coreos.com/backend-type: vxlan
                        flannel.alpha.coreos.com/kube-subnet-manager: true
                        flannel.alpha.coreos.com/public-ip: 192.168.10.100
                        kubeadm.alpha.kubernetes.io/cri-socket: unix:///run/containerd/containerd.sock
                        node.alpha.kubernetes.io/ttl: 0
                        volumes.kubernetes.io/controller-managed-attach-detach: true
    CreationTimestamp:  Wed, 21 Jan 2026 23:57:17 +0900
    **Taints:             node-role.kubernetes.io/control-plane:NoSchedule**

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/sysconfig/kubelet
    tree /etc/kubernetes  | tee -a etc_kubernetes-2.txt
    tree /var/lib/kubelet | tee -a var_lib_kubelet-2.txt
    tree /run/containerd/ -L 3 | tee -a run_containerd-2.txt
    pstree -alnp | tee -a pstree-2.txt
    systemd-cgls --no-pager | tee -a systemd-cgls-2.txt
    lsns | tee -a lsns-2.txt
    ip addr | tee -a ip_addr-2.txt
    ss -tnlp | tee -a ss-2.txt
    df -hT | tee -a df-2.txt
    findmnt | tee -a findmnt-2.txt
    sysctl -a | tee -a sysctl-2.txt
    ```

- 인증서 확인

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# kc describe cm -n kube-system kubeadm-config
    Name:         kubeadm-config
    Namespace:    kube-system
    Labels:       <none>
    Annotations:  <none>

    Data
    ====
    ClusterConfiguration:
    ----
    apiServer: {}
    apiVersion: kubeadm.k8s.io/v1beta4
    **caCertificateValidityPeriod: 87600h0m0s
    certificateValidityPeriod: 8760h0m0s**
    certificatesDir: /etc/kubernetes/pki
    clusterName: kubernetes
    controllerManager: {}
    dns: {}
    encryptionAlgorithm: RSA-2048
    etcd:
      local:
        dataDir: /var/lib/etcd
    imageRepository: registry.k8s.io
    kind: ClusterConfiguration
    kubernetesVersion: v1.32.11
    networking:
      dnsDomain: cluster.local
      podSubnet: 10.244.0.0/16
      serviceSubnet: 10.96.0.0/16
    proxy: {}
    scheduler: {}

    BinaryData
    ====

    (⎈|HomeLab:default) root@k8s-ctr:~# kubeadm certs check-expiration
    [check-expiration] Reading configuration from the "kubeadm-config" ConfigMap in namespace "kube-system"...
    [check-expiration] Use 'kubeadm init phase upload-config --config your-config.yaml' to re-upload it.

    CERTIFICATE                EXPIRES                  RESIDUAL TIME   CERTIFICATE AUTHORITY   EXTERNALLY MANAGED
    admin.conf                 Jan 21, 2027 14:56 UTC   364d            ca                      no
    apiserver                  Jan 21, 2027 14:56 UTC   364d            ca                      no
    apiserver-etcd-client      Jan 21, 2027 14:56 UTC   364d            etcd-ca                 no
    apiserver-kubelet-client   Jan 21, 2027 14:56 UTC   364d            ca                      no
    controller-manager.conf    Jan 21, 2027 14:56 UTC   364d            ca                      no
    etcd-healthcheck-client    Jan 21, 2027 14:56 UTC   364d            etcd-ca                 no
    etcd-peer                  Jan 21, 2027 14:56 UTC   364d            etcd-ca                 no
    etcd-server                Jan 21, 2027 14:56 UTC   364d            etcd-ca                 no
    front-proxy-client         Jan 21, 2027 14:56 UTC   364d            front-proxy-ca          no
    scheduler.conf             Jan 21, 2027 14:56 UTC   364d            ca                      no
    super-admin.conf           Jan 21, 2027 14:56 UTC   364d            ca                      no

    CERTIFICATE AUTHORITY   EXPIRES                  RESIDUAL TIME   EXTERNALLY MANAGED
    ca                      Jan 19, 2036 14:56 UTC   9y              no
    etcd-ca                 Jan 19, 2036 14:56 UTC   9y              no
    front-proxy-ca          Jan 19, 2036 14:56 UTC   9y              no
    ```

- kubeconfig 확인

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/kubernetes/admin.conf
    apiVersion: v1
    clusters:
    - cluster:
        certificate-authority-data:
    ##############중략###################
    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/kubernetes/super-admin.conf
    apiVersion: v1
    clusters:
    - cluster:
        certificate-authority-data:
    ##############중략###################
    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/kubernetes/controller-manager.conf
    apiVersion: v1
    clusters:
    - cluster:
        certificate-authority-data:
    ##############중략###################

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /var/lib/kubelet/pki/kubelet.crt | openssl x509 -text -noout
    Certificate:
        Data:
            Version: 3 (0x2)
            Serial Number: 4215227672604660729 (0x3a7f7f3c28ff53f9)
            Signature Algorithm: sha256WithRSAEncryption
            Issuer: CN=k8s-ctr-ca@1769007433
            Validity
                Not Before: Jan 21 13:57:13 2026 GMT
                Not After : Jan 21 13:57:13 2027 GMT
            Subject: CN=k8s-ctr@1769007433
            Subject Public Key Info:
                Public Key Algorithm: rsaEncryption
                    Public-Key: (2048 bit)
                    Modulus:

     (⎈|HomeLab:default) root@k8s-ctr:~# cat /var/lib/kubelet/pki/kubelet-client-current.pem | openssl x509 -text -noout
    Certificate:
        Data:
            Version: 3 (0x2)
            Serial Number: 5381870817680008066 (0x4ab03efe8adba382)
            Signature Algorithm: sha256WithRSAEncryption
            Issuer: CN=kubernetes
            Validity
                Not Before: Jan 21 14:51:44 2026 GMT
                Not After : Jan 21 14:56:44 2027 GMT
            Subject: O=system:nodes, CN=system:node:k8s-ctr
            Subject Public Key Info:
                Public Key Algorithm: rsaEncryption
    ```

- static pod 확인 : etcd, kube-apiserver, kube-scheduler,kube-controller-manager

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# tree /etc/kubernetes/manifests/
    /etc/kubernetes/manifests/
    ├── etcd.yaml
    ├── kube-apiserver.yaml
    ├── kube-controller-manager.yaml
    └── kube-scheduler.yaml

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /var/lib/kubelet/config.yaml
    apiVersion: kubelet.config.k8s.io/v1beta1
    authentication:
      anonymous:
        enabled: false
      webhook:
        cacheTTL: 0s
        enabled: true
      x509:
        clientCAFile: /etc/kubernetes/pki/ca.crt

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /var/lib/kubelet/kubeadm-flags.env
    KUBELET_KUBEADM_ARGS="--container-runtime-endpoint=unix:///run/containerd/containerd.sock --node-ip=192.168.10.100 --pod-infra-container-image=registry.k8s.io/pause:3.10"

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/kubernetes/manifests/etcd.yaml
    apiVersion: v1
    kind: Pod
    metadata:
      annotations:
        kubeadm.kubernetes.io/etcd.advertise-client-urls: https://192.168.10.100:2379
      creationTimestamp: null
      labels:
        component: etcd
        tier: control-plane
      name: etcd
      namespace: kube-system
    spec:
      containers:
      - command:
        - etcd
        - --advertise-client-urls=https://192.168.10.100:2379
        - --cert-file=/etc/kubernetes/pki/etcd/server.crt

     (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get svc,ep
    NAME                 TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)   AGE
    service/kubernetes   ClusterIP   10.96.0.1    <none>        443/TCP   41m

    NAME                   ENDPOINTS             AGE
    endpoints/kubernetes   192.168.10.100:6443   41m

    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get nodes -o jsonpath='{range .items[*]}{.metadata.name}{"\t"}{.spec.podCIDR}{"\n"}{end}'
    k8s-ctr 10.244.0.0/24
    ```

- 필수 애드온 설치 확인

    ```bash
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get deploy -n kube-system coredns -owide
    NAME      READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES                                    SELECTOR
    coredns   2/2     2            2           41m   coredns      registry.k8s.io/coredns/coredns:v1.11.3   k8s-app=kube-dns
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get pod -n kube-system -l k8s-app=kube-dns -owide
    NAME                       READY   STATUS    RESTARTS   AGE   IP           NODE      NOMINATED NODE   READINESS GATES
    coredns-668d6bf9bc-n2xwv   1/1     Running   0          41m   10.244.0.3   k8s-ctr   <none>           <none>
    coredns-668d6bf9bc-xsk2k   1/1     Running   0          41m   10.244.0.2   k8s-ctr   <none>           <none>
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get svc,ep -n kube-system
    NAME               TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)                  AGE
    service/kube-dns   ClusterIP   10.96.0.10   <none>        53/UDP,53/TCP,9153/TCP   41m

    NAME                 ENDPOINTS                                               AGE
    endpoints/kube-dns   10.244.0.2:53,10.244.0.3:53,10.244.0.2:53 + 3 more...   41m
    (⎈|HomeLab:default) root@k8s-ctr:~# curl -s http://10.96.0.10:9153/metrics | head
    # HELP coredns_build_info A metric with a constant '1' value labeled by version, revision, and goversion from which CoreDNS was built.
    # TYPE coredns_build_info gauge
    coredns_build_info{goversion="go1.21.11",revision="a6338e9",version="1.11.3"} 1
    # HELP coredns_cache_entries The number of elements in the cache.
    # TYPE coredns_cache_entries gauge
    coredns_cache_entries{server="dns://:53",type="denial",view="",zones="."} 1
    coredns_cache_entries{server="dns://:53",type="success",view="",zones="."} 0
    # HELP coredns_cache_misses_total The count of cache misses. Deprecated, derive misses from cache hits/requests counters.
    # TYPE coredns_cache_misses_total counter
    coredns_cache_misses_total{server="dns://:53",view="",zones="."} 1

    (⎈|HomeLab:default) root@k8s-ctr:~# kc describe cm -n kube-system coredns
    Name:         coredns
    Namespace:    kube-system
    Labels:       <none>
    Annotations:  <none>

    Events:  <none>

    (⎈|HomeLab:default) root@k8s-ctr:~# cat /etc/resolv.conf
    # Generated by NetworkManager
    nameserver 8.8.8.8
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get ds -n kube-system -owide
    NAME         DESIRED   CURRENT   READY   UP-TO-DATE   AVAILABLE   NODE SELECTOR            AGE   CONTAINERS   IMAGES                                SELECTOR
    kube-proxy   1         1         1       1            1           kubernetes.io/os=linux   43m   kube-proxy   registry.k8s.io/kube-proxy:v1.32.11   k8s-app=kube-proxy
    (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get pod -n kube-system -l k8s-app=kube-proxy -owide
    NAME               READY   STATUS    RESTARTS   AGE   IP               NODE      NOMINATED NODE   READINESS GATES
    kube-proxy-9dpcs   1/1     Running   0          42m   192.168.10.100   k8s-ctr   <none>           <none>
    (⎈|HomeLab:default) root@k8s-ctr:~# kc describe cm -n kube-system kube-proxy
    Name:         kube-proxy
    Namespace:    kube-system
    Labels:       app=kube-proxy
    Annotations:  kubeadm.kubernetes.io/component-config.hash: sha256:cdf765c8ace05d9c91a233c33ad96de755530f97919a928be185843e99db7bd7

    Data
    ====
    config.conf:
    ----
    apiVersion: kubeproxy.config.k8s.io/v1alpha1
    bindAddress: 0.0.0.0
    bindAddressHardFail: false
    clientConnection:
      acceptContentTypes: ""
      burst: 0
      contentType: ""
      kubeconfig: /var/lib/kube-proxy/kubeconfig.conf
      qps: 0

    ====

    Events:  <none>
    (⎈|HomeLab:default) root@k8s-ctr:~# curl 127.0.0.1:10249/healthz ; echo
    ok

    (⎈|HomeLab:default) root@k8s-ctr:~# dnf install -y conntrack-tools
    Last metadata expiration check: 0:37:12 ago on Thu 22 Jan 2026 12:03:57 AM KST.
    Dependencies resolved.
    ========================================================================================================================
     Package                              Architecture         Version                        Repository               Size
    ========================================================================================================================
    Installing:
     conntrack-tools                      x86_64               1.4.8-3.el10                   appstream               235 k
    Installing dependencies:
     libnetfilter_cthelper                x86_64               1.0.1-1.el10                   appstream                23 k
     libnetfilter_cttimeout               x86_64               1.0.0-27.el10                  appstream                23 k
     libnetfilter_queue                   x86_64               1.0.5-9.el10                   appstream                28 k

    Transaction Summary
    ========================================================================================================================
    Install  4 Packages

    ######중략#######
    ```

k8s-w1,w2 설정

사전설정

  접속후 동일하게 세팅진행
  PS C:\Users\bom\Desktop\스터디\week3> vagrant ssh k8s-w1

  This system is built by the Bento project by Chef Software
  More information can be found at https://github.com/chef/bento

  Use of this system is acceptance of the OS vendor EULA and License Agreements.
  vagrant@k8s-w1:~$ echo "sudo su -" >> /home/vagrant/.bashrc
  vagrant@k8s-w1:~$ sudo su -
  root@k8s-w1:~# timedatectl set-local-rtc 0
  root@k8s-w1:~# timedatectl set-timezone Asia/Seoul
  root@k8s-w1:~# setenforce 0
  root@k8s-w1:~# sed -i 's/^SELINUX=enforcing/SELINUX=permissive/' /etc/selinux/config
  root@k8s-w1:~# systemctl disable --now firewalld
  Removed '/etc/systemd/system/multi-user.target.wants/firewalld.service'.
  Removed '/etc/systemd/system/dbus-org.fedoraproject.FirewallD1.service'.
  root@k8s-w1:~# swapoff -a
  root@k8s-w1:~# sed -i '/swap/d' /etc/fstab
  root@k8s-w1:~# modprobe overlay
  root@k8s-w1:~# modprobe br_netfilter
  root@k8s-w1:~# cat <<EOF | tee /etc/modules-load.d/k8s.conf
  overlay
  br_netfilter
  EOF
  overlay
  br_netfilter
  root@k8s-w1:~# cat <<EOF | tee /etc/sysctl.d/k8s.conf
  net.bridge.bridge-nf-call-iptables  = 1
  net.bridge.bridge-nf-call-ip6tables = 1
  net.ipv4.ip_forward                 = 1
  EOF
  net.bridge.bridge-nf-call-iptables  = 1
  net.bridge.bridge-nf-call-ip6tables = 1
  net.ipv4.ip_forward                 = 1
  root@k8s-w1:~# sysctl --system >/dev/null 2>&1
  root@k8s-w1:~# sed -i '/^127\.0\.\(1\|2\)\.1/d' /etc/hosts
  cat << EOF >> /etc/hosts
  192.168.10.100 k8s-ctr
  192.168.10.101 k8s-w1
  192.168.10.102 k8s-w2
  EOF

CRI설치

  root@k8s-w2:~# dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
  Adding repo from: https://download.docker.com/linux/centos/docker-ce.repo
  root@k8s-w2:~# dnf install -y containerd.io-2.1.5-1.el10
  Docker CE Stable - x86_64                                                               282 kB/s |  16 kB     00:00
  Dependencies resolved.
  ========================================================================================================================
   Package                      Architecture          Version                       Repository                       Size
  ========================================================================================================================
  Installing:
   containerd.io                x86_64                2.1.5-1.el10                  docker-ce-stable                 34 M

  Transaction Summary
  ========================================================================================================================
  Install  1 Package

  root@k8s-w2:~# containerd config default | tee /etc/containerd/config.toml
  version = 3
  root = '/var/lib/containerd'
  state = '/run/containerd'
  temp = ''
  disabled_plugins = []
  required_plugins = []
  oom_score = 0
  imports = []
  ###########중략###########

  root@k8s-w2:~# sed -i 's/SystemdCgroup = false/SystemdCgroup = true/g' /etc/containerd/config.toml
  root@k8s-w2:~# systemctl daemon-reload
  root@k8s-w2:~# systemctl enable --now containerd
  Created symlink '/etc/systemd/system/multi-user.target.wants/containerd.service' → '/usr/lib/systemd/system/containerd.service'.

kubeadm, kubelet 및 kubectl 설치

  root@k8s-w2:~# cat <<EOF | tee /etc/yum.repos.d/kubernetes.repo
  [kubernetes]
  name=Kubernetes
  baseurl=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/
  enabled=1
  gpgcheck=1
  gpgkey=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/repodata/repomd.xml.key
  exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni
  EOF
  [kubernetes]
  name=Kubernetes
  baseurl=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/
  enabled=1
  gpgcheck=1
  gpgkey=https://pkgs.k8s.io/core:/stable:/v1.32/rpm/repodata/repomd.xml.key
  exclude=kubelet kubeadm kubectl cri-tools kubernetes-cni
  root@k8s-w2:~# dnf install -y kubelet kubeadm kubectl --disableexcludes=kubernetes
  Kubernetes                                                                               38 kB/s |  19 kB     00:00
  Dependencies resolved.
  ========================================================================================================================
   Package                       Architecture          Version                            Repository                 Size
  ========================================================================================================================
  Installing:
   kubeadm                       x86_64                1.32.11-150500.1.1                 kubernetes                 12 M
   kubectl                       x86_64                1.32.11-150500.1.1                 kubernetes                 11 M
   kubelet                       x86_64                1.32.11-150500.1.1                 kubernetes                 15 M
  Installing dependencies:
   cri-tools                     x86_64                1.32.0-150500.1.1                  kubernetes                7.1 M
   kubernetes-cni                x86_64                1.6.0-150500.1.1                   kubernetes                8.0 M

  Transaction Summary
  ========================================================================================================================
  Install  5 Packages

  root@k8s-w2:~# systemctl enable --now kubelet
  Created symlink '/etc/systemd/system/multi-user.target.wants/kubelet.service' → '/usr/lib/systemd/system/kubelet.service'.
  root@k8s-w2:~# cat << EOF > /etc/crictl.yaml
  runtime-endpoint: unix:///run/containerd/containerd.sock
  image-endpoint: unix:///run/containerd/containerd.sock
  EOF

kubeadm k8s join

  root@k8s-w2:~# crictl images
  crictl ps
  cat /etc/sysconfig/kubelet
  tree /etc/kubernetes  | tee -a etc_kubernetes-1.txt
  tree /var/lib/kubelet | tee -a var_lib_kubelet-1.txt
  tree /run/containerd/ -L 3 | tee -a run_containerd-1.txt
  pstree -alnp | tee -a pstree-1.txt
  systemd-cgls --no-pager | tee -a systemd-cgls-1.txt
  lsns | tee -a lsns-1.txt
  ip addr | tee -a ip_addr-1.txt
  ss -tnlp | tee -a ss-1.txt
  df -hT | tee -a df-1.txt
  findmnt | tee -a findmnt-1.txt
  sysctl -a | tee -a sysctl-1.txt

  root@k8s-w2:~# NODEIP=$(ip -4 addr show enp0s8 | grep -oP '(?<=inet\s)\d+(\.\d+){3}')

  root@k8s-w2:~# NODEIP=$(ip -4 addr show enp0s8 | grep -oP '(?<=inet\s)\d+(\.\d+){3}')
  root@k8s-w2:~# cat << EOF > kubeadm-join.yaml
  apiVersion: kubeadm.k8s.io/v1beta4
  kind: JoinConfiguration
  discovery:
    bootstrapToken:
      token: "123456.1234567890123456"
      apiServerEndpoint: "192.168.10.100:6443"
      unsafeSkipCAVerification: true
  nodeRegistration:
    criSocket: "unix:///run/containerd/containerd.sock"
    kubeletExtraArgs:
      - name: node-ip
        value: "$NODEIP"
  EOF

  root@k8s-w2:~# kubeadm join --config="kubeadm-join.yaml"
  [preflight] Running pre-flight checks
  [preflight] Reading configuration from the "kubeadm-config" ConfigMap in namespace "kube-system"...
  [preflight] Use 'kubeadm init phase upload-config --config your-config.yaml' to re-upload it.
  [kubelet-start] Writing kubelet configuration to file "/var/lib/kubelet/config.yaml"
  [kubelet-start] Writing kubelet environment file with flags to file "/var/lib/kubelet/kubeadm-flags.env"
  [kubelet-start] Starting the kubelet
  [kubelet-check] Waiting for a healthy kubelet at http://127.0.0.1:10248/healthz. This can take up to 4m0s
  [kubelet-check] The kubelet is healthy after 505.002436ms
  [kubelet-start] Waiting for the kubelet to perform the TLS Bootstrap

  This node has joined the cluster:
  * Certificate signing request was sent to apiserver and a response was received.
  * The Kubelet was informed of the new secure connection details.

  Run 'kubectl get nodes' on the control-plane to see this node join the cluster.

  root@k8s-w2:~# curl -s -k https://192.168.10.100:6443/api/v1/namespaces/kube-public/configmaps/cluster-info | jq
  {
    "kind": "ConfigMap",
    "apiVersion": "v1",
    "metadata": {
      "name": "cluster-info",
      "namespace": "kube-public",
      "uid": "4f8df4c9-5dc4-4734-b1b7-e5a803feab7f",

k8s-w1/w2 정보확인

  (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get node -owide

  NAME      STATUS   ROLES           AGE   VERSION    INTERNAL-IP      EXTERNAL-IP   OS-IMAGE                        KERNEL-VERSION                 CONTAINER-RUNTIME
  k8s-ctr   Ready    control-plane   2d    v1.32.11   192.168.10.100   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.x86_64   containerd://2.1.5
  k8s-w1    Ready    <none>          58s   v1.32.11   192.168.10.101   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.x86_64   containerd://2.1.5
  k8s-w2    Ready    <none>          53s   v1.32.11   192.168.10.102   <none>        Rocky Linux 10.0 (Red Quartz)   6.12.0-55.39.1.el10_0.x86_64   containerd://2.1.5

  (⎈|HomeLab:default) root@k8s-ctr:~# kc describe node k8s-w2
  Name:               k8s-w2
  Roles:              <none>
  Labels:             beta.kubernetes.io/arch=amd64
                      beta.kubernetes.io/os=linux
                      kubernetes.io/arch=amd64
                      kubernetes.io/hostname=k8s-w2
                      kubernetes.io/os=linux
  Annotations:        flannel.alpha.coreos.com/backend-data: {"VNI":1,"VtepMAC":"d2:83:ae:e6:6e:a0"}
                      flannel.alpha.coreos.com/backend-type: vxlan
                      flannel.alpha.coreos.com/kube-subnet-manager: true
                      flannel.alpha.coreos.com/public-ip: 192.168.10.102
                      kubeadm.alpha.kubernetes.io/cri-socket: unix:///run/containerd/containerd.sock
                      node.alpha.kubernetes.io/ttl: 0
                      volumes.kubernetes.io/controller-managed-attach-detach: true
  CreationTimestamp:  Fri, 23 Jan 2026 23:56:42 +0900
  Taints:             <none>

모니터링 툴 설치진행

metric-server설치진행

  (⎈|HomeLab:default) root@k8s-ctr:~# helm repo add metrics-server https://kubernetes-sigs.github.io/metrics-server/
  "metrics-server" has been added to your repositories
  (⎈|HomeLab:default) root@k8s-ctr:~# helm upgrade --install metrics-server metrics-server/metrics-server --set 'args[0]=--kubelet-insecure-tls' -n kube-system
  Release "metrics-server" does not exist. Installing it now.
  NAME: metrics-server
  LAST DEPLOYED: Sat Jan 24 00:14:07 2026
  NAMESPACE: kube-system
  STATUS: deployed
  REVISION: 1
  TEST SUITE: None
  NOTES:
  ***********************************************************************
  * Metrics Server                                                      *
  ***********************************************************************
    Chart version: 3.13.0
    App version:   0.8.0
    Image tag:     registry.k8s.io/metrics-server/metrics-server:v0.8.0
  ***********************************************************************

kube-prometheus-stack 설치

  (⎈|HomeLab:default) root@k8s-ctr:~# helm repo add prometheus-community https://prometheus-community.github.io/helm-charts

  (⎈|HomeLab:default) root@k8s-ctr:~# helm list -n monitoring
  NAME                    NAMESPACE       REVISION        UPDATED                                 STATUS          CHART                           APP VERSION
  kube-prometheus-stack   monitoring      1               2026-01-24 00:14:59.530116612 +0900 KST deployed        kube-prometheus-stack-80.13.3   v0.87.1
  (⎈|HomeLab:default) root@k8s-ctr:~# kubectl get pod,svc,ingress,pvc -n monitoring
  NAME                                                            READY   STATUS              RESTARTS   AGE
  pod/kube-prometheus-stack-grafana-5cb7c586f9-7ntdf              0/3     ContainerCreating   0          18s
  pod/kube-prometheus-stack-kube-state-metrics-7846957b5b-gjccp   0/1     Running             0          18s
  pod/kube-prometheus-stack-operator-584f446c98-nsm8c             0/1     ContainerCreating   0          18s
  pod/kube-prometheus-stack-prometheus-node-exporter-p7j45        1/1     Running             0          18s
  pod/kube-prometheus-stack-prometheus-node-exporter-slqhj        1/1     Running             0          18s

  NAME                                                     TYPE        CLUSTER-IP      EXTERNAL-IP   PORT(S)                         AGE
  service/kube-prometheus-stack-alertmanager               ClusterIP   10.96.42.69     <none>        9093/TCP,8080/TCP               18s
  service/kube-prometheus-stack-grafana                    NodePort    10.96.172.144   <none>        80:30002/TCP                    18s
  service/kube-prometheus-stack-kube-state-metrics         ClusterIP   10.96.34.132    <none>        8080/TCP                        18s
  service/kube-prometheus-stack-operator                   ClusterIP   10.96.116.217   <none>        443/TCP                         18s
  service/kube-prometheus-stack-prometheus                 NodePort    10.96.30.242    <none>        9090:30001/TCP,8080:30485/TCP   18s
  service/kube-prometheus-stack-prometheus-node-exporter   ClusterIP   10.96.83.43     <none>        9100/TCP

  (⎈|HomeLab:default) root@k8s-ctr:~# kubectl exec -it -n monitoring deploy/kube-prometheus-stack-grafana -- grafana --version
  grafana version 12.3.1
  (⎈|HomeLab:default) root@k8s-ctr:~# kubectl exec -it sts/prometheus-kube-prometheus-stack-prometheus -n monitoring -c prometheus -- prometheus --version
  prometheus, version 3.9.1 (branch: HEAD, revision: 9ec59baffb547e24f1468a53eb82901e58feabd8)
    build user:       root@61c3a9212c9e
    build date:       20260107-16:08:09
    go version:       go1.25.5
    platform:         linux/amd64
    tags:             netgo,builtinassets

k8s 대시보드 확인

Certificate exporter 설치 및 화면 구성

  (⎈|HomeLab:default) root@k8s-ctr:~# cat << EOF > cert-export-values.yaml
  # -- hostPaths Exporter
  hostPathsExporter:
    hostPathVolumeType: Directory

    daemonSets:
      cp:
        nodeSelector:
          node-role.kubernetes.io/control-plane: ""
        tolerations:
        - effect: NoSchedule
          key: node-role.kubernetes.io/control-plane
          operator: Exists

  (⎈|HomeLab:default) root@k8s-ctr:~# helm install x509-certificate-exporter enix/x509-certificate-exporter -n monitoring --values cert-export-values.yaml
  NAME: x509-certificate-exporter
  LAST DEPLOYED: Sat Jan 24 00:34:37 2026
  NAMESPACE: monitoring
  STATUS: deployed
  REVISION: 1
  TEST SUITE: None
  (⎈|HomeLab:default) root@k8s-ctr:~# helm list -n monitoring
  NAME                            NAMESPACE       REVISION        UPDATED                                 STATUS         CHART                            APP VERSION
  kube-prometheus-stack           monitoring      1               2026-01-24 00:14:59.530116612 +0900 KST deployed       kube-prometheus-stack-80.13.3    v0.87.1
  x509-certificate-exporter       monitoring      1               2026-01-24 00:34:37.079222386 +0900 KST deployed       x509-certificate-exporter-3.19.1 3.19.1

  (⎈|HomeLab:default) root@k8s-ctr:~# curl -s 10.244.0.4:9793/metrics | grep '^x509' | head -n 3
  x509_cert_expired{filename="apiserver-etcd-client.crt",filepath="/etc/kubernetes/pki/apiserver-etcd-client.crt",issuer_CN="etcd-ca",serial_number="5085519134918927718",subject_CN="kube-apiserver-etcd-client"} 0
  x509_cert_expired{filename="apiserver.crt",filepath="/etc/kubernetes/pki/apiserver.crt",issuer_CN="kubernetes",serial_number="8664196532623716359",subject_CN="kube-apiserver"} 0
  x509_cert_expired{filename="ca.crt",filepath="/etc/kubernetes/pki/ca.crt",issuer_CN="kubernetes",serial_number="303979118069449790",subject_CN="kubernetes"} 0

인증서 갱신

 (⎈|HomeLab:default) root@k8s-ctr:~# **kc describe cm -n kube-system kubeadm-config | grep -i cert**
 *caCertificateValidityPeriod: 87600h0m0s
 certificateValidityPeriod: 8760h0m0s*

 (⎈|HomeLab:default) root@k8s-ctr:~# **kubeadm certs check-expiration -v 6**

 **cat /etc/kubernetes/pki/apiserver.crt | openssl x509 -text -noout**
 *Certificate:
     Data:
         Version: 3 (0x2)
         Serial Number: 9019049356910942135 (0x7d2a199aea6457b7)
         Signature Algorithm: sha256WithRSAEncryption
         Issuer: CN=kubernetes
         **Validity**
             Not Before: Jan 24 00:18:08 2026 GMT
             **Not After : Jan 24 00:23:08 2027 GMT**
         Subject: CN=kube-apiserver*
 ====================중략===============================

K8S Upgrade by kubeadm

쿠버네티스는 1년에 3개의 마이너 버전 출시하며 → 최근 3개 버전 패치를 지원 해준다.

버젼 관련 정보

HA 클러스터에서는 가장 낮은 kube-apiserver 버전이 모든 기준
kube-apiserver(HA)는 N / N-1 까지만 가능하며 업그레이드는 apiserver부터 진행
kubelet / kube-proxy는 apiserver보다 신버젼 불가, 최대 3 마이너 OLD 허용
kcm·scheduler·ccm은 apiserver보다 신버젼 불가 1 마이너 OLD만 허용
kubectl 은 apiserver 기준 ±1 마이너 버전까지 허용

실습환경 배포
C:\Users\bom\Desktop\스터디\upgrade_week3>vagrant up
Bringing machine 'k8s-ctr' up with 'virtualbox' provider...
Bringing machine 'k8s-w1' up with 'virtualbox' provider...
Bringing machine 'k8s-w2' up with 'virtualbox' provider...

사전준비

kube-prometheus-stack 설치

  (⎈|HomeLab:N/A) root@k8s-ctr:~#kubectl exec -it sts/prometheus-kube-prometheus-stack-prometheus -n monitoring -c prometheus -- **prometheus --version**
  *prometheus, version 3.9.1*

  ****(⎈|HomeLab:N/A) root@k8s-ctr:~#kubectl exec -it -n monitoring deploy/kube-prometheus-stack-grafana -- **grafana --version**
  *grafana version 12.3.1*

etcd백업

  ##etcd백업
  (⎈|HomeLab:N/A) root@k8s-ctr:~# crictl images | grep etcd
  registry.k8s.io/etcd                      3.5.24-0            8cb12dd0c3e42       23.7MB
  (⎈|HomeLab:N/A) root@k8s-ctr:~# kubectl exec -n kube-system etcd-k8s-ctr -- etcdctl version
  etcdctl version: 3.5.24
  API version: 3.5
  (⎈|HomeLab:N/A) root@k8s-ctr:~# ETCD_VER=3.5.24
  (⎈|HomeLab:N/A) root@k8s-ctr:~# ARCH=amd64
  (⎈|HomeLab:N/A) root@k8s-ctr:~#
  (⎈|HomeLab:N/A) root@k8s-ctr:~# curl -L https://github.com/etcd-io/etcd/releases/download/v${ETCD_VER}/etcd-v${ETCD_VER}-linux-${ARCH}.tar.gz -o /tmp/etcd-v${ETCD_VER}.tar.gz
    % Total    % Received % Xferd  Average Speed   Time    Time     Time  Current
                                   Dload  Upload   Total   Spent    Left  Speed
    0     0    0     0    0     0      0      0 --:--:-- --:--:-- --:--:--     0
  100 21.3M  100 21.3M    0     0  17.4M      0  0:00:01  0:00:01 --:--:-- 17.4M
  (⎈|HomeLab:N/A) root@k8s-ctr:~# mkdir -p /tmp/etcd-download
  (⎈|HomeLab:N/A) root@k8s-ctr:~# tar xzvf /tmp/etcd-v${ETCD_VER}.tar.gz -C /tmp/etcd-download --strip-components=1
  etcd-v3.5.24-linux-amd64/Documentation/
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/apispec/
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/apispec/swagger/
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/apispec/swagger/v3lock.swagger.json
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/apispec/swagger/v3election.swagger.json
  etcd-v3.5.24-linux-amd64/Documentation/dev-guide/apispec/swagger/rpc.swagger.json
  etcd-v3.5.24-linux-amd64/Documentation/README.md
  etcd-v3.5.24-linux-amd64/README-etcdutl.md
  etcd-v3.5.24-linux-amd64/READMEv2-etcdctl.md
  etcd-v3.5.24-linux-amd64/README-etcdctl.md
  etcd-v3.5.24-linux-amd64/README.md
  etcd-v3.5.24-linux-amd64/etcdutl
  etcd-v3.5.24-linux-amd64/etcdctl
  etcd-v3.5.24-linux-amd64/etcd
  (⎈|HomeLab:N/A) root@k8s-ctr:~# mv /tmp/etcd-download/etcdctl /usr/local/bin/
  mv /tmp/etcd-download/etcdutl /usr/local/bin/
  chown root:root /usr/local/bin/etcdctl
  chown root:root /usr/local/bin/etcdutl
  (⎈|HomeLab:N/A) root@k8s-ctr:~# etcdctl version
  etcdctl version: 3.5.24
  API version: 3.5

  (⎈|HomeLab:N/A) root@k8s-ctr:~# etcdctl snapshot save /backup/etcd-snapshot-$(date +%F).db
  {"level":"info","ts":"2026-01-24T01:04:27.603103+0900","caller":"snapshot/v3_snapshot.go:65","msg":"created temporary db file","path":"/backup/etcd-snapshot-2026-01-24.db.part"}

Flannel CNI업그레이드

이미지 다운로드

  ⎈|HomeLab:N/A) root@k8s-ctr:~# crictl images | grep flannel
  ghcr.io/flannel-io/flannel-cni-plugin     v1.7.1-flannel1     cca2af40a4a9e       4.88MB
  ghcr.io/flannel-io/flannel                v0.27.3             5de71980e553f       34MB
  ghcr.io/flannel-io/flannel                v0.27.4             e83704a177312       34.1MB

Helm업그레이드


  (⎈|HomeLab:N/A) root@k8s-ctr:~# cat << EOF > flannel.yaml
  podCidr: "10.244.0.0/16"
  flannel:
    cniBinDir: "/opt/cni/bin"
    cniConfDir: "/etc/cni/net.d"
    args:
    - "--ip-masq"
    - "--kube-subnet-mgr"
    - "--iface=enp0s9"
    backend: "vxlan"
  image:
    tag: v0.27.4
  EOF

  (⎈|HomeLab:N/A) root@k8s-ctr:~# helm upgrade flannel flannel/flannel -n kube-flannel -f flannel.yaml --version 0.27.4
  Release "flannel" has been upgraded. Happy Helming!
  NAME: flannel
  LAST DEPLOYED: Sat Jan 24 01:07:43 2026
  NAMESPACE: kube-flannel
  STATUS: deployed
  REVISION: 2
  TEST SUITE: None

Rockey Linux OS 마이너버젼 업그레이드

업그레이드

  (⎈|HomeLab:N/A) root@k8s-ctr:~# rpm -q containerd.io
  containerd.io-2.1.5-1.el10.aarch64

  (⎈|HomeLab:N/A) root@k8s-ctr:~# dnf install -y 'dnf-command(versionlock)'

  (⎈|HomeLab:N/A) root@k8s-ctr:~# dnf versionlock add containerd.io
  Adding versionlock on: containerd.io-0:2.1.5-1.el10.*

  (⎈|HomeLab:N/A) root@k8s-ctr:~# dnf versionlock list
  containerd.io-0:2.1.5-1.el10.*
  -------------------------------------------------------------

  (⎈|HomeLab:N/A) root@k8s-ctr:~# dnf -y update
  Running scriptlet: kernel-modules-core-6.12.0-124.27.1.el10_1.aarch64                                           584/584

  (⎈|HomeLab:N/A) root@k8s-ctr:~# reboot
  (⎈|HomeLab:N/A) root@k8s-ctr:~# ping 192.168.10.100
  64 bytes from 192.168.10.100: icmp_seq=47 ttl=64 time=0.454 ms
  64 bytes from 192.168.10.100: icmp_seq=48 ttl=64 time=0.532 ms
  Request timeout for icmp_seq 49                                 # 재부팅 시점에 ping 통신 불가
  Request timeout for icmp_seq 50

  (⎈|HomeLab:N/A) root@k8s-ctr:~# kubectl get pod -A -owide | grep k8s-ctr
  default        curl-pod                                                    1/1     Running   1 (2m25s ago)   61m    10.244.0.3       k8s-ctr   <none>           <none>
  kube-flannel   kube-flannel-ds-f2572                                       1/1     Running   1 (2m25s ago)   15m    192.168.10.100   k8s-ctr   <none>           <none>
  kube-system    coredns-668d6bf9bc-ctkmb                                    1/1     Running   1 (2m25s ago)   142m   10.244.0.2       k8s-ctr   <none>           <none>
  kube-system    etcd-k8s-ctr                                                1/1     Running   1 (2m25s ago)   142m   192.168.10.100   k8s-ctr   <none>           <none>
  kube-system    kube-apiserver-k8s-ctr                                      1/1     Running   1 (2m25s ago)   142m   192.168.10.100   k8s-ctr   <none>           <none>
  kube-system    kube-controller-manager-k8s-ctr                             1/1     Running   1 (2m25s ago)   142m   192.168.10.100   k8s-ctr   <none>           <none>
  kube-system    kube-proxy-wwd9c                                            1/1     Running   1 (2m25s ago)   142m   192.168.10.100   k8s-ctr   <none>           <none>
  kube-system    kube-scheduler-k8s-ctr                                      1/1     Running   1 (2m25s ago)   142m   192.168.10.100   k8s-ctr   <none>           <none>
  monitoring     kube-prometheus-stack-prometheus-node-exporter-6k5rk        1/1     Running   1 (2m25s ago)   36m    192.168.10.100   k8s-ctr   <none>           <none>

kubeadm,kubelet,kubectl 업그레이드

고려사항(업그레이드순서)
- kubeadm 업그레이드
- kubelet / kubectl 업그레이드
- kubelet 재시작
containerd 관련 유의사항
- containerd 재시작 불필요함

업그레이드 진행

  (⎈|HomeLab:N/A) root@k8s-ctr:~# **dnf list --showduplicates kubeadm --disableexcludes=kubernetes**
  *Installed Packages
  kubeadm.aarch64                                       **1.32.11-150500.1.1**                                       @kubernetes
  Available Packages*
  (⎈|HomeLab:N/A) root@k8s-ctr:~# dnf install -y --disableexcludes=kubernetes kubeadm-**1.33.7-150500.1.1**

  (⎈|HomeLab:N/A) root@k8s-ctr:~# **kubeadm upgrade plan**
  *[upgrade/versions] Target version: **v1.33.7**
  [upgrade/versions] Latest version in the v1.32 series: **v1.32.11***

  - etcd schema 확인
  - kube-apiserver / controller-manager / scheduler static pod 교체
  - CoreDNS 업그레이드
  - kube-proxy 업그레이드

  ******(⎈|HomeLab:N/A) root@k8s-ctr:~# **kubeadm config images pull**
  *[config/images] Pulled registry.k8s.io/kube-apiserver:v1.33.7
  [config/images] Pulled registry.k8s.io/kube-controller-manager:v1.33.7

  *****(⎈|HomeLab:N/A) root@k8s-ctr:~# crictl pull registry.k8s.io/kube-proxy:v1.33.7

  ****(⎈|HomeLab:N/A) root@k8s-ctr:~# crictl pull registry.k8s.io/coredns/coredns:v1.12.0

  ****(⎈|HomeLab:N/A) ****root@k8s-ctr:~# **kubeadm upgrade apply v1.33.7**
  *[upgrade] Reading configuration from the "kubeadm-config" ConfigMap in namespace "kube-system"...
  [upgrade] Use 'kubeadm init phase upload-config --config your-config-file' to re-upload it.
  [upgrade/preflight] Running preflight checks
  [upgrade] Running cluster health checks
  [upgrade/preflight] You have chosen to upgrade the cluster version to "v1.33.7"
  [upgrade/versions] Cluster version: v1.32.11
  [upgrade/versions] kubeadm version: v1.33.7
  [upgrade] Are you sure you want to proceed? [y/N]: **y***

  (⎈|HomeLab:N/A) ****root@k8s-ctr:~# dnf install -y --disableexcludes=kubernetes kubeadm-**1.34.3-150500.1.1**

  (⎈|HomeLab:N/A) ****root@k8s-ctr:~# **kubeadm upgrade plan**
  *[upgrade/versions] Target version: v1.34.3
  [upgrade/versions] Latest version in the v1.33 series: v1.33.7*

  (⎈|HomeLab:N/A) ****root@k8s-ctr:~#**crictl pull registry.k8s.io/kube-proxy:v1.34.3**
  (⎈|HomeLab:N/A) ****root@k8s-ctr:~#**crictl pull registry.k8s.io/coredns/coredns:v1.12.1**
  (⎈|HomeLab:N/A) ****root@k8s-ctr:~#**crictl pull registry.k8s.io/pause:3.10.1**

  (⎈|HomeLab:N/A) ****root@k8s-ctr:~#**kubeadm upgrade apply v1.34.3 --yes**
  *[upgrade] Reading configuration from the "kubeadm-config" ConfigMap in namespace "kube-system"...
  [upgrade] Use 'kubeadm init phase upload-config kubeadm --config your-config-file' to re-upload it.
  [upgrade/preflight] Running preflight checks
  [upgrade] Running cluster health checks*

  (⎈|HomeLab:N/A) ****root@k8s-ctr:~# dnf install -y --disableexcludes=kubernetes **kubelet-1.34.3-150500.1.1 kubectl-1.34.3-150500.1.1**
  *Upgrading:
   kubectl                  aarch64                  1.33.7-150500.1.1                    kubernetes                  9.7 M
   kubelet                  aarch64                  1.33.7-150500.1.1*

   (⎈|HomeLab:N/A) ****root@k8s-ctr:~# **systemctl daemon-reload**
   (⎈|HomeLab:N/A) ****root@k8s-ctr:~# **systemctl restart kubelet**        **

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 6주차 과제 (1)	2026.02.13
K8S ) 5주차 과제 (0)	2026.02.06
K8S) 4주차 과제 (0)	2026.01.31
K8S)2주차 과제 (0)	2026.01.15
K8S) 1주차 과제 (0)	2026.01.08

PREV 이전 1 2 3 4 NEXT 다음

ZO

Study

K8S ) 7주차 과제

RKE2란?

RKE2 실습

Cluster API 실습

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 6주차 과제

Kubespray offline 설치

폐쇄망환경에서 정상적인 서비스 제공을 위한 주요 구성 요소

폐쇄망 실습환경구성

Kubespray Offline 설치소개

1️⃣ 오프라인 배포 준비 기능

2️⃣ Kubespray Offline 동작 흐름

K8S 관련 폐쇄망 실습

'Study > K8S-Deploy' 카테고리의 다른 글

K8S ) 5주차 과제

실습 환경 배포

1. 실습환경배포

'Study > K8S-Deploy' 카테고리의 다른 글

K8S) 4주차 과제

'Study > K8S-Deploy' 카테고리의 다른 글

K8S)3주차 과제

Kubeadm deep dive

K8S Upgrade by kubeadm

'Study > K8S-Deploy' 카테고리의 다른 글

+ Recent posts

티스토리툴바
